Please read the following instructions and warnigns carefully.
Keep this instruction manual for future reference.
Tools required: Screwdriver and Drill (not included)
For technical support see back page.
Adult use only.
WARNING:
Mom Applauded Features:
• 5" video monitor screen
• Wireless camera with night vision
• Movement and position monitor with an alert for inactivity
• User friendly interface
INSTRUCTION MANUAL
WARNING:
or cords within 3 feet of the crib. Use enclosed Security Clips to help secure
cord away from baby's reach. Never use extension cords with AC Adapters.
Only use the AC adapters provided.
Adult assembly required. Keep small parts
away from children when assembling.
Warnings & Guidelines:
STRANGULATION HAZARD - Keep cord
out of baby's reach. NEVER place camera
®
1
Advertisement
Table of Contents
Related Manuals for BABY DELIGHT AJEY-402R
Summary of Contents for BABY DELIGHT AJEY-402R
- Page 1 Please read the following instructions and warnigns carefully. Keep this instruction manual for future reference. Tools required: Screwdriver and Drill (not included) For technical support see back page. Adult use only. WARNING: Adult assembly required. Keep small parts away from children when assembling. ®...
-
Page 2: Battery Warning
Warnings & Guidelines • Continued WARNING: THIS PRODUCT CANNOT REPLACE RESPONSIBLE ADULT SUPERVISION. • STRANGULATION HAZARD - Keep cord out of baby’s reach. NEVER place camera or cords within 3 feet of the crib. Use enclosed Security Clips to help secure cord away from baby’s reach. Never use extension cords with AC adapters. - Page 3 All Components • 1 camera, 1 monitor, 1 movement unit • 6 Cable Clips • 2 AC Adaptors • 1 Actor and Wall Mount Screw Camera Movement Unit ® AC Adapters Hardware ® Monitor Features • Camera Microphone Lens Power On LED Power On/Off DC-7.5V 500mA...
- Page 4 Features • Monitor Menu Video On/Off Volume VIDEO / MENU/ Alarm? Ok/Select Sound/Lights ® Power on LED Speaker Toggle Up/Down (Underneath) Magnetic Clip for Clothing DC-7.5V 500mA ® Adjustable Battery AC Adapter Kickstand Compartment Plugin NOTE: There is no need to pair any of the components. The Camera, Monitor and Movement Unit have all been synched at the factory.
- Page 5 Camera Setup • Adult Assembly Required There is no need to pair any of the components. The Camera, Monitor and Movement Unit have all been synched at the factory. WALL MOUNT: Place camera in desired location Determine a location for the Camera that will provide the best view of your baby in the crib.
- Page 6 Secure the cord to the wall using the 6 Security Clips included to keep cord away from baby’s reach. Be sure to test reception and Camera positioning TABLE TOP: Place camera in desired location, secure cord, and turn on. Be sure to test reception and Camera positioning.
- Page 7 Movement Unit Setup • Adult Assembly Required The Movement Unit will transmit movement info and baby’s orientation (side, stomach and back) to the Camera. The Camera will transit this information to the Monitor and display that information on the screen. For best results, make sure the Movement Unit is within 30 feet of the Camera.
- Page 8 Charging Icon – This means the Movement Unit is currently in the recharging dock in the Camera and is charging. Charging No signal icon – This means the Movement Unit is out of range or powered off while not charging in the dock. Please locate the movement unit and place it in the charging dock on the Camera or move the Movement unit closer to the Camera.
-
Page 9: Troubleshooting
Alarm Icon – After no movement has Pause Icon – Pressing the Pause been detected for 15 seconds, the button on the Monitor when the Alarm Monitor will begin to beep. After 20 Icon is on the screen and the Monitor seconds of no movement detected, the is alarming will silence the Alarm for Alarm icon will appear on the Monitor... - Page 10 Use the Up button to move to You should see the PAIRING the PAIRING button and press SCREEN. the OK button. select Power the Camera on. You should see live video on the Monitor. DC-7.5V 500mA To Pair the Movement Unit and Camera: Place Monitor and Press the Menu button on the Monitor and Movement Unit within...
-
Page 11: Pairing Screen
Use the Up button to move to Power the Movement Unit the PAIRING button and press on (hold the power button the OK button. You should see the for 3 seconds). You should see PAIRING SCREEN. movement and orientation information on the Monitor. ®... -
Page 12: Cleaning Information
Limited Warranty At Baby Delight, Inc. we make innovative and high quality products for babies, children and their parents. We warrant this product to be free from defects in... -
Page 13: Fcc Caution
FCC Caution: Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
