- Page 1 12 Language Talking Translator Translates and Talks over 720,000 Words Translates and Talks 39,600 Travel Phrases History and Favorite lists 8 Metric Conversions 8 Currency Conversions International clothing and shoe converter Sudoku Game Time zone in 360 cities TT-12000 C91104...
- Page 2 OPERATIONAL NOTES Thank you for your purchase of our lingo Translator. To insure trouble-free operation of your Translator, we recommend the following: The Translator should be kept in area free from extreme temperature changes, moisture and dust. This equipment is precision-built. Do not subject the translator to strong shock by striking or dropping it.
- Page 3 7. METRIC CONVERSION converts automatically 8 different types of measurement. 8. LIGHT/DARK DISPLAY allows you a choice of 16 levels either light display or dark display. 9. Read by 160 x 51 DOTS MATRIX DISPLAY. 10. AUTOMATIC POWER OFF conserves battery power allows you a choice by turning off the translator from 1 to 15 minutes.
- Page 4 Replacing the main battery: Before replacing the main battery. Turn off the machine. Slide off the battery door according the direction of the arrow indicated. The battery door is linkage with translator case. Remove the old batteries and replace 2 PCS AAA batteries (1.5 V, SUM-4, R3) in the correct polarity corresponding to the symbol indicated inside the battery compartment.
- Page 5 OVERVIEW THE TRANSLATOR...
- Page 6 NAME OF KEYS...
- Page 7 1. ON/OFF : a) Turn on & off. The translator will automatically switch off if you do not press any keys from 1 to 15 minutes . (please set up the time from 1 to 15 minutes in Set Up Mode) b) Some models have backlight which you can find icon on the On/Off button.
- Page 8 Japanese Input method. There are two input methods in Japanese. 9. 1st line speak : Speak key for language on top line of display. Press this key to hear the voice for the first language which shown on the top line of display.
- Page 9 22. Pg Up : Page UP key, to move screen to the last page. 23. Pg Dn : Page Down key, to move screen to the next page. 24. ENTER : a) Press this key to have translation in Translator mode. b) Press this key to confirm the setting in set up mode.
- Page 10 DISPLAY SYMBOLS Standard display area display the language match with the Status bar Caps Shift More keyboard with symbols : Indicate the language which you are using. The first 2 digits is for the input language; the second 2 digits is for the translation. The language number is printed on the keyboard.
- Page 11 BACKLIGHT DISPLAY The built-in backlight will enable you to read the LCD in dark. Your translator comes with a backlight feature. To switch on the backlighting, do the following: Press and hold the <ON/OFF> button for approximately 1 to 2 seconds. The lighting switches on and remains on for as long as keys are pressed.
- Page 12 The translator automatically switches off if no key is pressed for a certain period. You can select this time period from 1 minute to 15 minutes. Go to <SET UP> mode, number 3 (off time), from this mode, you can select to set your machine to have automatically switch off time of 1 minute to 15 minutes.
- Page 13 B. OTHER SETTINGS There are also following settings: KEY SOUND : You can select to have tone or without tone when you press any keys on keyboard. 1.1 Press 1 in setup mode, display shows: 1.2 Press 1 to have tone on, you will find an “ “...
- Page 14 3. OFF TIME The translator automatically switches off if no key is pressed for a certain period. You can select this time period from 1 minute to 15 minutes. In this mode, you can select to set your machine to have automatically switch off time of 1 minute to 15 minutes. 3.1 Press 3 in the setup mode, display shows: 3.2 The translator is set up to have automatic off of 5 minutes.
- Page 15 GAME - SUDOKU The purpose of the game: Fill in the grid so that every row, every column, and every 2 x 3 box contains digits from 1 to 6. Game rule: 1. The number of LCD bottom denotes the place of current box, mark “?” denotes the box is empty, mark “√” denotes your input is right. Mark “×” denotes your input is error.
- Page 16 USING THE TRANSLATOR It help you to translate 12 languages instantly. Words translation - Press ‘Words’ key, display ‘INPUT ENG:’ If you like to input other language, just press the number key, e.g. press 2 to input Spanish, press 4 to input German. Press 1 return to “Input ENG“, type in your word e.g.
- Page 17 Press Right arrow key () to see other 29 words related to CAR. Press 8 to get Chinese translation, 9 to get Japanese translation and so on. 6. If the message is too long, press “Down” () arrow key to see the whole screen. 7.
- Page 18 If you like to input other language, press ‘Words’ key and select to input other language again. 10. There is a smart system of inflective form to input the European languages. E.g. in English, when you enter “boys”, it can find the rootword “boy” and displays : Type in “more beautiful”, can display rootword “...
- Page 19 12. English to English Dictionary There is English Dictionary to help you to catch the meaning of a headword, meanwhile its Parts of Speech. a. Type in any word(s) you wish to translate, e.g. <shine>, press <ENTER> key, display flash “Found : 1”, telling you there are 1 words relating to <...
- Page 20 13. FOR THE EUROPEAN LANGUGAES HAVE THEIR ALPHABET WITH ACCENT - Simply press the original key and then European Accent key ( ), the display will show different alphabets and let you to select. NOTE : The Accent Alphabet can be formed just in their own language mode. If you press the “European”...
- Page 21 Press “European” ( ) twice, Press “European” ( ) triply, display shows: display shows: Press “European” ( ) four times, display shows: E.g. input German: Type in S, display show: Press “European” ( display shows:...
