PSB Image Series Specifications page 2

The unifying front baffle is a radical design precisely radiused, textured, and
shaped from man-made composites. Though expensive to "tool up," with
only four variations to manufacture this system is highly economical over
the long run. More importantly, its acoustically inert, non-reflective structure
promotes the Images' accurate response, lifelike imaging, and impressive
depth. And since cost savings in one area can be applied to others the Image
Series cabinets can be fabricated of heavy, non-resonant wood composites
with extensive cross-bracing. This yields remarkably rigid, non-resonant,
sonically pure enclosures—measurably and demonstrably superior to those
of virtually any competing designs.
The Image models combine easily to produce seamless results across the
critical "front stage". There are two horizontal Image models with impressive
T h e I m a g e S e r i e s
Image B15
Bookshelf/Surround
FREQUENCY RANGE (Anechoic Chamber)
Response
On Axis @ 0°±3dB 50-23,000Hz
On Axis @ 0°±1 1/2dB 70-20,000Hz
Off Axis @ 30°±1 1/2dB 70-10,000Hz
LF Cutoff -10dB 50Hz
SENSITIVITY (1W (2.83V) @ 1m, IEC-filtered Pink Noise, C-weighted)
Anechoic Chamber 89dB
Typical Listening Room 91dB
IMPEDANCE
Nominal 6 Ohms
Minimum 4 Ohms
INPUT POWER (RMS, Clipping <10% Time)
Recommended 10-80 Watts
Program 60 Watts
ACOUSTIC DESIGN
Tweeter Tweeter T (Nominal) 1" (25mm)
Aluminium Dome
with Ferrofluid
Woofer (Nominal) 5 1/4" (133mm)
Injection Molded
Metalized-
Polypropylene Cone
Rubber Surround
Crossover 2,200Hz, B3
Internal Volume 0.25 cu ft (6.9 liter)
Design Type Bass Reflex
2" Front Port
Video Shielded
SIZE (W x H x D) 7 x 13 3/8 x 9 5/8"
165 x 327 x 244mm
WEIGHT
Net 12 lb (5.5kg)/each
Shipping 27 lb (12.3kg)/pair
(Some finishes may not be available in all markets.)
FINISH
Black Ash, Maple
or Sienna
FEATURES
5-way Gold-plated
Binding Posts
Clear Bumpers
www.psbspeakers.com
- S p e c i f i c a t i o n s
Image B25 Image T45
Bookshelf/Surround Tower
45-23,000Hz 35-23,000Hz
59-20,000Hz 48-20,000Hz
59-10,000Hz 48-10,000Hz
40Hz 30Hz
89dB 90dB
91dB 93dB
6 Ohms 6 Ohms
4 Ohms 4 Ohms
10-100 Watts 10-150 Watts
70 Watts 100 Watts
1" (25mm) 1" (25mm)
Aluminium Dome Aluminium Dome
with Ferrofluid with Ferrofluid
6 1/2" (165mm) 2 x 5 1/4" (133mm)
Injection Molded Injection Molded
Metalized- Metalized-
Polypropylene Cone Polypropylene Cone
Rubber Surround Rubber Surround
2,500Hz, B3 2,200Hz, B3; 500Hz, LR4
0.50 cu ft (12.7 liter) 1.20 cu ft (33.6 liter)
Bass Reflex Bass Reflex
2" Front Port 2 x 2" Front Port
Video Shielded Video Shielded
8 1/2 x 15 3/4 x 11 15/16" 7 x 36 x 14 5/8"
203 x 387 x 303mm 165 x 914 x 372mm
Feet add 1" (25mm)
15 lb (6.8kg)/each 37 lb (16.8kg)/each
38 lb (17.3kg)/pair 47 lb (21.4kg)/each
Black Ash, Maple Black Ash, Maple
or Sienna or Sienna
5-way Gold-plated Dual, 5-way Gold-plated
Binding Posts Binding Posts
Clear Bumpers Bi-wireable/Bi-ampable
Feet/stabilizers with
Adjustable Spikes and
Rubber Levelers
1 888 772 0000
mid to low-frequency output—enough to reproduce the deepest male voices
effortlessly and naturally: The unobtrusive Image C40, standing just 6-1/2-
inches, and the slightly larger Image C60, ideal for bigger rooms or systems. In
sharp contrast to nearly all other center-channel speakers. The Image family's
model S50 surround speaker (rear channel) is just as carefully designed for its
role, with substantial dynamics and uncommonly wide ambient dispersion.
