INTRODUCTION
Thanks for purchasing our Grower's Edge
Wireless Hygrometer- Thermometer .
Enclosed with this package includes one main unit and
one remote temperature and humidity sensor.
The main unit has an extra-large multifunction 2-line
LCD that shows recordings for indoor and outdoor
temperature, humidity, maximum and minimum
recordings and trend indicators.
The unit supports up to three 433MHz remote
Hygrometer -Thermometer sensors. Additional sensors can
be purchased separately.
In addition to monitoring maximum and minimum
Temperature And Humidity readings, the unit also has an
alarm that can be set to activate once readings exceed a
given variance.
No wire installation is required between the main and
remote units as the Wireless Hygrometer -Thermometer
operates at 433MHz frequency.
Wireless Hygro-Thermometer
1
2
4
5
1． Temperature trend
2． Sensor reception icon
3． Battery low icon
4． Humidity comfort zone
5． Humidity trend
6． Hi/Lo temperature alarm
7． Maximum and minimum temperature icon
8． Temperature display area
9． Hi/Lo humidity alarm
10．Maximum and minimum humidity icon
11．
H umidity display area.
1
Part #716555
USER MANUAL
OVERVIEW
FRONT VIEW OF MAIN UNIT
3
6
7
8
9
10
11
Advertisement
Table of Contents
Summary of Contents for Grower's Edge 716555
- Page 1 Wireless Hygro-Thermometer Part #716555 USER MANUAL INTRODUCTION OVERVIEW FRONT VIEW OF MAIN UNIT Thanks for purchasing our Grower’s Edge Wireless Hygrometer- Thermometer . Enclosed with this package includes one main unit and one remote temperature and humidity sensor.
-
Page 2: Remote Sensor
BACK VIEW OF MAIN UNIT REMOTE SENSOR 1. LCD display 2. LED status indicator 1. HI/LO: Change alarm setting, enable/disable 2. Reset 3. MEN/CLR: View maximum and minimum temperat- ure and humidity. Clear the maximum and minimum temperature and humidity. - Page 3 HOW TO CHECK REMOTE AND GETTING STARTED INDOORS TEMPERATURES Display of readings from a remote sensor or the main unit is a Once batteries are placed in a given remote sensor unit, it will start one – step procedure. The remote sensor channel or the main transmitting information at 40-second intervals.
-
Page 4: Temperature And Humidity
MAXIMUM AND MINIMUM TEMPERATURE AND HUMIDITY Upper and lower temperature and humidity limits for channel-1 can The maximum and minimum recorded temperature and be set so that an alarm activates when the limits are exceeded. humidity readings will automatically be stored in the The high and low temperature and humidity displays are selected by memory. -
Page 5: Specifications
THE RESET BUTTON Signals from other household devices, such as doorbells, home This button is only used when the unit is operating in an security systems and entry controls, may interfere with those of this The main unit has a retractabletable stand, which when flipped open, unfavorable way or malfunctioning.
