Page 1: Dome Camera
HD-TVI Dome Camera User Manual User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice. -
Page 2: Regulatory Information
Privacy Notice Surveillance laws vary by jurisdiction. Check all relevant laws in your jurisdiction before using all this product for surveillance purpose to ensure that your use of this product conforms. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Product Features
1 Introduction 1.1 Product Features This series of camera adopts high performance sensor and advanced circuit board design technology. It features high resolution, low distortion, and low noise, etc. It is suitable for surveillance system and image process system. The main features are as follows: High performance CMOS sensor and high resolution bring high-quality image;... -
Page 4: Ceiling Mounting
2.1 Ceiling Mounting 2.1.1 Ceiling Mounting without Inclined Base Steps: 1. Disassemble the dome camera by loosening three screw of the bubble, and then take apart the bubble, as shown in Figure 2-1. Screw Figure 2-1 Disassemble the Camera Three screws on the bubble are all drop-proof screws. You don’t have to loosen them completely. - Page 5 Pan Position Range [0°-355°] Tilt Adjusting Screw Rotation Position Range Tilt Position Range [0°-355°] [0°-75°] Figure 2-4 3-axis Adjustment 6. Install the bubble to the camera and tighten three screws. Figure 2-5 Fix the Camera to the Ceiling 2.1.2 Ceiling Mounting with Inclined Base Steps: Attach the drill template (supplied) and then drill the screw holes and the cable hole in the ceiling.
- Page 6 Figure 2-8 Drill Template 2. Install the bracket onto the wall according to the template and fix the screws to secure the bracket. Figure 2-9 Fix the Bracket onto the Wall 3. Repeat steps 1-5 of 2.1.1 to fix the dome camera with the plastic bracket.
- Page 7 Figure 2-12 Install the Pendent Cap 2. Fix the adapter to the pendent cap with two screws. (Optional) Figure 2-13 Install the Adapter to the Pendent Cap 3. Repeat step 1-8 of 2.1.1 to install the camera to the pendent cap. 2.3 Pendent Mounting with Pendent Bracket Steps: 1.
-
Page 8: Menu Description
3 Menu Description SETUP FORMAT MAIN MENU VIDEO RESET &NIGHT SETTING SAVE CONTRAST &EXIT BRIGHTNESS COLOR SHARPNESS EXPOSURE MODE COLOR GAIN GAIN SMART MIRROR Figure 3-1 Main Menu Overview With a camera controller (purchased separately) or calling the preset No. 95 of DVR you can select the menu and adjust the parameters. - Page 9 BLC(Backlight Compensation) BLC (Backlight Compensa n) compensate light to the object in the front to make it clear, but this causes the over-exposure of the background where the light is strong. When BLC is selected as the exposure mode, the BLC level can be adjusted from 0 to 8.
- Page 10 INFRARED You can select to turn on/off the IR LED to response to the requirements of different circumstances. SMART IR The Smart IR func n is used to adjust the light to its most suitable intensity, and to prevent the image from over exposure.
