iEi Integration Corp. POC-17i User Manual

Poc-17i/19i series medical panel pc with intel core i7/i5/i3 processor, tft lcd, wireless lan, touch screen, rs-232/422/485 and rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
POC-17i/19i Series
MODEL:
POC-17i/19i Series
Medical Panel PC with Intel® Core™ i7/i5/i3 Processor,
TFT LCD, Wireless LAN, Touch Screen,
RS-232/422/485 and RoHS
User Manual
Page i
Rev. 1.01 – June 30, 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POC-17i and is the answer not in the manual?

Questions and answers

Summary of Contents for iEi Integration Corp. POC-17i

  • Page 1 POC-17i/19i Series MODEL: POC-17i/19i Series Medical Panel PC with Intel® Core™ i7/i5/i3 Processor, TFT LCD, Wireless LAN, Touch Screen, RS-232/422/485 and RoHS User Manual Page i Rev. 1.01 – June 30, 2016...
  • Page 2 POC-17i/19i Series Revision Date Version Changes June 30, 2016 1.01 Updated Appendix D: Hazardous Materials Disclosure August 7, 2013 1.00 Initial release Page ii...
  • Page 3 POC-17i/19i Series Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 POC-17i/19i Series Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Contact Information

    POC-17i/19i Series Contact Information Headquarters IEI Integration Corp. No. 29, Zongxing Rd., Xizhi Dist., Address: New Taipei City 221, Taiwan +886-2-8691-6798 Phone: +886-2-6616-0028 Fax: www.ieiworld.com Web Site: sales@ieiworld.com.tw Sales Email: IEI Integration USA Corp. 138 University Parkway, Address: Pomona, CA 91768...
  • Page 6 POC-17i/19i Series Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 E ....................3 XTERNAL VERVIEW 1.3.1 General Description................... 3 1.3.2 Front Panel ......................3 1.3.3 Rear Panel ......................4 1.3.4 I/O Interface Panel .................... 5 1.3.5 OSD Control Buttons ..................
  • Page 7 POC-17i/19i Series 3.6.6.1 COM3 RS-422 and RS-485 Pinouts ............26 3.6.7 COM3 RS Function Select Jumper ..............27 3.6.8 ME Debug Mode Jumper ................. 28 3.6.9 iTPM Setting Jumper ..................29 3.6.10 ME RTC Select Jumper.................. 30 3.6.11 SPI Setting Jumper ..................31 3.7 M...
  • Page 8 POC-17i/19i Series 5.3.1 ACPI Settings ....................54 5.3.2 Trusted Computing ................... 55 5.3.3 CPU Configuration..................56 5.3.4 SATA Configuration ..................57 5.3.5 USB Configuration................... 58 5.3.6 Super IO Configuration ................... 59 5.3.6.1 Serial Port n Configuration ............... 60 5.3.7 H/W Monitor ....................64 5.3.8 Serial Port Console Redirection ..............
  • Page 9 POC-17i/19i Series A.2 M ............104 AINTENANCE AND LEANING RECAUTIONS A.2.1 Maintenance and Cleaning................104 A.2.2 Cleaning Tools ....................105 A.3 FCC P ....................106 RECAUTIONS B BIOS OPTIONS ......................107 B.1 BIOS C ................108 ONFIGURATION PTIONS C WATCHDOG TIMER ....................110 D HAZARDOUS MATERIALS DISCLOSURE ............113...
  • Page 10 POC-17i/19i Series List of Figures Figure 1-1: POC-17i/19i Series Medical Panel PC ...............2 Figure 1-2: Front View ........................4 Figure 1-3: Rear View ........................4 Figure 1-4: I/O Interface Connector Panel..................5 Figure 1-5: OSD Control Buttons ....................6 Figure 1-6: POC-17i Series Dimensions (mm) ................9 Figure 1-7: POC-17i Series Dimensions (mm) ................10...
  • Page 11 POC-17i/19i Series Figure 4-3: DDR SO-DIMM Module Installation................46 Figure 4-4: HDD Cover Screw......................47 Figure 4-5: HDD Bracket Retention Screw .................47 Figure 4-6: HDD Removal ......................48 Figure 6-1: Chipset Driver File Extraction Screen..............77 Figure 6-2: Chipset Driver Welcome Screen................77 Figure 6-3: Chipset Driver License Agreement .................78 Figure 6-4: Readme File Information Screen ................78...
  • Page 12 POC-17i/19i Series Figure 6-32: Wireless Driver Installation ..................95 Figure 6-33: Keypad Driver Welcome Screen................96 Figure 6-34: Customer Information Screen ................96 Figure 6-35: Setup Type .......................97 Figure 6-36: Ready to Install the Program .................97 Figure 6-37: Installing KeypadAP v2.2 ..................98 Figure 6-38: Keypad Driver Installation Complete Screen ............98 Figure 6-39: Reboot the Computer .....................99...
  • Page 13 POC-17i/19i Series List of Tables Table 1-1: System Specifications....................8 Table 3-1: Jumpers ........................20 Table 3-2: Preconfigured Jumpers .....................21 Table 3-3: Clear CMOS Jumper Settings..................21 Table 3-4: COM1 Pin 9 Setting Jumper Settings ...............22 Table 3-5: COM3 Pin 9 Setting Jumper Settings ...............23 Table 3-6: COM3 TX Function Select Jumper Settings.............24...
  • Page 14 POC-17i/19i Series BIOS Menus BIOS Menu 1: Main ........................52 BIOS Menu 2: Advanced ......................54 BIOS Menu 3: ACPI Configuration ....................54 BIOS Menu 4: TPM Configuration ....................55 BIOS Menu 5: CPU Configuration ....................56 BIOS Menu 6: IDE Configuration....................57 BIOS Menu 7: USB Configuration ....................58 BIOS Menu 8: Super IO Configuration..................59...

