Revolution Spas Atlantis Owner's Manual

Rotationally-molded spa
Hide thumbs
Table of Contents

Advertisement

Quick Links

REVOLUTION
SPAS
Rotationally-Molded Spa Owner's Manual
Customer Service 1•800•787•6649
READ AND FOLLOW ALL INSTRUCTIONS
Unit is IPX5 Compliant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Atlantis and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Revolution Spas Atlantis

  • Page 1 REVOLUTION SPAS Rotationally-Molded Spa Owner’s Manual Customer Service 1•800•787•6649 READ AND FOLLOW ALL INSTRUCTIONS Unit is IPX5 Compliant...
  • Page 2 Congratulations on your purchase! Your new spa will bring you years of enjoyment and relaxation. Please take the time to familiarize yourself with the safety precautions, operational procedures, routine water maintenance and cleaning so that your spa will provide a healthy environment for all your bathers.

  • Page 3: Table Of Contents

    Contents Important Safety Instructions and Warnings ..........4 Prepare for Your New Spa Plan the Best Location .

  • Page 4: Important Safety Instructions And Warnings

    Important Safety Instructions and Warnings READ AND FOLLOW ALL INSTRUCTIONS To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. Warning: Children should not use Warning: Do not use drugs or alcohol spas or hot tubs without adult supervi- before or during the use of a spa or sion.
  • Page 5 Important Safety Instructions and Warnings READ AND FOLLOW ALL INSTRUCTIONS To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. Warning: Prolonged immersion in a HYPERTHERMIA spa or hot tub may be injurious to your Hyperthermia occurs when the inter- health.

  • Page 6: Prepare For Your New Spa

    Prepare for Your New Spa Prepare for Your New Spa Consider Spa Use Most cities and counties require permits for exte- How you intend to use your spa will help you rior construction and electrical circuits. In addition, determine where you should position it. For exam- some communities have codes requiring residential ple, will you use your spa for recreational or thera- barriers such as fencing and/or self-closing gates on...

  • Page 7: Identifying The Spa's Electrical Components

    Prepare for Your New Spa Identifying the Spa’s Electrical Components Locate Electrical Pack Part Number and Model Number on the metal plate mounted on out- side of spa panel. Balboa Pack Usage Description and Settings Suggested Wire(s) GFCI Size* Required Model No.
  • Page 8 Prepare for Your New Spa 120 Volt Electrical • Receptacle shall be located not less than 5 feet Installation (1.5 m) from and not exceeding 10 feet (3.0 m) from the inside wall of the spa. (NEC 680.43(A)) • Do not bury the power cord. If your cord be- (North America 60hZ) comes damaged, replace it before next usage.

  • Page 9: 120V To 240V Conversion

    Prepare for Your New Spa 120V to 240 V The steps to converting your spa from 120V Conversion to 240V operation are shown below and must be completed by a licensed electrician. (North America 60hZ) Power supply installation must include a properly rated GFCI circuit breaker.
  • Page 10 Prepare for Your New Spa Step 3. Turn Dipswitch #10 off (down). All other dipswitches should remain the same. Your 240V wiring should look like this. See Wiring Diagrams on pages 12-13 for further information. If wiring appears differently, DO NOT power your spa! Consult a certified electrician.

  • Page 11: Electrical Installation (240 V 60Hz North America)

    Prepare for Your New Spa 240 Volt Electrical GFCI and Wiring Requirements Installation • The power supplied to the spa must be on a dedi- cated GFCI protected circuit as required by ANSI/NFPA 70 with no other appliances or lights (North America 60hZ) sharing the power.

  • Page 12: Gfci Wiring Diagram (240 V 60Hz North America)

    Prepare for Your New Spa GFCI Wiring Diagram (North America 240V 60hZ) WARNING: The electrical circuit must be installed by an electrical con- House Breaker Box tractor and approved by a local building or electrical inspec- tor. Failure to comply with state and local codes may result in fire or OFF OFF OFF OFF OFF personal injury and will be the sole responsibility of the spa owner.

  • Page 13: Gfci Wiring Diagram (230 V 50Hz Europe)

    Prepare for Your New Spa GFCI Wiring Diagram (European 230V 50hZ) Systems with PCB Rev B Only For Certified Electrical Personnel reference ONLY! Note: A residual current device with a tripping current rated not more than 30 mA has to be installed in addition to local requirement.

  • Page 14: Operating Your Spa

    Operate Your Spa Filling and Starting 1. Place spa on an approved surface and have it properly wired by a licensed electrician. 2. Remove exterior spa panel near Service Access Side label by inserting a flathead 5. Remove the filter (and weir and basket, if screwdriver at bottom edge of equipped) from filter chamber.

  • Page 15: Priming The Pump

    Operate Your Spa Priming the Pump To remove a large air lock within the pump: 1. Turn off power at the breaker. Sometimes air can become trapped in the pump while filling the spa. You will know this has happened 2.

  • Page 16: Topside Control Panels

    Operate Your Spa Topside Control Panels dard Mode. The temperature is constantly displayed when in Standard Mode. This is the best mode to use during COLD weather. System Settings Economy Mode heats the spa to the set temper- When your spa is first actuated, it will go into Prim- ature only during filter cycles or if the ing mode, indicated by “Pr.”...

