- Page 1 W&T 2 / 4 Computer Adapter Manual 2 / 4 Computer Adapter Model 15210 25210, 25410 W&T 25215, 25415 Release Subject to error and alteration...
- Page 2 W&T 2 / 4 Computer Adapter © 07/2004 by Wiesemann & Theis GmbH Subject to errors and changes: Since we can make mistakes, none of our statements should be used without checking. Please let us know of any mistakes or misunderstandings you are aware of, so that we can recognize and eliminate them quickly.
- Page 3 W&T 2 / 4 Computer Adapter Subject to error and alteration...
-
Page 4: Table Of Contents
W&T 2 / 4 Computer Adapter Index Inhalt PC 2 Computer Adapter, Model 15210 ......... 29 Centronics 2 Computer Adapter, Model 25210 ..... 33 Centronics 4 Computer Adapter, Model 25410 ..... 37 EPP/ECP/Bitronics 2 Computer Adapter, Model 25215 ... 41... -
Page 5: Pc 2 Computer Adapter, Model 15210
W&T 2 / 4 Computer Adapter PC 2 Computer Adapter, Model 15210 The 15210 Adapter allows two PC‘s to be connected to a single printer over a parallel interface. The Adapter electronics are integrated in a somewhat larger Centronics plug which can be connected directly to the printer port. - Page 6 W&T 2 / 4 Computer Adapter Supply voltage The Adapter is designed using power-saving CMOS technology and can generally be powered with no problem by the signal lines of the parallel interface. Optionally it is possible to power the Adapter via an external power supply having an output voltage or 5V regulated.
- Page 7 W&T 2 / 4 Computer Adapter Technical Data Inputs: 2x DB25 male each with 2m of cable Output: 36-pin Centronics male for connecting adapter directly to the printer Data direction: unidirectional from PC to printer Supply voltage: from the Centronics signals no external power supply generally needed optional: external 5V power supply...
- Page 8 W&T 2 / 4 Computer Adapter...
-
Page 9: Centronics 2 Computer Adapter, Model 25210
W&T 2 / 4 Computer Adapter Centronics 2 Computer Adapter, Model 25210 The 25210 Adapter allows two PC‘s to be connected to a single printer over a parallel interface. The Adapter input provides 36-pin Centronics females so that the original printer cables can still be used. A printer cable for connecting the printer to the Adapter is included. - Page 10 W&T 2 / 4 Computer Adapter Supply voltage The Adapter is designed using power-saving CMOS technology and can generally be powered with no problem by the signal lines of the parallel interface.. Optionally it is possible to power the Adapter via an external power supply having an output voltage or 5V regulated.
- Page 11 W&T 2 / 4 Computer Adapter Technical Data Inputs: 2x 36-pin oCentronics females with 0.5m cable each Output: 36-pin Centronics male for connecting adapter directly to the printer Data direction: unidirectional from PC to printer Supply voltage: from the Centronics signals no external power supply generally needed optional: external 5V power supply...
- Page 12 W&T 2 / 4 Computer Adapter...
-
Page 13: Centronics 4 Computer Adapter, Model 25410
W&T 2 / 4 Computer Adapter Centronics 4 Computer Adapter, Model 25410 The 25410 Adapter allows up to four PC‘s to be connected to a single printer over a parallel interface. The Adapter electronics are integrated in a Centronics which can be connected directly to the printer port. - Page 14 W&T 2 / 4 Computer Adapter Supply voltage The Adapter is designed using power-saving CMOS technology and can generally be powered with no problem by the signal lines of the parallel interface.. Optionally it is possible to power the Adapter via an external power supply having an output voltage or 5V regulated.
- Page 15 W&T 2 / 4 Computer Adapter Technical Data Inputs: 4x 36-pin Centronics females Output: 25-pin SUB-D female Data direction: unidirectional from PC to printer Supply voltage: from the Centronics signals no external power supply generally needed optional: external 5V power supply Current draw: approx.
- Page 16 W&T 2 / 4 Computer Adapter...
-
Page 17: Epp/Ecp/Bitronics 2 Computer Adapter, Model 25215
W&T 2 / 4 Computer Adapter EPP/ECP/Bitronics 2 Computer Adapter, Model 25215 The 25215 Adapter allows two PC‘s to be connected to a single printer over a bidirectional parallel interface. The Adapter input provides 36-pin Centronics females so that the original printer cables can still be used. A printer cable for connecting the printer to the Adapter is included. - Page 18 W&T 2 / 4 Computer Adapter If another print job is started parallel to a running print job on the second connected computer, a Windows-generated error message is generally displayed immediately to indicate that the connected printer is not available. The driver attempts to establish contact with the printer without delay but of course fails, since the printer is at this moment already used by another computer.
- Page 19 W&T 2 / 4 Computer Adapter Technical Data Inputs: 2x 36-pin oCentronics females with 0.5m cable each Output: 36-pin Centronics male for connecting adapter directly to the printer P1284/EPP modes: Compatible, Nibble, EPP and ECP mode Supply voltage: from the Centronics signals no external power supply generally needed optional: external 5V power supply...
- Page 20 W&T 2 / 4 Computer Adapter...
-
Page 21: Epp/Ecp/Bitronics 4 Computer Adapter, Model 25415
W&T 2 / 4 Computer Adapter EPP/ECP/Bitronics 4 Computer Adapter, Model 25415 The 25415 Adapter allows up to four PC‘s to be connected to a single printer over a bidirectional parallel interface. The Adapter electronics are integrated in a Centronics which can be connected directly to the printer port. - Page 22 W&T 2 / 4 Computer Adapter If another print job is started parallel to a running print job on the second connected computer, a Windows-generated error message is generally displayed immediately to indicate that the connected printer is not available. The driver attempts to establish contact with the printer without delay but of course fails, since the printer is at this moment already used by another computer.
- Page 23 W&T 2 / 4 Computer Adapter Technical Data Inputs: 4x 36-pin Centronics females Output: 25-pin SUB-D female P1284/EPP modes: Compatible, Nibble, EPP and ECP mode Supply voltage: from the Centronics signals no external power supply generally needed optional: external 5V power supply Current draw: approx.
- Page 24 W&T 2 / 4 Computer Adapter...
