HDPlex H1 V2 Series Installation Manual

Fanless pc chassis
Hide thumbs

Advertisement

Quick Links

Download this manual
HDPLEX H1 V2 Series Fanless PC Chassis
Installation Guide Version 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the H1 V2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for HDPlex H1 V2 Series

  • Page 1 HDPLEX H1 V2 Series Fanless PC Chassis Installation Guide Version 1...
  • Page 2 Paypal/Rü ckerstattung zu Ihrem Auftrag. Offre de remboursement HDPLEX Recevez 20 dollars US pour tout achat d'un boitier HDPLEX. Pour bé né ficier de cette offre, rien de plus simple: prenez deux ou trois photos de votre installation HDPLEX accompagné es de vos commentaires ou suggestions (dans la langue de votre choix) puis postez-les sur un blog, sur Facebook, ou sur n'importe quel forum.

  • Page 3: Package Contents

    Package Contents H1.S V2 Chassis Top Plate Bottom Plate Left Side Panel Right Side Panel Backplate for Mini-ITX Faceplate (Brushed Silver/Black) Four Aluminum Feet with cushion Backplate for Thin-ITX (Optional and Sold Separately) H1.S Installation Kit List: B: M5*8 4pcs (Front) & M4*6 Screw 4pcs(Back) A: M3*6 Screw w/Ring 15pcs C: M4*8 Flat Head HEX Screw-Black 16pcs D: M3*8 Round Head Screw 8pcs...
  • Page 4 SSD/2.5” HDD Rack*2 for H1 Series Side I/O PCB with Aluminum Power Button and USB 3.0 Cable Power Adapter Plate for 7.4*5.0 and 5.5/2.5 DC Connector HDPLEX H1 Fanless CPU Heatsink System H-1: M3*6 Silver Screw 4pcs H-2: M3*8 CUP Head HEX Screw Silver 8pcs...
  • Page 5 H1 CPU Heatsink System Installation Install four feet with rubber cushion to the bottom plate via 4pcs M*6 HEX screw C. Install four 7mm copper post on the bottom plate ITX motherboard installation position and use M3 nut to fix the copper post from the back. Install aluminum power button and side I/O PCB using four copper post (12mm height) four M3*6 screws A.
  • Page 6 For AM4 socket, the straight edge of the AMD rack should be on the outside. Remove the two plastics holders on the AM4 socket, keep the original bottom plate untouched. Install the copper heatsink block using 4 H-3.
  • Page 7 Apply a very thin layer of thermal paste to the copper baseplate surface. Install 4pcs plastic screw holder onto the four corners and install the copper base to the motherboard using 4pcs H-3. Do not over tighten as this will bend the rack and put too much pressure on CPU.
  • Page 8 Connect SATA power, USB cable, and SODIMM memory module first. Those ports might not be accessible after heatpipes are installed. Apply a very thin layer of thermal paste to the copper plate groove using the dumbbell tool. Warning: Don't over use the thermal paste as it will decrease the thermal transfer efficiency. For all Thin-ITX and mini-ITX motherboard with 24PIN connector on the front，arrange the six heatpipes following those two examples.
  • Page 9 Example 1: Example 2: For mini-ITX motherboard with 24PIN ATX connector on the side, you could install the heatpipes like this:...

  • Page 10: Power Supply Installation

    A:HDPLEX Internal 80W/160W AC-DC Adapter +HDPLEX 160W DC-ATX converter Install the IEC C14 AC connector from the HDPLEX 80W/160W AC-DC package to the H1.S backplate using 2pcs M3*12 flat head screw I. If the capacitor on your motherboard back corner conflicts with the metal EMI filter box from the IEC C14 AC connector, please use the IEC C14 without the EMI filter which is included in the H1 accessories box.
  • Page 11 Install HDPLEX 80W AC-DC or 160W AC-DC on the H1.S faceplate using four M3*6 screws included in the AC-DC package. Plug HDPLEX 160W DC-ATX directly into the motherboard. HDPLEX 160W AC-DC adapter can also be installed on the H1.S V2 bottom plate.
  • Page 12 There are two positions to install the 400W HiFi DC-ATX. One is on the faceplate and the other is on the bottom plate. HDPLEX 160W DC-ATX could also be installed on the H1 bottom plate using two M2*6 screws included in the 160W DC-ATX package. It connects to motherboard via the 24PIN extension cable included in the H1 accessories box.
  • Page 13 Thin-ITX backplate for H1 series is sold separately and is NOT included in the H1 package. Connect the AC IEC input to the HDPLEX 160W AC-DC or 80W AC-DC adapter and connect 19V output 4PIN-2PIN cable onto the Thin-ITX 19V two PIN input. Both connectors have lock pin to ensure the correct direction.
  • Page 14 SSD to the rack. Install the rack to the H1 body using 3pcs G. H1 V2 series has three rack installation positions. Low profile memory is required for middle position to be available. If HDPLEX 80W AC-DC or 160W AC-DC adapter is installed, front HDD rack position will be disabled.
  • Page 15 M5 Cup head screw using the M5 wrench. Install the optical drive using four M2*4 screws. HDPLEX has designed a unique eject button connecting to the USB 2.0 onboard port to eject optical drive via OS command. The HDPLEX eject button does not rely on optical drive's own eject button.
  • Page 16 For suggestions and advice on HDPLEX fanless chassis, please visit our community at https://www.hdplex.com/forum Copyright 2018 HDPLEX LTD. All rights reserved. All trademarks are the property of their respective owners. Reproduction in whole or in part without written permission is prohibited.
