meitav-tec RS03 Operating Instructions

Room sensor

Operating instructions

The RS03 Room Sensor with temperature adjustment dial is designed

for use with Meitav-tec controllers.

The dial on the front of the Room Sensor allows the occupant to adjust

the temperature set point for a warmer or cooler temperature within the

range of ±4°C

Turn the set point temperature dial counter clockwise for cooler temperature (cooling).

Note: The maximum temperature set point for cooling (the dial at leftmost position, is the room ambient

temperature - 4°C

Set point = Room temperature (no demand for cooling)

Set point = Room temperature - 4°C (cooling)

Turn the set point temperature dial clockwise for warmer temperature (heating).

Note: The maximum temperature set point for heating (the dial at rightmost position, is the room ambient

temperature + 4°C

RS03

Remote Sensor with

temperature adjustment dial

Set point = Room temperature (no demand for heating)

Set point = Room temperature + 4°C (heating)
