  • Page 1 Poolsmart Plus Touchscreen Heating Controller Installation & Operating Manual...
  • Page 2: Important Notes

    Important Notes Congratulations on purchasing the PoolSmart Plus touchscreen heating controller, manufactured in England to the highest standards. To ensure your new product will give years of trouble free service please carefully read the following instructions. Incorrect installation will affect your warranty. Do not discard this manual, please retain for future reference.
  • Page 3: Installation

    Installation Screw mount the PoolSmart Plus to a suitable wall in a dry weather proof location out of direct sunlight, ensuring that it is sited no more than 3 metres from the swimming pool filtration pipe work and upstream i.e: before the heating appliance.
  • Page 4: Electrical Connection

    T-Piece must point in the direction of flow. Electrical Connection The PoolSmart Plus must be installed in accordance with the Country / regional requirements and regulations. In any event the work must be carried out by a qualified electrician who will provide a certificate of conformity upon completion of the work.
  • Page 5: Wiring Diagram

    Wiring Diagram www.elecro.co.uk...
  • Page 6 Digital Touchscreen Controller Overview The Touchscreen digital controller has been pre-programmed with all the necessary parameters to ensure reliable service & operation. Below is an overview indicating the controller button keys and graphical symbols. www.elecro.co.uk...
  • Page 7 Operating Instructions On initial power up of the controller the digital display will be illuminated. The heating device will only be switched ‘On’ when the following criteria are met i.e: • Water circulating pump is ‘On’ delivering in excess of 4,000 litres per hour (4m³/h) •...
  • Page 8: Operating Modes

    Time Switching Delay To prevent overheating of the switch components within the heating device caused by frequent on/ off switching (cycling) the controller has been pre-programmed with a time delay function. When time switching delay is activated the message display will show ‘HEATER DELAY’...
  • Page 9: Installation Mode

    Installation Mode When entering Installation mode the heating device and pump will immediately be turned off (if they are on) and will not be permitted to be turned on while the controller remains in any of the setup menus. On exiting the ‘Installation’...
  • Page 10 Language Setup continued Touch the ‘UP’ / ‘DOWN’ button keys until the desired language is displayed then touch the ‘O.K’ button key to select www.elecro.co.uk...
  • Page 11 UNITS Setup After selecting ‘O.K.’ For the language setup the display will then revert back to show ‘LANGUAGE’ touch the ‘UP’ / ‘DOWN’ button keys again to display the next option which is ‘UNITS’ touch the ‘O.K.’ Button key to select, the display will show ‘UNITS’...
  • Page 12 CLOCK Setup Touch the ‘UP’ / ‘DOWN’ button keys to display the next option which is ‘CLOCK’ touch the ‘O.K.’ Button key to select, the display will show ‘SET TIME’ and the current clock time, touch the ‘UP’ / ‘DOWN’ button keys to change the clock time, touch the ‘O.K.’...
  • Page 13 TIMER Setup After selecting ‘O.K.’ for the ‘CLOCK’ setup the display will then revert back to show ‘CLOCK’, touch the ‘UP’ / ‘DOWN’ button keys until ‘TIMER’ is displayed, touch the O.K. Button key to select, ‘TIMER 1’ will be displayed, touch the O.K.
  • Page 14 Probe Calibration Setup After selecting ‘EXIT’ for the timer setup the display will then show ‘PROBE CAL’ touch the ‘O.K.’ Button key to select, touch the ‘UP’ / ‘DOWN’ button keys to increase or decrease the temperature calibration adjustment, touch the ‘O.K.’...
  • Page 15 MODBUS Setup Refer to your BMS Management System manual for the required settings. SET BAUD Touch the ‘O.K.’ Button key to select, ‘MODBUS SET BAUD’ will be displayed, touch the ‘O.K.’ Button key to select and ‘SET BAUD 19200 Baud’ will be displayed, touch the ‘UP’ / ‘DOWN’ button keys for the other option ‘...
  • Page 16 MODBUS Setup continued Set Parity Touch the ‘OK’ button key to select ‘MODBUS SET PARITY’ and ‘PARITY ODD’ will be displayed Touch the ‘UP’ / ‘DOWN’ button keys to change ‘PARITY ODD’ to ‘PARITY EVEN’ or ‘PARITY NONE’ touch the ‘O.K’ button key to select the required setting, the display will now revert back to show ‘MODBUS SET PARITY’...
  • Page 17: Standby Operating Mode

    Standby Operating Mode When in Standby mode the controller will display the text ‘STANDBY’ , Clock time and the Standby button key (as below). When in this mode the internal clock continues to run but there is no other functionality apart from the Standby button key. www.elecro.co.uk...
  • Page 18: Normal Operating Mode

    Normal Operating Mode Under normal conditions when the controller is connected and ‘On’ and flow has been detected by the flow switch the controller display will be as shown below indicating the following information: 1) ‘Normal’ and ‘Time’ 2) Actual water temperature 3) Required temperature 4) If the Flow switch does not detect sufficient flow the message ‘NO FLOW’...
  • Page 19: Timer Mode

    Timer Mode To activate the Timer mode, touch the ‘M’ button key until the ‘TIMER’ symbol is displayed (see below) In this mode the controller will only heat during a timed on period and when receiving sufficient flow. If no or insufficient flow is being recieved no heating will take place. When in a timed off period no heating will take place.
  • Page 20 Priority of Heating Mode To activate the ‘Priority of Heating’ mode touch the ‘MODE’ button key until the ‘PRIORITY’ symbol is displayed, the message ‘FLOW STABILISING’ will be displayed, after two minutes the display will change to show ‘SAMPLING’ and after a further two minutes the display will change back ‘PRIORITY’...
  • Page 21 reached the controller will switch the heating appliance off, followed by the filtration pump. After one hour a new water temperature sample will be taken, if the sampled water is at or above the required temperature no heating will take place and the controller will switch the circulation pump off, then one hour later take a new temperature sample.
  • Page 22: Troubleshooting

    Trouble shooting Heating Device will not switch on In most cases this will be the result of one of the following not being met: Possible Cause 1.) The required temperature has been reached. To confirm the controller is requesting the heating device to switch on check that the required temperature is at least 0.6⁰C greater than the current water temperature and that the red thermometer in the display is ‘animated’...
  • Page 23: Rohs Compliance Statement

    Guarantee Your PoolSmart Plus is guaranteed for 3 years* from the date of purchase against faulty workmanship and materials. *regional variations apply The manufacturer will replace or repair, at it’s discretion, any faulty units or components returned to the company for inspection.
  • Page 24 11 Gunnels Wood Park Stevenage Hertfordshire SG1 2BH United Kingdom | f: | e: +44 (0) 1438 749 474 +44 (0) 1438 361 329 sales@elecro.co.uk www.elecro.co.uk © Copyright 2017 Z-INS-PSPC-50/1.5 www.elecro.co.uk...
