Advanced Charger Technology, Inc
PAGE
Warning and Precautions...................................................3
Parts included in the Kit ................................................. 4
Software Install..............................................................5
Norcross, Georgia, USA
System Connections..........................................................6
LED Status+ The Software Messages and Control .....................8-9
Operation ...................................................................10
iCHARGE Battery Analyzing Solution
Battery Charging + Battery history.....................................10-11-13
Battery Reconditioning (CYC) .........................................13
Model No. i90-100A
Capacity Add and Battery Capacity ......................................14
Application Software and
Instructions
© 2011 ACT. All rights reserved. The logo,
Are the trademarks of Advanced Charger Technology, Inc.
Advertisement
Table of Contents
Related Manuals for ACT i90-100A
Summary of Contents for ACT i90-100A
- Page 1 Battery Analyzing Solution Battery Charging + Battery history……………………………….10-11-13 Battery Reconditioning (CYC) …………………………………..13 Model No. i90-100A Capacity Add and Battery Capacity ………………………………..14 Application Software and Instructions © 2011 ACT. All rights reserved. The logo, Are the trademarks of Advanced Charger Technology, Inc.
-
Page 2: Operation
Connect your i90 to a wall AC supply (120VAC or 220VC ) and make sure To avoid electrical shock, do not open. Refer service request to ACT. all Red LED`s are blinking ( No adaptor installed ) Batteries shall not be exposed to excessive heat before charging. - Page 3 Note: Adapter’s P/N i90-003A Red light blinks when USB connection between your computer and the adaptor is achieved, Green LED will start blinking upon successful communication between your i90 and your computer (see picture # 3) Copy the iCHARGE software to your Computer. The screen in picture # 1 will appear after executing the iCHARGE Program Picture # 3 Green background will appear on the each of the Bay # software screen...
-
Page 4: Picture
An indication “No Battery“ will appear under “Charger state “after adding D. LED Status; an adaptor and the charger recognizes the adaptor (see Picture #5for 6bay configuration or picture # 6 for 12 bay configuration) The following are the LED`s statues appearing on the charger during operations. READY (Green)…………...Charge completed. -
Page 5: Picture
Parking, Battery is ready. NiMH and NiCD (battery could stay in this stage indefinitely without any Operation harm, Lithium batteries will re-start the charging process when battery self discharges to 3.6V/cell. 1. Battery Charging; Rapid Charge comes after "Soft Charge" and runs until charging is terminated. Insert battery into its relative pocket on the i90 charger, the following screen Soft Charge, come when new battery begins to charge. -
Page 6: See Picture
3. Pre-assigned battery info. Two options are available (Clicking on the battery S/N field (Color will change into Blue, reflecting proper selection.) or clicking on the History icon on the menu bar) The history window will open. (see below picture # 9) In the search box, enter the Battery S/N requested. -
Page 7: Picture
After selecting the number of cycles the charger will bring the battery to its full capacity 4. Locating battery History information file and then will discharge the battery to 1V /cell and repeat this process until the selected number of cycles is reached. - Page 8 6. Capacity Add and Battery Capacity; ****Capacity Add is the current ( capacity )added to the battery from a specific battery state. This number will be equal to the battery capacity after a full analyzing cycle**** If battery “ Cyc “ was selected then right click (after all analyzing cycles finished ) on “Battery Capacity “...
