- Page 1 900 MHz WIRELESS COLOR CAMERA SYSTEM INCLUDES: VIDEO/AUDIO CAMERA & RECEIVER CR1916-9 USER’S GUIDE...
-
Page 2: System Contents
Congratulations on your purchase of the 900 MHz Wireless Color Camera System. The system consists of a wireless color camera with night vision and an A/V receiver, which is an ideal product for application of monitoring the porch, the yard, the pool, the pets and the baby. It is also suited to small business surveillance application. -
Page 3: Setting Up The Receiver
2. Decide whether the camera will be wall mounted or sit on a tabletop. If on a tabletop, install it as it is. If wall mounted, loosen the screw on the bracket and pull the camera out of the base bracket. Then insert the camera to the other hole in the base bracket (as shown in above pictures), then tight the screw. -
Page 4: Operating The System
OPERATING THE SYSTEM The system supports two cameras. Users can switch from one camera to the other one manually or automatically by pressing the buttons on the top panel of the receiver. Be sure that the both dip switches in the receiver should be switched on. MANUAL MODE/// To select one of the two channels manually, press the MANUAL button on the top panel of the receiver. -
Page 5: Specifications
SPECIFICATIONS Camera TV System NTSC Integrated Lens 5.6mm, F2.0 fixed focus Resolution 360 horizontal TV Lines High-Speed Electronic Shutter 1/60 - 1/15,000 sec Image Sensor 1/4” CMOS Min. Illumination 0.1 lux Current Consumption Approx. 160mA with IR lights on Overall Size 1.4"Dia x 2.5”H (excluding antenna length) Frequency 910MHz and 920MHz... - Page 6 Drilling Template for Wall Mounting Camera(s) For wall-mounting Camera (s), drill two holes using a 1/4” drill bit and the template below. Insert supplied wall anchors into holes and secure Camera to wall with supplied screws.
