PCE Americas Inc.
PCE Instruments UK Ltd.
711 Commerce Way
Units 12/13
Suite 8
Southpoint Business Park
Jupiter
Ensign way
FL-33458
Hampshire / Southampton
USA
United Kingdom, SO31 4RF
From outside US: +1
From outside UK: +44
Tel: (561) 320-9162
Tel: (0) 2380 98703 0
Fax: (561) 320-9176
Fax: (0) 2380 98703 9
info@pce-americas.com
info@pce-instruments.com
www.pce-instruments.com/english
www.pce-instruments.com
Manual
Crane scale PCE-CS 10000N
Version 1.0
Date of creation: 23.09.2015
Date of last change: 08.09.2016
Advertisement
Table of Contents
Summary of Contents for PCE Americas PCE-CS
- Page 1 From outside UK: +44 Tel: (561) 320-9162 Tel: (0) 2380 98703 0 Fax: (561) 320-9176 Fax: (0) 2380 98703 9 info@pce-americas.com info@pce-instruments.com www.pce-instruments.com/english www.pce-instruments.com Manual Crane scale PCE-CS 10000N Version 1.0 Date of creation: 23.09.2015 Date of last change: 08.09.2016...
- Page 2 Zero function ..........................8 Tare function ..........................8 Hold function ..........................8 Accumulation function ........................ 9 Battery voltage ..........................9 Brightness ........................... 9 Measuring unit ..........................9 Troubleshooting ....................10 Contact ........................11 PCE Instruments UK ........................ 11 PCE Americas .......................... 11...
-
Page 3: Introduction
Thank you for purchasing a crane scale from PCE Instruments. The crane scale PCE-CS 10000N can weigh up to 10 tons. To do so, the scale comes with a solid shackle on top and a rotatable safety hook on the bottom side. The 5-digit LED display has a character height of 30 mm, so that it is easily readable, even from a distance. - Page 4 Manual ranges in which the measuring equipment can be used, as stipulated in the operating instructions, must always be adhered to. The usage of the equipment in areas which are exposed to high levels of contamination or corrosion should be avoided. In instances of major temperature fluctuations, the equipment must be given time to acclimatise before being used.
-
Page 5: Specification
264 x 206 x 745 mm Weight 30 kg Delivery contents 1 x crane scale PCE-CS 10000N incl. Shackle, hook and battery 1 x charging adaptor 1 x remote control 2 x 1.5 V AAA batteries 1 x instruction manual... -
Page 6: System Description
Manual System description Dimensions A (mm) B (mm) C (mm) D (mm) H (mm) R (mm) Display Measuring unit LED display indication Charging indication Infrared receiver ON/OFF button Tare button and and stable tare indication indication Max. capacity... -
Page 7: Remote Control
Manual Remote control Button Function ZERO Zeroing Note: Use this function, if the scale is unloaded, but the display shows a reading unequal “0”. In settings: Increase selected digit TARE Activate tare function In setting: go to next digit SHIFT Activate further functions in combination with other buttons (see chapter 5) In settings: confirm input... -
Page 8: Operation
Manual Operation Turn the scale on/off To turn the crane scale on, press and hold the ON/OFF Button on the scale for 3 seconds. Now, the display shows the following: 1. [88888] 2 times 2. [ Ert ] 2 times 3. -
Page 9: Accumulation Function
Manual Accumulation function To activate the accumulation function, press the ACCU button on the remote control. The display now shows the following: 1. [No***] how many readings have been added to the sum 2. [H****] the first 4 digits of the sum 3. -
Page 10: Troubleshooting
Manual Troubleshooting Problem Possible cause Possible solution Display does not show anything Battery dead Recharge battery Battery damaged Replace battery ON/OFF button damaged Contact customer support ON/OFF button was not pressed Press and hold ON/OFF button properly for 3 seconds Display starts blinking Battery voltage low Recharge battery... -
Page 11: Contact
PCE Instruments UK Ltd. Units 12/13 Southpoint Business Park Ensign Way, Southampton Hampshire United Kingdom, SO31 4RF By phone: 02380 987 035 PCE Americas By post: PCE Americas Inc. 711 Commerce Way Suite 8 Jupiter 33458 FL By phone: 561 3209162...
