Summary of Contents for RF Arrays RWF111HM
- Page 1 RWF111HM Quick Start Guide RF H OWER ODULE RWF111HM High Power Module Reference Design Revision 1.1.1 ■ 01/02/09 Confidential Page 1 of 4...
- Page 2 OWER ODULE Introduction The RWF111HM is a 2-layer FR4 high power module to increase the power and sensitivity of any low power module operating in 2.4GHz frequency band. It comprises of RF Front End RWF111, UPG2214 GaAs SPDT switch, 748323024 Wurth Elektronik 2.4GHz BPF, 74LVC2G04 Dual inverter and two 2-pin relimate male connectors for supply, ground and control.
- Page 3 RWF111HM Quick Start Guide RF H OWER ODULE Schematic of RWF111HM Revision 1.1.1 ■ 01/02/09 Confidential Page 3 of 4...
- Page 4 This publication supersedes and replaces all information previously supplied. RF Arrays Inc. products are NOT authorized for use in implantation or life support applications or systems without express written approval from RF Arrays Inc.
