Wireless laser mouse
User's Manual
1.
Contents
2.4GHz Laser Mouse
Micro Dongle
Two AAA Batteries
Mouse Driver CD
User's Manual
2.
The RF mouse overview
(1)
Micro Dongle (7) Connect button
(2)
Left Key
(3)
Right Key
(4)
Roller Key
(5)
Backward (B4)
(6)
Forward (B5)
3.
Hardware Installation
Installing Batteries:
Remove the battery cover from the bottom case and put 2 AAA batteries into battery compartment.
Pairing the Micro Dongle (Receiver) to the Computer
Plug the Micro dongle into any available USB port on your computer and an indication of identifying new
USB device will appear on the Screen
device will appear. The user can now start to enjoy the RF mouse. Note: If the Mouse is not first time use and had
been "Turn Off" the power under different Resolution, when you "Turn ON" the power again, then it will appear
the last memory resolution LED light.
5 seconds
Bottom Green LED "On"
4.
Driver Installation (Notice: The driver supports Windows 2000 XP and Vista)
Installation of driver CD will be done automatically once the CD is plugged in and recognized. In case it doesn't
work, please try steps below:
Insert the driver CD
(8) Power ON/OFF
(9) Laser LED
●Pairing the receiver and mouse
Turn on the mouse power, keep the mouse close to the receiver and
wait for at least 5 seconds. For the 1
mouse turns on when pairing begins. After pairing successful, the
Green Led turns off automatically and an indication of new input
"Off"
st
pairing, the Green LED of

Advertisement

   Related Manuals for Fujitsu KM010

   Summary of Contents for Fujitsu KM010

  • Page 1

    Wireless laser mouse User’s Manual Contents 2.4GHz Laser Mouse Micro Dongle Two AAA Batteries Mouse Driver CD User’s Manual The RF mouse overview Micro Dongle (7) Connect button Left Key (8) Power ON/OFF Right Key (9) Laser LED Roller Key Backward (B4) Forward (B5) Hardware Installation...

  • Page 2

    Double click “Setup.exe” Follow set-up instructions: The InstallShield Wizard will appear on your computer, click “Next”. Select folder where to save the files and click “Next”. Setup Status Click Finish to complete setup. A mouse icon will appear on the task bar. Battery Notice When Red LED indicator appears, it means battery low.

  • Page 3

    Press Right key and Wheel key at the same time for 3 seconds to change the DPI setting: Green Led – 800dpi (Default) Amber Led – 1200dpi Red Led – 1600dpi Green Amber Specifications 〔Mouse〕 Weight : 86.5g - Dimensions : 102.5(L)mm x 69.3(W)mm x 40.2(H)mm - Power: Power rating 2.4V~3.2V DC;...

  • Page 4

    This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. 2008/12/08 Fujitsu Rev: B CAUTION LASER RADIATION. DO NOT STARE INTO THE BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS. CLASS I LASER PRODUCT.
