Summary of Contents for Sigrand IPhouse-15E/W
Page 1
The IPhouse-15 is controlled by the Command Line Interface (CLI). The IPhouse-15 can be supplied in several configurations: IPhouse-15E/W – PoE, White LEDs • IPhouse-15E/IR – PoE, Infrared LEDs •...
Page 2
Table 3. Mechanical Characteristics Parameter Value Units Housing Material Aluminium Dimensions 396 x 137 x 102 Camera Space 258 x 81 x 75 Weight (without bracket) 1400 Weight (with bracket) 1800 Protection Rating IP66 Table 4. Operating Conditions Parameter Value Units Ambient Temperature –40 to +40...
Page 3
4.1.2 Unscrew the temporary screw and remove the bracket assembly. 4.1.3 Unscrew the thumbscrews and remove the support. 4.1.4 Attach the support to the camera by means of the nut and the screw [1]. 4.1.5 Insert the camera into the housing and fix it by the thumbscrews. 4.2 Serial Port Connection 4.2.1 If the camera has a serial port, connect the housing's console port to the camera's serial port by the 4-wire flat cable.
Page 4
4.3 LAN Cable Entrance The housing has two sealed LAN cable entrance points. Depending of the configuration, one or two entrances can be used. Two entrances are used in the PoE chain configuration, one for LAN IN cable and the other for LAN OUT cable.
Page 5
4.6.1 Close the housing and lock the fasteners. 4.6.2 Attach the bracket assembly to the wall of the building. 4.6.3 Unscrew two screws from the bottom of the housing. 4.6.4 Mount the housing on the bracket and fix it by two screws. 5.
Page 6
Press Enter. The IPhouse-15 will show the command prompt : (the colon sign). Issue the info command. The IPhouse-15 should answer as follows: :info Sigrand IPhouse-15 Light Camera Housing V.2.0 5.3 Accessing CLI through HyperTerminal 5.3.1 Attach BLS-4 connector of the IPhouse-15 Console Cable (Annex A) to the console port of the IPhouse15 device (XP7).
Page 7
5.5.1 Reference Commands – info and help The info command displays the name of the device and the version of the firmware. :info Sigrand IPhouse-15 Light Camera Housing V.2.0 The help command displays the list of available commands. :help HELP [LED | TH | PH | FAN | CAM] - detailed help...
Page 8
To get the detailed help for a specific command, issue the help command with the name of the command as an argument. For example, the help led command displays the help text of the led command. :help led LED - LED status LED [ON|OFF|AUTO] - turn LED On, Off, or Auto mode LED POWER - LED power in % LED LXON - turn-on illuminance...
Page 9
Note: The upper threshold should be higher than the lower one. Typically the upper threshold is several times higher. It is required to prevent LEDs flashing when the actual illuminance is near the threshold. The commands led lxon and led lxoff display the current settings for the illuminance thresholds. :led lxon 10 lx :led lxoff...
Page 10
The th power command displays the current setting of the heating power. :th power Note: the same LEDs are used for lighting and for heating, but the power assigned for heating may differ from the power assigned for lighting. 5.5.3.4 Setting Temperature Thresholds If the thermostat is enabled, the LEDs are turned on when the internal temperature falls down to the lower threshold, and are turned off when the internal temperature rises up to the upper threshold.
Page 11
The ph ton N command sets the target temperature for the preheat. The N is a signed integer value in °C. :ph ton 0 The ph ton command displays the current settings of the target temperature. :ph ton +0'C 5.5.4.5 Saving Preheat Settings The ph save command saves the current preheat settings to the EEPROM.
Page 12
The reboot command causes the restart of the device. The camera is restarted as well. :reboot Rebooting... Sigrand IPhouse-15 Light Camera Housing V.2.0 Ready! Note: The SSH connection to the camera will be lost. The new connection is not possible until the camera's boot process completes.
Page 13
Problem: The settings changed to the previous values after power off. Solution: After changing the settings, do not forget to issue the appropriate save command (led save, th save, etc) to store the settings to the EEPROM. Note: some settings, such as thresholds, are stored to the EEPROM immediately. 5.6.2 Changing Settings Causes Reboot Problem: The device restarts upon changing some settings, and the SSH connection is lost.
