- Page 1 User's Manual...
-
Page 2: Replacing The Strap
User's Manual Contents About Your InBody BAND 2 Precautions Parts and Functions Product Components InBody BAND 2 How to Use Your InBody BAND 2 Charging Powering On Turning Screen On Navigating the Display Using the App InBody Test Measuring Steps... - Page 3 The InBody BAND 2 also counts steps, measures heart rate, calculates calories burned, and tracks sleep. • Disclaimer: The InBody BAND 2 is not a medical device. It cannot determine the presence of an illness or disease. The examination of a medical professional is required for diagnosis.
- Page 4 Precautions CAUTION Please observe the following precautions and use the product in a safe manner in order to prevent an accident from occurring. • Test results may vary depending on the environment and measurement conditions. • If possible, avoid taking measurements in cold weather. • This product has been tested in a controlled environment and is water/dust-proof in specific conditions (meets the requirements of IP68 rating specified in International Standard IEC 60529 - Degrees of Protection provided by Enclosures [IP Code]). However, under certain conditions, the product may be damaged when submerged in water. • Do not disassemble product or apply electricity to the product. This may result in electric shock, injury, product malfunction or inaccurate results;...
- Page 5 • Because Bluetooth uses the same frequency as the BAND, indirect interference may occur between devices. • Users are liable for any problems occurring from data transmission or illegal use of Bluetooth. WARNING • Individuals with medical implant devices such as pacemakers or essential support devices such as patient monitoring systems should not take the InBody Test. • The electrical current used for measurements are not harmful to the human body, however, women who are pregnant should consult with a specialist. NOTES • Use a soft cloth to clean the product once a week • Product specifications and user manuals are subject to change without notice.
-
Page 6: Parts And Functions
Parts and Functions Product Components Charging Cable Safety Information and Warranty InBody BAND 2 Quick User Guide InBody BAND 2 Clip Hand Electrodes Wrist Electrodes Display Strap... - Page 7 InBody BAND 2 Screen Layout The InBody BAND 2 has different displays for each function. Date and Time: Displays date, day of week, and time InBody Test: Measures Percent Body Fat (PBF) and Skeletal Muscle Mass(SMM) Heart Rate: Step Count : Measures heart rate Measures the number of...
-
Page 8: How To Use
How to Use Charging 1. Charge the InBody BAND 2 by connecting the device to the included charging cable and plugging the USB connector into a USB port. 2. Once the InBody BAND 2 is securely connected to the charging cable, it will automatically turn on while charging. -
Page 9: Navigating The Display
Search for "InBody Wear " in the Apple App Store or the Google Play Store and download Sign Up and Sync 1. Open the InBody Wear app and press Sign Up. 2. Press InBody BAND 2 to pair your device with the app. Once it is successfully paired with the app, press Next. - Page 10 3. Select Country for your country calling code. Enter your mobile phone number and press Confirm. 4. Enter your Email address and create and confirm a password. Select the check box to accept the terms and conditions & privacy policy and press Done. 5. Input gender, height (cm or ft/in), age, weight, and nickname. Once finished, press Done.
- Page 11 Transferring Data At the InBody Wear App main screen, swipe the entire screen down to automatically update the InBody Test results as well as heart rate monitoring data, walking step count data and sleep analysis data stored on your InBody BAND 2.
-
Page 12: Inbody Test
1. Press on the bottom right of the main screen. 2. Input your current weight and press InBody Test to start the measurement. 3. Place your fingers on both electrodes, when the test icon ( ) starts blinking on the device. * It is recommended that you maintain the same posture and measurement time for the most accurate measurements. 4. After measurements are completed, the results are automatically saved in the app. * Make sure your hands do not come in contact with each other when testing. Measuring using only the InBody BAND 2 1. Press and hold both electrodes until the test icon ( ) starts blinking on the device. 2. Place your fingers on both electrodes, when the test icon ( ) starts blinking on the device. 3. After the test is completed, the result will come up on the device. * To change the result to Skeletal Muscle Mass (SMM) InBody Wear app > Menu > Device Settings > Enable Muscle Mass. * When measuring using only the InBody BAND 2, the InBody Test measurements will be based on the weight saved. -
Page 13: Measuring Steps
1. Wear your InBody BAND 2 on your wrist while carrying out your activities. 2. Your InBody BAND 2 automatically measures your steps. 3. When your InBody BAND 2 is synced with the InBody Wear app, the step data will be automatically transferred to the app. -
Page 14: Heart Rate Monitoring
2. Place two fingers on the electrodes. 3. The heart rate measurement takes about 10 seconds. 4. When your InBody BAND 2 is synced with the InBody Wear app, the result will be automatically transferred to the app on the app. - Page 15 Goal Alarm 1. Enable Goal Alarm in the Profile menu at the bottom of the main screen. 2. You can set your goal (number of walking steps, calories) by selecting the flag icon in the Activity screen. Time Alarm 1.
- Page 16 WearMe Alarm By enabling WearMe Alarm, you can get your InBody BAND 2 to alert you when you have not worn it for a set time. 1. Select WearMe Alarm in the Profile menu at the bottom of the main screen.
-
Page 17: Specifications
Specifications Current time, Percent Body Fat or Skeletal Muscle Mass (selectable from the app), heart rate, Information Displayed walking steps, active time, calories burned, distance walked/ran, notifications, EZTrainingTM, and battery level. Measurement Current Below 90μA Data Storage 2 weeks (depending on usage) Dimensions 0.7 (W) x 1.7 (L) x 0.4 (H) inches Charging Time Approx. 1 hour Wrist circumference 5.3 - 7.7 inches Color Midnight Black, Stone Gray, Red Wine, Modern Navy Input Power Operating voltage: 3.7 VDC, Charging voltage: 5.0 VDC Operating environment 50 - 104 ° F, 30 - 75%RH, 70 - 106kPa Transportation and 14 - 158 ° F, 10 - 80%RH, 50 - 106kPa (no condensation) Storage Environment Frequency Used 2402 MHz to 2480 MHz No. of Channels Modulation Method GFSK Wattage 1mW and below Waterproof Rating IP68... -
Page 18: Warranty
Warranty Product Service Standards • Complementary service is only available when a manufacturer defect or natural defect occurs within the warranty period. • Matters not specified here are subject to "Fair Trade Commission Notice of Consumer Dispute Resolution Standards". Types of Compensation for Consumer Damages Within Warranty After Warranty Types of Compensation for Consumer Damages... - Page 19 For more information on disposal and recycling electronic products, please reference local government policies. For any problems with your InBody BAND 2, please contact us at the following: InBody USA 13850 Cerritos Corporate Drive, Unit C, Cerritos, CA 90703 Website: http://www.inbody.com Email: band@inbody.com Reproduction, adaptation, or translation of this manual is prohibited without prior written consent from InBody Co., Ltd under the copyright laws. This manual might have typographical errors, and its content can be changed without a prior notice. InBody Co., Ltd. shall not be liable for any errors, incidental, or consequential damages that occurred by not complying with the content of the User's Manual. InBody Co., Ltd reserves the right to modify the appearance, specifications, and etc. of the InBody BAND 2 to improve the quality of the product, without prior notice for reasons of performance improvement.
