Summary of Contents for AUTOAQUA Technologies Co. QEye QE-100
- Page 1 Change for Simple Installation Guide Installationsanleitung Manuel d’installation Model QE-100 01 01...
- Page 2 English Installation Diagram / List of Parts QEye QEye x1 QEye Wet Side Magnet x1 Mini USB Port x2 (Mini USB Ports can be connected either with power adapter or with QShooter.) Caution : Risk of Injury from Strong Magnets Item Pictures Description...
- Page 3 Installation (1~3) English 1. Mount QEye on the 2. Download QSmart APP aquarium and connect power QSmart 3. Set up AP Mode 3-1. Tap setting to connect QEye SSID (SSID: QEYE＊＊＊＊, Password: 12345678)
-
Page 4: Installation
English Installation (3) 3-2. After connection, go back to QSmart APP and tap “Add QEye“ Add QEye 3-3. Add QEye (3 Options) I. Key in QEye ID I. Key in QEye ID Directly II. Scan QR Code III.LAN Search *Remark QEye ID &... - Page 5 Installation (3) English II. Scan QR Code (Generate QEye ID Automatically) III. LAN Search (Recommendation)
- Page 6 English Installation (3~4) 3-4. Use default User Name and password to tap done (User : admin, Password : 4. Set up IP Mode from AP Mode 4-1. Tap setting and then go to WiFi setting Setting...
- Page 7 Installation (4) English 4-2. Choose your WiFi Router, key in password and tap join 4-3. WiFi setting is done Shows WiFi setup successfully and will restart (Please wait for a few minutes)
- Page 8 English Installation (4~5) 4-4. Go back to setting and choose your WiFi again (Choosing 3G or 4G / LTE is ok as well) 5. Wait for a few minutes and tap QSmart APP...
- Page 9 Installation (6) English 6. Tap the picture to enjoy viewing online *Remark Blue Light : QEye connects successfully. Red Light : QEye does not connect successfully. Gray Light : QEye is not online.
- Page 10 English Specifications / Notice QEye 1. Power Input : 100-240 VAC 50 / 60 HZ 2. Power Output (USB) : 5 V 2000 mA 3. Power Consumption : 5 W (Max.) 4. QEye Size : 60 mm x 75 mm x 86 mm (Width x Height x Depth) 5.
-
Page 11: Fcc Statement
FCC Statement English This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 12: Warranty Card
English Warranty Card This product is guaranteed for one year from the date of purchase at normal operation. This warranty is not transferable. Any incorrect operation will not be warranted and will result in a repair fee. All warranty repairs are performed by the distributor. Please contact the distributor to obtain a Return Authorization number when sending a warranted unit.
