ULTRASONIC THICKNESS GAGE
MODEL NO. 15947 & 15949
OPERATION MANUAL
250 Gibbs Road • Islandia, NY 11749
Tel: (631) 582-8440 • Fax: (631) 582-8487
E-Mail: sales@flexbar.com
www.flexbar.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 15947 and is the answer not in the manual?

Questions and answers

Summary of Contents for flexbar 15947

  • Page 1 ULTRASONIC THICKNESS GAGE MODEL NO. 15947 & 15949 OPERATION MANUAL 250 Gibbs Road • Islandia, NY 11749 Tel: (631) 582-8440 • Fax: (631) 582-8487 E-Mail: sales@flexbar.com www.flexbar.com...

  • Page 2: Table Of Contents

    INDEX 1) GENERAL 1.1) APPLICATIONS 1.2) BASIC WORKING PRINCIPLE 2) SPECIFICATIONS 3) DIAGRAM Model#15947 & 15949 4) MAIN FUNCTIONS 4.1) PREPARING FOR MEASUREMENT 5) SETTING PARAMETERS 5.1) Velocity a) Velocity Setting b) Velocity Measuring 5.2) Probe selection 5.3) Resolution 6) TESTING PROCEDURE...

  • Page 3: Applications

    1. GENERAL 1.1) APPLICATIONS The Flexbar Ultrasonic Thickness Gage, Model No. 15947 & 15949 are designed for measuring the thickness of metals, plastics, ceramics, glass and other ultrasonic wave conducting materials with two parallel surfaces (top & bottom). The 15947/15949 can be used in industrial applications to perform precise measurements on various kinds of materials, parts and components.
  • Page 4 UTG- Model 15947/15949 1. LCD Screen 2. Calibration Block 3. Increase/Change Setting/Backlight 4. Decrease/Change Setting/AutoCalibrat 5. Power On/Off 6. Menu Program/Save 7. Probe Ports...
  • Page 5 UTG- Model 15947/15949 1. LCD Screen 2. Test Shim 3. Increase/Change Setting/Backlight 4. Decrease/Change Setting/Auto Calibration 5. Power On/Off 6. Menu Program/Save 7. Probe Ports 8. Memory Recall (15947/15949 Only) 9. Store Data (15947/15949 Only)
  • Page 6 MODEL 15947/15949 1. LCD Screen 2. Calibration Pad 3. Increase/Change Setting/Backlight 4. Decrease/Change Setting/Auto Calibration 5. Power On/Off 6. Menu Program/Save 7. Probe Port 8. Memory Recall (15947/15949 Only) 9. Store Data 10. RS-232/Printer Port...

  • Page 7: Main Functions

    (See Below) 0.000IN 0.00mm VEL:0.230 PT-12 VEL:5920m/s PT-12 5) SETTING PARAMETERS A) Press the button. The screen will display as follows: Model# 15947 Model# 15949 1. Measurement 1. Measurement 2. Velocity 2. Velocity 3. Probe Setting 3. Probe Setting 4.

  • Page 8: Velocity

    5.1) Velocity Press the button once to select 2. Velocity. Press the button to enter into the velocity parameter. The screen will display as follows: 1. Vel. Setting 2. Vel. Measuring a) Vel. Setting Press the button to enter VEL SETTING. Use the button to move the cursor from column to column.
  • Page 9 Model# 15949 has a memory capacity of 2000 measurements. These can be stored in • any group from 0000 to 1999. Model# 15947 has a memory capacity of 4000 measurements. These can be stored in • any group from 0000 to 3999.
  • Page 10 5.6 LIMITATION (Model# 15947 only) Press the button and return to the main menu. Scroll down until you see the 6. LIMITATION. Press the button to enter the limitation parameter. Set your lower limit by pressing the button to advance the numerals. Press the button to change your column.

  • Page 11: Testing Procedure

    5.8 PRINTING (Model# 15947 only) If you want to print the stored values, you must first determine the initial location number and the last location number to be printed. • Press the button to enter main menu. Scroll down to the 8.PRINT.

  • Page 12: Measuring Thickness

    * AUTOMATIC SHUT-OFF If the 15947/15949 remains idle for 2 minutes, the unit will automatically shut off. * PRECAUTIONS The surface of the probe is made of Polypropylene resin and is very sensitive to heavy scratches and rough surfaces.
  • Page 13 Inch to Millimeter Conversion Table Decimals to Millimeters Fractions to Decimals to Millimeters Decimal Decimal Fraction Decimal Fraction Decimal 0.001 0.0254 0.500 12.7000 1/64 0.0156 0.3969 33/64 0.5156 13.0969 0.002 0.0508 0.510 12.9540 1/32 0.0312 0.7938 17/32 0.5312 13.4938 0.003 0.0762 0.520 13.2080...
  • Page 14 0.450 11.4300 0.960 24.3840 15/32 0.4688 11.9062 31/32 0.9688 24.6062 0.460 11.6840 0.970 24.6380 31/64 0.4844 12.3031 63/64 0.9844 25.0031 0.470 11.9380 0.980 24.8920 0.480 12.1920 0.990 25.1460 0.490 12.4460 1.000 25.4000 0.5000 12.7000 1.0000 25.4000 Millimeter to Inch Conversion Table Decimal Decimal Decimal...
  • Page 15 0.240 6100 Tungsten 0.200 5200 Uranium 0.130 3400 Water 0.584 1480 Zinc 0.170 4200 • Note: To calibrate the 15947 or 15949 , you must set the velocity to 0.2330/5981M/S (Steel) as stated in Sect. 7 Calibration, on page 7.
