Summary of Contents for red lighting QUADRO 24
-
Page 2: General Guidelines
At first, thank you for purchasing QUADRO 24. For the sake of safety and regular operation of this projector, please read this manual carefully before using and operating it, lest incur any personal injury or damage to the projector. GENERAL GUIDELINES This device is a lighting effect for professional use on stages, in discotheques, theatres, etc.. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS This device has left the factory in perfect condition. In order to maintain this condition and to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in this user manual. If the device has been exposed to temperature changes due to environmental changes, do not switch it on immediately. - Page 4 INSTALLATION INSTRUCTIONS Mounting the device The applicable temperature for the lignting is between 0°C～45°C Do not use the lighting under or above the temperature. The installation of the effect has to be built and constructed in a way that it can hold 10 times the weight for 1 hour without any harming deformation.
- Page 5 Function Mode Set When the performer is switched on, the LCD display will appear Red Lighting ,please press any key to enter into the Function Menu. You can choose function by pressing UP or DOWN,→ arrowhead shows current operation position. Press ENTER or EXIT to enter or return into the current function.
- Page 6 5：Back Light set: → Light Enter → OFF Press UP or DOWN to choose whether the back light has been turned on or not，press ENTER to confirm，press EXIT to return. 6：W-DMX set: → W-DMX → OFF Enter RESET Press UP or DOWN to choose wireless ON , OFF or RESET to do the LOGOUT from the transmitter.
-
Page 7: Cleaning And Maintenance
We recommend a frequent cleaning of the device.Please use a moist,lint- free cloth.Never use alcohol or solvents.Should you need any spare parts,please order genuine parts. Technical Parameters: QUADRO 24 (24*15W) Operating environment: indoor and outdoor with IP65 protection LED quantity : 24pcs 15W RGB 3in1 high-power LEDs Control mode：DMX-512 signal , automatic , master and slave...