  • Page 17: Operational And Energy Tips

    Operate Your Spa ately back on turned off and on again. 1. Fading: The lights will cycle through all the 1. Savings – if your electric provider offers dif- colors in this order: White, Cyan, Magenta, Blue, ferent rate per KWH (peak / off-peak) then Chartreuse, Green, Red you will want your filter time to take place 2.

  • Page 18: Personal Settings; Adjusting Jets, Air Controls, Diverters, Waterfalls

    Operate Your Spa should overlap the usage time by a half • Covering your spa helps prevent children from hour. This will have spa temperature closest drowning in the spa. See the photo for instructions to the desired temperature. on mounting the locks and how to lock and unlock a.

  • Page 19: Maintaining Spa Water Quality

    Operate Your Spa Water Columns too high and may be difficult to bring down. High TA (if equipped) can be corrected by adding pH decreaser. IMPORTANT! When spa session is over, When the TA is balanced, it normally remains and before cover is closed, stable, although adding water with high or low these water features alkalinity will raise or lower the TA level.

  • Page 20: Filter Cleaning

    Maintaining Spa Water Quality Ozone If Using Bromine as a Sanitizer Bromine is a very effective sanitizer that produces Ozone is a natural purifier. Chemically known as low chemical odors. Unlike chlorine, it can break O3, it is produced from simple oxygen molecules in down bacteria and other impurities to a safe level our atmosphere.

  • Page 21: Vacation Care

    Maintaining Spa Water Quality Vacation Care move surface debris, your filter should be deep cleaned periodically to dissolve scale and particles that get lodged deep within the filter fibers and im- You can leave your spa unattended for up to two pede the filtration process.

  • Page 22: Draining Your Spa

    Maintaining Spa Water Quality/Cleaning and Care Draining Your Spa ments on this surface as they may scratch it. Small scratches can be removed by buffing lightly with a Your spa should be drained every 3-4 months, and clean cloth and using either an automotive polishing refilled with fresh tap water.

  • Page 23: Winterizing

    Winterizing and De-Winterizing Your Spa Winterizing Important: Damage caused by improper winter- izing is not covered under the manufacturer’s warranty. If you have any questions, please call Technical Support at 1-800-787-6649. You may also wish to contact a professional to perform FIGURE 1 FIGURE 2 these services for you.

  • Page 24: Maintenance Schedule

    Maintenance Schedule Maintenance Schedule Each time you refill the spa Every 3-4 months • Follow the Filling and Starting procedure, • Drain and clean your spa with a sections 7-10 on page 14. non-abrasive cleaner. • Follow the Filling and Starting procedure, Prior to each use sections 7-10 on page 14.

  • Page 25: Water Quality Problems

    Troubleshooting Water Quality Problems Problem Probable Causes Possible Solutions Water is cloudy • Dirty filter • Clean the filter • Inadequate or improper sanitizing • Run jet pumps and clean filter • Oils, lotions, organic matter • Add sanitizer • Old water •...

  • Page 26: Operational Problems

    Troubleshooting Operations Symptom Possible Cause(s) Possible Solution(s) POWER System does not work Power is turned off Reset spa Control pad and spa No electrical power to spa Turn on or reset the GFCI circuit breaker. equipment do not operate If this does not solve the problem, have a qualified electrician check the electrical service.
  • Page 27 Troubleshooting Operations Symptom Possible Cause(s) Possible Solution(s) WATER Water is not clean For all water clarity problems, see page 26. High water consumption Very high evaporation due to air valves Shut off air valves and refill as necessary being open Low water stream from the jets Running in FILTER mode - slow speed Select high speed jets Blocked wall suctions or skimmer...
  • Page 28 Troubleshooting Operations Symptom Possible Cause(s) Possible Solution(s) PUMP Pump runs constantly – will Problem with circuit board Contact customer service not shut off Noisy pump Water level is too low Add water to normal level Blocked wall suctions or skimmer Clean the wall suction/skimmer Damaged or worn-out motor block Contact customer service...

  • Page 29: Control Pack Codes

    Control Pack Codes VS and GS SERIES Control Pack Codes STANDARD MODE ECONOMY MODE SLEEP MODE Problem: No message on display. Power has been cut off to the spa. Solution: The control panel will be disabled until power returns. Spa settings will be preserved until next power up.
  • Page 30 Control Pack Codes VS and GS SERIES Control Pack Codes cont. Problem: Possible inadequate water, poor flow, or air bubbles in detected in the heater. Spa is shut down for 15 minutes. Solution: Check water level in spa. Refill if necessary. If water level is okay, make sure the pumps have been primed.

  • Page 31: Product Registration

    Register Your Product Product Registration Register your spa online! Go to strongspas.com and click on Register. It is important that you register your product as soon as possible. IMPORTANT: Warranty is void if the spa is moved to any location that is not the original ‘Ship To’ address. Locating the product serial number The serial number of your spa is located on a metal plate attached to exterior of the spa.
  • Page 32 For customer service, please call 1-800-787-6649 READ AND FOLLOW ALL INSTRUCTIONS To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. SAVE THESE INSTRUCTIONS 12 29 16...
