Electronic Flash Diagram
1. Wide angle diffuser
2. Flash bounce card
3. Flash head
4. Wireless sensor
5. External power
source socket port
6. PC synchronous
socket port
7. Lock ring
8. Hot shoe foot
14
15
16
17
6
1
3
4
7
9.
9
10.
10
11.
12.
11
13.
14.
12
15.
16.
13
17.
18.
18
2
MODE indicator (M, S1, S2)
Battery cover
Power indicator
TEST button
Flash MODE button
Output level indicator
Flash power level – button
Flash power level + button
Power switch

Hot shoe stand
