Summary of Contents for Blue Bamboo P25M
- Page 1 P25M Installation Guide P25M Bluetooth Printer Quick Installation Guide http://www.bluebamboo.com...
- Page 2 P25M Installation Guide FCC compliance statement “This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.”...
- Page 3 P25M Installation Guide 1 Unpacking P25 Printer When opening the original shipping carton, carefully inspect the contents. It should include the following items listed below. If any items are damaged or missing, please contact your dealer. Figure 1: Unpacking P25 Printer...
-
Page 4: Installation
P25M Installation Guide 2 Installation 2.1 Hardware features Figure 2: Hardware features 2.2 Inserting the paper roll To install the paper roll in the printer, follow these steps: 1. Open the paper cover by applying your finger pressure to both sides of the printer cover, squeeze to release the lock. - Page 5 P25M Installation Guide Figure 3: Open the paper cover 3. Remove the paper roll and insert to a new roll, paper feeds from the bottom and allowing the free paper to extend outside the printer door. 4. Insert the paper roll in the printer as the picture shows:...
- Page 6 P25M Installation Guide Figure 4: Install paper roll 5. Press the cover down until it snaps in place. Allow a small amount of paper to extend outside the cover. http://www.bluebamboo.com...
-
Page 7: Battery Supply
P25M Installation Guide Figure 5: Pull out a small amount of paper 2.3 Battery supply 2.3.1 Installing/ Removing the battery pack Installing: The battery pack is located at the bottom of the printer. To install it please follow these steps: 1．Remove the isolation film on battery if the battery is a new one. - Page 8 P25M Installation Guide Figure 6: Arrow to show the direction 3．Insert the battery pack, and press until it clicks into place. Removal: 1. Release the battery pack by pressing the lock tab. http://www.bluebamboo.com...
- Page 9 P25M Installation Guide Figure 7: Remove battery 2. Remove the battery pack. 2.3.2 Battery and charge 1．Insert the DC plug of power adaptor into the power jack of printer; 2．Insert the AC plug of power adaptor into AC power supply;...
-
Page 10: Using The Printer
P25M Installation Guide 3 Using the printer 3.1 Control panel Buttons The POWER button switches the power on/off. In order to power off the power, you should press the POWER button for more than 1s. The FEED button advances the paper roll. Paper is advanced continuously until the button is released. -
Page 11: Version History
P25M Installation Guide Version History Version Author Date Description Initial Version Simon 2006-12-19 Modified 3.1, the part of LED http://www.bluebamboo.com...