One final thought: Talk is cheap—real cheap, in the highly competitive world
of hi-fi loudspeakers. So visit a PSB audio specialist to hear what we mean.
Five minutes spent listening, even to the modest PSB Image B15s, will say
more than a thousand words—including the ones you just read.
Image T55 Image T65
Tower Tower
32-23,000Hz 30-23,000Hz
45-20,000Hz 42-20,000Hz
45-10,000Hz 42-10,000Hz
30Hz 25Hz
90dB 92dB
93dB 94dB
6 Ohms 6 Ohms
4 Ohms 4 Ohms
10-175 Watts 10-200 Watts
125 Watts 150 Watts
1" (25mm) 1" (25mm)
Aluminium Dome Aluminium Dome
with Ferrofluid with Ferrofluid
2 x 6 1/2" (165mm) 3 x 6 1/2" (165mm)
Injection Molded Injection Molded
Metalized- Metalized-
Polypropylene Cone Polypropylene Cone
Rubber Surround Rubber Surround
2,500Hz, B3; 500Hz, LR4 2,500Hz, B3; 500Hz, LR4
1.56 cu ft (43.7 liter) 2.35 cu ft (65.8 liter)
Bass Reflex Bass Reflex
2 x 2" Front Port 3 x 2" Front Port
Video Shielded Video Shielded
8 1/2 x 36 x 14 15/16" 8 1/2 x 39 x 20"
203 x 914 x 379mm 203 x 965 x 508mm
Feet add 1" (25mm) Feet add 1" (25mm)
42 lb (19.1kg)/each 49 lb (22.3kg)/each
51 lb (23.2kg)/each 60 lb (27.3kg)/each
Black Ash, Maple Black Ash, Maple
or Sienna or Sienna
Dual, 5-way Gold-plated Dual, 5-way Gold-plated
Binding Posts Binding Posts
Bi-wireable/Bi-ampable Bi-wireable/Bi-ampable
Feet/stabilizers with Feet/stabilizers with
Adjustable Spikes and Adjustable Spikes and
Rubber Levelers Rubber Levelers
© 2006 PSB Speakers, a division of Lenbrook Industries Limited. PSB is a registered trademark of Lenbrook Industries Limited.
No part of this publication may be reproduced, stored or transmitted in any form whatsoever without the written permission of PSB Speakers.
Image C40 Image C60
Center Center
50-23,000Hz 40-23,000Hz
65-20,000Hz 50-20,000Hz
65-10,000Hz 50-10,000Hz
45Hz 35Hz
90dB 90dB
92dB 92dB
6 Ohms 8 Ohms
4 Ohms 6 Ohms
10-150 Watts 10-175 Watts
120 Watts 150 Watts
1" (25mm) 1" (25mm)
Aluminium Dome Aluminium Dome
with Ferrofluid with Ferrofluid
2 x 5 1/4" (133mm) 2 x 6 1/2" (165mm)
Injection Molded Injection Molded
Metalized- Metalized-
Polypropylene Cone Polypropylene Cone
Rubber Surround Rubber Surround
2,200Hz, B3 2,500Hz, B3
0.59 cu ft (16.5 liter) 0.88 cu ft (24.6 liter)
Bass Reflex Bass Reflex
2 x 2" Front Port 2 x 2" Front Port
Video Shielded Video Shielded
23 3/8 x 7 x 11 5/8" 27 3/8 x 8 1/2 x 11 15/16"
581 x 165 x 295mm 683 x 203 x 303mm
23 lb (10.5kg)/each 25 lb (11.4kg)/each
27 lb (12.3kg)/each 33 lb (15.0kg)/each
Black Ash, Maple Black Ash, Maple
or Sienna or Sienna
5-way Gold-plated 5-way Gold-plated
Binding Posts Binding Posts
Clear Bumpers Clear Bumpers
PSB Speakers reserves the right to change specifications or features without notice.
Image S50
Surround
65-23,000Hz
65-10,000Hz
48Hz
91dB
93dB
6 Ohms
4 Ohms
10-200 Watts
150 Watts
2 x 1" (25mm)
Aluminium Dome
with Ferrofluid
2 x 5 1/4" (133mm)
Injection Molded
Metalized-
Polypropylene Cone
Rubber Surround
2,500Hz, B3
0.33 cu ft (9 liter)
Bipole
Acoustic Suspension
Video Shielded
12 3/4 x 13 x 7 3/8"
324 x 330 x 187mm
18 lb (4.5kg)/pair
40 lb (18.2kg)/pair
Black or
White Textured
5-way Gold-plated
Binding Posts
Wall Mounting Clips
