Summary of Contents for JUDDER MWFX
- Page 1 JUDDER IN STRUC TION S...
- Page 2 Thank you for purchasing the larger version of the Judder pedal. This version is an enhanced copy of the mini pedal from 2009. The effect was designed to sample and repeat constantly renewable sound loops at the press of a button. To do this, the input is constantly being recorded in the background, like a tape loop.
- Page 3 Controls 1/4 BPM Varies the length of the sample being taken. The scale shows a BPM reference, this number is a 1/4 division of the actual BPM (4 repeats per beat). HOLD Controls the feedback of the repeats. At 5 it achieves constant hold.
- Page 4 Switches EFFECT In central position (‘JUDDER’ mode), no more sound is added to the sample. In LAYER the sample can be layered over. STUTTER mode acts as cut or boost (altered by MIX control). MOD. Modulates the sample length and pitch using the LFO or ENV.
-
Page 5: Tap Footswitch
Judder/Stutter Dry Mix Layer Dry Mix TAP FOOTSWITCH Momentary switch that turns effect on and off, depending on the status of the LOCK footswitch. LOCK FOOTSWITCH Latching footswitch that can be used to hold the effect on and invert the direction of the TAP switch. - Page 6 T ECHNICAL I NFORMATION Repeat Length: 27ms to 300ms/27ms to 10secs Input Impedance: 1m Ω Output Impedance: 100 Ω Current Consumption: 35mA SAFET Y GUI DEL INES This pedal should be used with a 9v DC power adaptor dedicated for use with guitar effects. It uses a centre negative polarity 2.1mm socket (see diagram below), standard to 9v guitar pedals.
- Page 7 Repairs outside of this time may incur a small fee but in most cases it’s still free. This guarantee is not extended to damaged, opened, modified or improperly used items. CONTACT DETAILS info@mwfx.co.uk www.mwfx.co.uk All circuitry, logo, names and design ©2016 MWFX...