- Page 22 14. Chinese Input method: There are 2 input methods in Chinese. First is the PinYin, another is the WuBe. Press ( ) Chinese Input key to select your input method. For example you selected PinYin “拼“ input method, e.g. type ‘ai’, it will display all the characters 爱...
- Page 23 16. Korean Input method: A Korean character is group with several parts. The translator keyboard is same as the Korean PC keyboard. E.G. in English keyboard; 1. Press R, Press K, Press Enter 2. Press W, Press K, Press D, Press Enter MOST 3.
- Page 24 Phrases translation - There are 3300 phrases divided into 16 categories and 170 subjects. 16 Categories and the subjects: 1. COMMUNICATION - Phrases, Gratitude, Apology, Asking Again, Basic Question, Greetings, Saying Goodbye, Conversation, Invitation, Expressing Sympathy, Emotion, Blame, Congratulations. 2. ACCOMMODATION -Looking for a Hotel, Reservation, Checking in, Front Desk, Concierge, Room Service, Laundry, Operator, Problem, Business Centre, Checking Out, Barber/Beauty shop, Youth Hostel.
- Page 25 8. EMERGENCY - Asking for Help, Lost/Theft, Sudden Illness/Injury, Symptoms/Diseases, Hospital, Consult a Doctor, Pharmacy, Threat, Swindle, Car Accident, Fire, Beach/Pool, Natural Disaster/Terrorism, Insurance Company. 9. TELECOM/MAIL - Mailing, Telephone. 10. BUSINESS CONVERSATION - Meeting, Payment Terms, Letter of Credit (L/C), Shipment Documents, General Term of Trade, Interview.
- Page 26 Press ‘Phrases’ key, displays category : ‘COMMUNICATION’ ‘ACCOMMODATION’. You can change to other language by pressing the number key. Press “Up/Down key” () to search your category, or simply type in the first alphabet of the category, e.g. ‘B’, it goes to ‘BUSINESS CONVERSATION’. ENTER to ‘BUSINESS CONVERSATION’, you will find there are 6 subjects.
- Page 27 Quick search Phrases - Press Phrases key, display category ‘COMMNUICATION’ ‘ACCOMMODATION’. Press PHRASE SEARCH (CLEAR) key to clear screen, type in the word, e.g. ‘sympathy’, press “ENTER”, displays shows searching symbol, and goes to a subject ‘sympathy’. Press ENTER to search more phrases in this subject.
- Page 28 TO HEAR VOICE The Translator speaks 12 languages, English, Spanish, French, German, Italian, Greek, Rus- sian, Chinese, Japanese, Korean, Hebrew and Arabic. Press the “1st LINE” speak key to hear the voice for the language on the top line of display and the “2nd LINE’...
- Page 29 Press the “1st LINE” speak key, you can hear the English voice “bookshop”. Press the “ 2nd LINE” speak key, you can hear the Spanish voice “librería”. It is with the same procedure to hear the phrases. Press the “1 st LINE” speak key to hear the ENTRY LANGUAGE, the “2nd LINE”...
- Page 30 Using the FAVORITES function Under the paraphrase interface, press [ EDIT] key to copy the word you like, display shows: Press “Y” for Yes to Save or press “N” for No, display returns to the last mode. Choose the “3” on the menu to have favorites contents display: To choose a word “good”...
- Page 31 Using the HISTORY function Choose the “4” on the menu to have history of dictionary display. To choose a word “shine” and ENTER to see the content, display shows: USING THE CALCULATOR You can use the Translator to do standard arithmetic calculations, memory calculations and percent calculations.
- Page 32 USING THE CURRENCY CONVERSION The Translator can convert between 8 user-programmed currencies and your own denomination. SETTING THE CURRENCY AND EXCHANGE RATES 1.1 Enter to “CURRENCY”, display shows: 1 = CURRENCY ONE RATE = EXCHANGE RATE USD = US Dollars EUR = EURO Dollars 1.2 Press “EDIT”...
- Page 33 1.7 Press “ENTER” to confirm the currency name. 1.8 The Translator programs the following 8 currencies, you can make your own denomination according to above procedure. Use Left & Right () key to move to view other currencies. 1 = USD > EUR (Euro) 2 = USD >...
- Page 34 2.4 Type in 1000, display shows: (i.e. EUR1000=USD 1008.06451613) 2.5 To clear display for next calculation, press CE or AC. USING THE GEO-DATA GEO-DATA shows the data of 360 major cities in the world, includes: Country name, Zone, Dial Code and Volt. Enter to “GEO-DATA”, display shows: Use ...
- Page 35 Enter ”2. SEARCH”, display shows: You can type in the first letter of the Country name and then use or key to search for the Country you like and press Enter to see the detailed contents, display shows: Press key to return.
- Page 36 USING THE METRIC CONVERSION The Translator can convert one type of measurement to another. The following 8 related C(Celsius ) to o F (Fahrenheit) ,M (Metre) pairs are built-in the unit and they can be inverse : to F (Feet), CM (Centimetre) to IN (Inch), L(Litre) to GL(US Gallon), L(Litre) to BG (British Gal- lon), KB (Kilogram) to LB (Pound),G (Gram) to OZ (Ounce) and A ( Are) to AC (Acre).
- Page 37 Enter the amount, e.g. 100 F, type 100, display shows: 5. Press “Right” key () to see other conversions, and “Left” key () to return. The other types of measurement conversion are with same format as above. Press ESC ( ) to return to select conversion screen.
