ESSEX AND ENTERTAINER 8FT. DROP POCKET POOL TABLE
1.
READ THIS MANUAL CAREFULLY BEFORE STARTING ASSEMBLY.
Read each step completely before beginning each step.
2. SOME SMALLER PARTS MAY BE SHIPPED INSIDE LARGER PARTS. CHECK INSIDE ALL PARTS
AND CARTONS BEFORE ASSEMBLING OR ORDERING PARTS.
3. USE THE HARDWARE IDENTIFIER TO IDENTIFY AND SORT ALL FASTENERS. CHECK ALL CARTONS
FOR KITS. ALL HARDWARE IS NOT LOCATED IN ONE KIT.
THIS TABLE IS CONTAINED IN THREE SEPARATE CONTAINERS:
Container #1......Three playfield pieces
Container #2......Contains owner's manual, leg assemblies, hardware kits, corner and side caps,
Container #3......Contains long slats, short slats, beams, top rails, aprons, playfield cloth,
Mailing Address: Escalade® Sports, PO Box 889, Evansville, IN 47706
Escalade® Sports products may be manufactured and/or licensed under the following patents.
D446275
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
O W N E R ' S
MODEL NO. P1240LEG 527.25408
MODEL NO. P1240RAIL 527.25410
MODEL NO. P1266
corner posts, playfield spots, slate shims, glue and grout kit and drop pockets.
and additional hardware kits.
PLEASE DO NOT RETURN PRODUCT TO THE STORE!
Contact Escalade® Sports customer service department at:
Phone: 1-866-556-2757 Toll Free !
Fax: 1-866-873-3532Toll Free !
E-mail: pooltables@escaladesports.com
Please visit our World Wide Web site at:
www.escaladesports.com
On-Line Trouble Shooting Frequently Asked Questions
Technical Assistance
Additional Escalade
M A N U A L
On-Line Parts Requests
Sports Product Information
®
2L-6791-01
©2005 Escalade
®
Sports
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mizerak P1240LEG
Summary of Contents for Mizerak P1240LEG
- Page 1 O W N E R ’ S M A N U A L ESSEX AND ENTERTAINER 8FT. DROP POCKET POOL TABLE MODEL NO. P1240LEG 527.25408 MODEL NO. P1240RAIL 527.25410 MODEL NO. P1266 READ THIS MANUAL CAREFULLY BEFORE STARTING ASSEMBLY. Read each step completely before beginning each step.
- Page 2 CAUTION THE SPRAY ADHESIVE USED FOR APPLYING PLAYFIELD CLOTH IS EXTREMELY FLAMMABLE AND UNDER PRESSURE CAREFULLY READ CAUTIONS ON SPRAY ADHESIVE CONTAINER KEEP OUT OF THE REACH OF CHILDREN DO NOT USE OR STORE NEAR HEAT SOURCE FLAMES SPARKS OR WHEN SMOKING WORK AREA MUST BE WELL VENTILATED OPEN DOORS AND WINDOWS WHEN USING SPRAY ADHESIVE...
- Page 3 Figure 1 1. Open hardware kits and sort hardware into "like" groups using hardware identifier provided in this manual. 2. Attach two wooden leg panels #2 (be sure wood grain faces out) to the inside of two leg facades #1 using six screws #33, six washers #35 and six locknuts #34 per leg panel.
- Page 4 6. Before starting this part of the assembly, orient beams #4 with ball return attachment holes at the same end of the table and the holes marked by arrows in figure 3 facing up. 7. Attach wooden beams #4 to the leg assemblies (that you just put together).
- Page 5 Square up long slats #6 by measuring diago- Once frame is square, tighten screws #24 nally as shown in figure 5. Diagonals should be the holding slats to beams. Note: Be sure the heads same length within 1/8". Check to make sure the of screws #24 are flush with or below the top table is square.
- Page 6 UNBOXING THE SLATE (Slate tables only:) AFTER CRATE PARTS ARE REMOVED, BEND NAILS OR STAPLES OVER WITH A HAMMER AT ONCE! USE CAUTION WHEN HANDLING CRATE PARTS! Figure 8 14. It is now time to uncrate the slate pieces. With a claw hammer or crow bar, pry off crate top at the notched corner.
- Page 7 THE FOLLOWING STEP REQUIRES THE HELP OF ANOTHER ADULT! Detail A Figure 11 CAUTION: Be sure countersunk holes in all three 20. Place end sections #7 onto slats. Be sure they are table top sections #7 and #8 face up: See Detail "A", square, in line and butted up tight against center slate Figure 11.
- Page 8 SHIMMING INSTRUCTIONS IF REQUIRED Figure 12 General Rules Accomplish the leveling of the playing surface with as few shims as possible. Do not tap with a hammer or tighten screws unreasonably tight. You will not be able to compress the playing surface. You must shim up the playing surface to level.
- Page 9 DO NOT SMOKE WHILE WORKING WITH CONTACT CEMENT! READ LABEL Figure 13 ON CEMENT CONTAINER CAREFULLY! Applying the cloth 34. Make sure slate/slatron is dry and free of dust. NOTE: Before spraying adhesive, cut a portion of the shipping carton to use as a shield to prevent cement overspray. 35.
- Page 10 Figure 18 46. Find the three ¾ inch holes in the playing surface that are 47. Place rails in position on the playing surface and attach between each pocket. Using a small sharp knife, cut a by using rail bolts #19, washers #20 and brackets #28. small cross in cloth over each hole for the rail bolts #19 Note: See Detail B for correct orientation of to pass through.
- Page 11 48. After all top rails are LOOSELY attached to 50. Square an end rail as well as you can. Check that the playfield, straighten the side rails (#10 and #11) on corner pocket radius edges line up. one side of the table as follows: 51.
- Page 12 IMPORTANT: Make sure that the finished side is facing Figure 21 out on all aprons! 52. Push the end apron #13 up into the groove in the bottom of the end rail and center it as well as possible. Secure end aprons #13 to the two apron brackets #28 that were used to attach the rails and tighten.
- Page 13 Detail A Figure 23 Detail B Detail C 60. Insert drop pockets #17 into each CORNER pocket opening in the table (wait to attach side pockets until next step). Attach drop pockets #17 to rails by using five nails #25 per pocket. Place nails about ½ inch below the top of pocket so the balls will not hit nails and get chipped.
- Page 14 ONE YEAR LIMITED WARRANTY ® This consumer warranty extends to the original consumer purchase of any ESCALADE SPORTS Product (hereinafter referred as the "Product"). WARRANTY DURATION: This Product is warranted to the original consumer purchase of a period of one (1) year from the original purchase. WARRANTY COVERAGE: ESCALADE SPORTS warrants to the original Consumer Purchaser that any Product of its manufacture is free from defects in material and workmanship when used for the intended purpose under normal use and conditions.
- Page 18 Slat (Long) 1Q-6002-00 80 Grit Sandpaper 7 809-551/2W-6029-00 Slate (End)/Slatron (End) 1B-6117-00 ¼-20 x 2 Carriage Bolt 8 809-552/2W-6030-00 Slate (Center)/Slatron (Center) 4L-7608-00 Mizerak Nameplate 5A-6670-90 Cloth 3A-6007-00 Video For Assembly 2A-4046-98 Rail (Left) 1B-6118-00 #10-24 x 1 Rd Hd Screw...
