Page 1: Espresso Machine
Espresso Machine Model CM-CN-0200 Item 21602 Instruction Manual Revised - 10/20/2017 Toll Free: 1-800-465-0234 Fax: 905-607-0234 Email: service@omcan.com www.omcan.com... -
Page 2: Table Of Contents
Table of Contents Model CM-CN-0200 Section Page General Information --------------------------------------------------------------------------- 3 - 4 Safety and Warranty --------------------------------------------------------------------------- 4 - 5 Technical Specifications -------------------------------------------------------------------------- 6 Installation --------------------------------------------------------------------------------------- 6 - 8 Operation --------------------------------------------------------------------------------------- 8 - 14 Maintenance --------------------------------------------------------------------------------- 14 - 17 Troubleshooting... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Safety And Warranty
Si el paquete ha sufrido un manejo de poco cuidado, golpes o daños (visible o oculto) por favor anote en la factura antes de aceptar la entrega y contacte Omcan dentro de las 24 horas, de modo que podamos iniciar una reclamación con la compañia. - Page 5 When disconnecting the main cable, never pull on the main cable or the machine itself. • Never repair or open the coffee machine yourself. Any repairs may only be carried out by Omcan using original spare parts and accessories. •...
-
Page 6: Technical Specifications
Technical Specifications Model CM-CN-0200 Power 1330 W Water Tank 1.9 litres / 2 quarts Pump Pressure Static, Max. 15 bar Bean Tank Capacity 200 grams / 7 ounce Coffee Grounds Container Capacity Max. 15 portions Power Cord Length Approx. 1.3m / 51 3/16”... -
Page 7: Installation
Installation • A fine grinding degree for bright roasts (the smaller the dots, the finer the grinding) • A coarse degree for dark roasts (the larger the dots, the coarser the grinding) 1. The grinding degree may only be adjusted while the grinding gear is running. 2. -
Page 8: Operation
Installation REPLACING THE FILTER 1. After drawing off approximately 50 litres, the filter cartridge will be used up. A message requesting you to replace the filter will appear on the display. [This will appear on the screen: READY / FILTER] 2. - Page 9 Operation 2. You can adjust the water quantity before the draw-off operation using the Rotary switch. The adjusted value (ML) refers to 1 cup. 3. You can stop the draw-off operation at any time by pressing any coffee draw-off key. 4.
- Page 10 Operation DRAWING OFF STEAM 1. To ensure perfect operation, clean the 2-stage frothing jet regularly. Screw the nozzle off and hold the nozzle at the top and at the bottom end and screw it apart. Thoroughly rinse the 3 parts under running water.
- Page 11 Operation settings last adjusted. 7. For cappuccino, turn the selector switch to area. 8. For hot milk, turn the selector switch to area. 9. Now place the cup with the cappuccino froth or the hot milk under the coffee spout and draw off the product of your choice.
- Page 12 Operation 2. Press programming key until FILTER appears. The illuminated ring is active. 3. Turn the Rotary switch until Aroma is displayed. [This will appear on the screen: AROMA] 4. Press the rotary switch. [This will appear on the screen: INTENSIVE] 5.
- Page 13 Operation Rotary switch. [This will appear on the screen: READY] PROGRAMMING THE AUTOMATIC SWITCH-OFF TIME 1. You must program the time if you want to use the automatic switch-off function. [This will appear on the screen: READY] 2. Press programming key until FILTER appears. The illuminated ring is active. 3.
-
Page 14: Maintenance
Operation PROGRAMMING THE DISPLAY FOR ML/OZ 1. Press the Rotary switch until FILTER -/_ appears. The illuminated ring is active. 2. Turn the Rotary switch until DISPLAY appears. 3. Press the Rotary switch until ML/OZ appears. 4. Select a setting of your choice. 5. - Page 15 Maintenance COFFEE MACHINE DECALCIFY During operation, the machine will calcify. The degree of scaling depends on the hardness of the water in your region. The machine will inform you when de-scaling is required. You can still draw off coffee or hot water/ steam.
- Page 16 Maintenance 7. Put a container under the adjustable coffee spout. [This will appear on the screen: PRESS / RINSE] 8. Press the maintenance key. [This will appear on the screen: CLEANING / ADD / TABLET] 9. Fill in the tablet. [This will appear on the screen: PRESS / RINSE] 10.
-
Page 17: Troubleshooting
Very loud noise coming from the grinding gear Foreign body in grinding gear: Drawing off pre- ground coffee still possible. Have the coffee machine checked by Omcan Too little froth when frothing milk 2-stage frothing jet blocked: Clean 2-stage frothing jet... -
Page 18: Parts Breakdown
4. Switch on 5. Have coffee machine checked by Omcan Note: High-frequency, electromagnetic interference may influence the display. Drawing off coffee is possible at any time. If the messages or problems still persist, please contact Omcan. Parts Breakdown Model CM-CN-0200 21602 Item No. - Page 19 Parts Breakdown Model CM-CN-0200 21602...
-
Page 20: Electrical Schematics
Electrical Schematics Model CM-CN-0200 21602 Transformer DC Motor (small) Thermostat Pump Fusible Power Board Protector Power Switch EM1 Power Line Fusible Filter Protector Boiler Terminal Block DC Motor (Big) Power Line... -
Page 21: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... -
Page 22: Notes
Notes ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________ ________________________________________________________________________________________... -
Page 23: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: Merci d’avoir acheté... - Page 24 Since 1951 Omcan has grown to become a leading distributor of equipment and supplies to the North American food service industry. Our success over these many years can be attributed to our commitment to strengthen and develop new and existing relationships with our valued customers and manufacturers.
