IVSCKmanual
For the purpose of proper using & maintaining the kitchen scale, please read this
instruction completely before operating.
SPECIFICATIONS
● Equipped with high precision "strain-guage" sensor
● Capacity: 5g-5000g/11LB
● Graduation: 1g/8oz
● LCD Display
● Sensor touch power on
● Automatic zero resetting
● Switch off or Auto off
● Overload indicator
● Tare function
POWER
Battery: 3xAAA batteries
OPERATION
1， When in the first use, please insert the batteries.
2， Place the scale on a hard and flat surface; Press the "ON/OFF"button, the scale will
be zero in 3 seconds.
3， Put the object on the plate, weight will display.
TARE
(TO WEIGHT DIFFERENT INGREDIENTS ON THE SAME KITCHEN SCALE)
Leave the first ingredient weighed on the plate, press "TARE" button to reset the display to
"0g", add the next ingredient on the plate and the weight will appear on the display, and so
on.
UNIT EXCHANGE
When "0g" displaying or weighing, press the "Unit" button on the base, you can choose the
Advertisement
Summary of Contents for Belter Health Measurement and Analysis Technology IVSCK
- Page 1 IVSCKmanual For the purpose of proper using & maintaining the kitchen scale, please read this instruction completely before operating. SPECIFICATIONS ● Equipped with high precision “strain-guage” sensor ● Capacity: 5g-5000g/11LB ● Graduation: 1g/8oz ● LCD Display ● Sensor touch power on ●...
- Page 2 unit of “g” “oz/lb”. SWITCH OFF OR AUTO OFF 1， After finish weighing, press “ON/OFF” button to switch off. 2， After finish weighing or if no any operation of the scale, the scale will automatically switch off after approximate 30 seconds. LOW BATTERY INDICATOR When the battery power is low, scale will display "Lo", please replace the battery in time.
- Page 3 FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 Annex of Report Manufacturer’s Declaration of the EUT (altogether 5 pages) Guidance and manufacturer’s declaration – electromagnetic emission – for all EQUIPMENT AND SYSTEMS Guidance and manufacturer’s declaration – electromagnetic emission The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The customer or the user of SF-371 body fat scale should assure that it is used in such an environment.
- Page 5 Guidance and manufacturer’s declaration – electromagnetic immunity The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The customer or the user of the SF-371 body fat scale should assure that it is used in such an environment. IEC 60601 Electromagnetic environment - Compliance level...
- Page 6 IEC 61000-4-8 NOTE is the a. c. mains voltage prior to application of the test level.
- Page 7 Guidance and manufacturer’s declaration – electromagnetic immunity – for EQUIPMENT and SYSTEM that are not LIFE-SUPPORTING Guidance and manufacturer’s declaration – electromagnetic immunity The SF-371 body fat scale is intended for use in the electromagnetic environment specified below. The customer or the user of the SF-371 body fat scale should assure that it is used in such an environment.
- Page 8 NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic is affected by absorption and reflection from structures, objects and people. Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
- Page 9 For transmitters rated at a maximum output power not listed above the recommended separation distance d in metres (m) can be estimated using the equation applicable to the frequency of the transmitter, where P is the maximum output power rating of the transmitter in watts (W) according to the transmitter manufacturer. NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
