Quick Start Guide
Hitex Starter Kit for ARM ®
with
MCB2100 Evaluation Board
04/2006 - 006 - 5.2 - 30.17.0011.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the MCB2100 and is the answer not in the manual?

Questions and answers

Related Manuals for Hitex MCB2100

Summary of Contents for Hitex MCB2100

  • Page 1 Quick Start Guide Hitex Starter Kit for ARM ® with MCB2100 Evaluation Board 04/2006 - 006 - 5.2 - 30.17.0011.0...
  • Page 2 Hitex Development Tools makes no commitment to update nor to keep current the information contained in this document. Hitex Development Tools makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Table Of Contents

    Contents Introduction Installing Software and Hardware Starting a Project in HiTOP The First Steps of Debugging Modifying an Application Trace Debugging (ETM Support)
  • Page 4 Hitex Starter Kit for ARM ® / MCB2100 Board...

  • Page 5: Introduction

    ARM 7-9 with HiTOP. The best way getting started is to follow the instructions of this small guide. To get more information about the Hitex Tool chain for ARM, refer to http://www.hitex.com/perm/arm_toolchain.html. A comprehensive introduction to the HiTOP5 user interface will be given in our video tutorials.

  • Page 6: Installing Software And Hardware

    Hitex Starter Kit for ARM ® / MCB2100 Board Installing Software and Hardware Installing the Software For the installation of HiTOP please insert the CD and follow the instructions on the screen. If the auto run feature of your CD drive is disabled, open the CD drive folder and start setup.exe.
  • Page 7 Hitex Starter Kit for ARM ® / MCB2100 Board Installing the Hardware Tantino for ARM 7-9 • Connect the Tantino to the PC's USB port via the USB cable (1). • Connect the 20-pin cable to the board's JTAG connector (2).

  • Page 8: Starting A Project In Hitop

    Hitex Starter Kit for ARM ® / MCB2100 Board Starting a Project in HiTOP Start HiTOP by double clicking the desktop icon: The tip of the day is presented which contains useful information when working with HiTOP. If HiTOP is started for the first time, select the System > Connect command.
  • Page 9 Hitex Starter Kit for ARM ® / MCB2100 Board Starting a FLASH Project Start the FLASH project using the Project > Open command and in the ..\Examples\LPC2000\MCB2100\GNU folder, select the following project file: Clock_MCB2100_Gnu_Flash.htp When the Download dialog is presented, click on Ok.
  • Page 10 Hitex Starter Kit for ARM ® / MCB2100 Board Project Loaded After having loaded the project successfully, proceed as follows: When pressing the target's reset button or performing a target reset using HiTOP's Debug > Reset command, execute the script file by clicking on the following toolbar icon: You may now arrange the windows according to your needs.

  • Page 11: The First Steps Of Debugging

    Hitex Starter Kit for ARM ® / MCB2100 Board The First Steps of Debugging Now the application is at the starting point ("appl_entry"). If using the flash project, the start address of the FLASH is 0. If using the RAM project, the start address of the RAM is 0x2000000.
  • Page 12 Hitex Starter Kit for ARM ® / MCB2100 Board To start debugging in the main C application you may execute the application until the function 'main' using • the Go until icon , or • the Debug > Go until dialog (entering 'main').
  • Page 13 Hitex Starter Kit for ARM ® / MCB2100 Board breakpoints and one hardware breakpoint (code breakpoint in ROM or data breakpoint). To show the features of these breakpoints, please do the following. We are now at the function 'main'. In the workspace window click on the plus sign ( ) of the 'Clock' module (if it is a minus sign please skip this action).
  • Page 14 Hitex Starter Kit for ARM ® / MCB2100 Board After starting emulation by clicking on the Go icon , emulation will stop at the breakpoint. Open the Source window's context menu right clicking on the green bar and select Disable Breakpoint.
  • Page 15 Hitex Starter Kit for ARM ® / MCB2100 Board Now start the emulation via the Go icon: After about 10 seconds the application will be stopped and 'Clock.Sec' shows the value 10. This was the intended action of this data breakpoint.

  • Page 16: Modifying An Application

    ARM Embedded Trace Macro Cell (ETM). Hitex's Tanto for ARM ® , the advanced JTAG Development Tool, can be expanded with an Add-On Module for on-chip ETM support. Please contact Hitex for more details or visit our WEB site at http://www.hitex.com/perm/arm_toolchain.html...
