Archer BH-300 User Manual

Bluetooth wireless car hands-free kit

FCC ID: RSQ-BH300

FCC Compliance and Advisory Statement

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

conditions:(1) this device may not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

according to Part 15 of the FCC rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there is

no guarantee that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be determined by turning

the equipment off and on, the user is encouraged to try correct the interference by one or more

of the following measures:

1.Reorient the receiving antenna.

2.Increase the separation between the equipment and receiver.

3.Connect the equipment into and outlet on a circuit different from that to which the receiver is

connected.

4.Consult the dealer or an experienced radio/TV technician for help.

Any special accessories needed for compliance must be specified in the instruction manual.

Warning: A shielded-type power cord is required in order to meet FCC emission limits and

also to prevent interference to the nearby radio and television reception. It is essential that

only the supplied power cord be used. Use only shielded cables to connect I/O devices to this

equipment.

CAUSION: Any changes or modifications not expressly approved by the party responsible for

compliance could void your authority to operate the equipment.

Table of Contents

Do you have a question about the BH-300 and is the answer not in the manual?

Page 1 FCC ID: RSQ-BH300 FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, according to Part 15 of the FCC rules.
Page 2 BH-300 BLUETOOTH WIRELESS CAR HANDS-FREE KIT Features : 1. Bluetooth v1.2 complaint CSR BC03 Chip 2. Output level, 1mW, 0dBm, class 2 3. 10 meters working range 4. Voice dialing out function by push Ending-button on the car kit (subject to mobile phone support) 5.
Page 3 3. Press and hold Ending key again, until you can hear the tones come from the speaker. And LCD display -------P-------- 4. BH-300 is under the pairing mode now, then you can start to pair the BH-300 with your mobile phone now, and the pairing device name is BH-300, and password is 1234.
Page 4 General Spec. Standard Bluetooth V1.2 Link Mode ACL, eSCO (Extended Synchronous Connection-Oriented) Data Rate : Asynchronous:723.2kbps/57.6kbps Synchronous:433.9kbps/433.9kbps Frequency Band ISM 2.4GHz PAN, DUN, SPP, LAN, FTP, Synchronization, OBEX, HCRP, HID, FAX, BIP, AV, HS Receiver Signal Range Better than –76dBm @0.1%BER RF Output Power -6~+4dBm (Max +6 dBm) Operating Distance Up to 10 meters -40~+85 Degree C...
