CyberBlock FLASH

User Manual

Meiya Pico Information Co., Ltd.

July 2016

Table of Contents

Need help?

Do you have a question about the CyberBlock FLASH and is the answer not in the manual?

Questions and answers

Summary of Contents for Meiya Pico Information Co. CyberBlock FLASH

Page 2 CyberBlock FLASH User Manual Contents 1 PRODUCT INTRODUCTION ............1 Overview ................... 1 Features .................... 1 2 COMPONENTS ................. 3 Front Panel..................4 Rear Panel ..................6 3 USAGE ....................7 Connecting a Storage Card .............. 7 Connecting to Computer ..............9 Replacing a Storage Card ...............
Page 3: Product Introduction
CyberBlock FLASH User Manual Product Introduction Overview The CyberBlock FLASH is used to provide write-protection for storage cards. It blocks all inbound write commands at hardware level. This protects data in storage cards from being modified during acquisition and analysis, maintaining the judicial availability and data integrity for forensic investigations.
Page 4 CyberBlock FLASH User Manual Compatible to various OSs, such as Mac OS, Windows 8,  Windows 7 and Windows XP Provide various interfaces that allow access from the following  storage cards: SD/MMC/miniSD/microSD/RS-MMC, MS/MS PRO/MS PRO Duo, CF, and xD/SM Support connection to the analysis computer through an USB2.0...
Page 5: Components
CyberBlock FLASH User Manual Components The CyberBlock FLASH device and its components are shown in the following figure. ①. CyberBlock FLASH device ②. USB 2.0 data cable ③. miniSD adapter ④. microSD adapter ⑤. Memory Stick Duo adapter...
Page 6: Front Panel
CyberBlock FLASH User Manual Front Panel The front panel provides access to various kinds of interfaces, as shown in the following figure. ①. xD/SM interface ②. CF/MD interface ③. MS interface ④. SD/MMC interface...
Page 7 CyberBlock FLASH User Manual The following table shows the match relations between storage cards and in interfaces. Storage Card Interface MS PRO MS PRO Duo RS-MMC miniSD (converted by miniSD adapter) microSD (converted by microSD adapter)
Page 8: Rear Panel
CyberBlock FLASH User Manual Rear Panel The rear panel is used to connect CyberBlock FLASH to the analysis computer, as shown in the following figure. ①. Mini USB interface The Mini USB interface is used to connect the device to the computer...
Page 9: Usage
CyberBlock FLASH. Connecting a Storage Card To connect a storage card to CyberBlock SATA, gently insert the card into the relevant front panel interface of CyberBlock FLASH, as shown in the following figures: Inserting an xD card ...
Page 10 CyberBlock FLASH User Manual Inserting an MS card  Inserting an SD card  When inserting an storage card such as an xD/MS/SD card, keep the panel with the chip downward and the panel with the arrow sign upward and slowly insert the card into the correct interface.
Page 11: Connecting To Computer
Slowly insert the card into the correct interface.  NOTE: CyberBlock FLASH can identify only one card at a time. Connecting to Computer You can use a USB data cable to connect CyberBlock FLASH to an analysis computer.
Page 12: Replacing A Storage Card
CyberBlock FLASH User Manual  CAUTION: It is recommended to connect CyberBlock FLASH directly to the USB interface on the motherboard of the computer. Replacing a Storage Card To change a connected storage card to another one, perform the following operations: 1 Remove the storage card from the computer OS.
Page 13 CyberBlock FLASH User Manual Q1: Why a computer cannot identify the storage card connected through CyberBlock FLASH? Check whether CyberBlock FLASH is properly connected to the computer. Use an USB interface on the computer motherboard to connect CyberBlock FLASH. If the problem persists, check whether the storage card is...
Page 14: Technical Support
CyberBlock FLASH User Manual Technical Support Tel: +86-592-2170918 Forum: https://bbs.meiyapico.com Skype: meiyapico@hotmail.com QQ Group: 261079328 Gmail: meiyapicots@gmail.com Whatsapp: +8618605926825 WeChat: MeiyaPicoTS Hardware version: V1.2 Document version: V1.1...