  • Page 15: Introduction

    POC-17i/19i Series Chapter Introduction Page 1...

  • Page 16: O Verview

    1.1 Overview Figure 1-1: POC-17i/19i Series Medical Panel PC The POC-17i/19i Series is an Intel® Core™ powered flat panel PC with a rich variety of functions and peripherals. All POC-17i/19i Series models are designed for easy and simplified integration into point-of-care (POC) applications.

  • Page 17: F Eatures

    SATA HDD drive. 1.3.2 Front Panel The front side of the POC-17i/19i Series is a flat panel TFT LCD screen surrounded by an anti-bacteria plastic frame. The power LED is located at the top center of the front panel (Figure 1-2).

  • Page 18: Rear Panel

    POC-17i/19i Series Figure 1-2: Front View 1.3.3 Rear Panel The rear panel provides access to retention screw holes that support the wall mounting. Refer to Figure 1-3. Figure 1-3: Rear View Page 4...

  • Page 19: I/O Interface Panel

    POC-17i/19i Series 1.3.4 I/O Interface Panel The I/O interface panel located on the bottom of the POC-17i/19i Series has the following I/O interface connectors:  1 x Power switch  1 x 12 V DC In connector  1 x RS-232 connector ...

  • Page 20: Osd Control Buttons

    POC-17i/19i Series 1.3.5 OSD Control Buttons The POC-17i/19i Series has seven OSD control buttons as shown below. Figure 1-5: OSD Control Buttons 1.4 Internal Overview The POC-17i/19i Series has the following components installed internally:  1 x Mainboard  1 x 2.0 GB 800/1066 MHz DDR3 SO-DIMM ...

  • Page 21: System Specifications

    POC-17i/19i Series 1.5 System Specifications The technical specifications for the POC-17i/19i Series systems are listed in Table 1-1. Specification POC-17i POC-19i LCD Size 17” 19” Max. Resolution 1280 x 1024 1280 x 1024 Brightness (cd/m LCD Color 16.7 M 16.7 M Viewing Angle (H-V) 170 。...

  • Page 22: Table 1-1: System Specifications

    POC-17i/19i Series Specification POC-17i POC-19i CAN/CSA C22.2 No. 60601-1 IEC/EN 60601-1 3rd edition Touch Screen Resistive Type 5-wire (touch controller is on board) Power Adapter Manufacturer: FSP Group Inc. (Medical Grade) Model: PMP120-12-S Input: 100 V ~ 240 V, 47 Hz ~ 63 Hz, 1.4 A ~ 0.6 A...

  • Page 23: Figure 1-6: Poc-17I Series Dimensions (Mm)

    POC-17i/19i Series 1.6 Dimensions The POC-17i Series dimensions are shown in Figure 1-6 and listed below.  428 mm Width:  250.1 mm Height: 76 mm (approximate)  Depth: Figure 1-6: POC-17i Series Dimensions (mm) Page 9...

  • Page 24: Figure 1-7: Poc-17I Series Dimensions (Mm)

    POC-17i/19i Series The POC-19i Series dimensions are shown in Figure 1-7 and listed below.  469.9 mm Width:  382.5 mm Height:  79 mm (approximate) Depth: Figure 1-7: POC-17i Series Dimensions (mm) Page 10...

  • Page 25: Unpacking

    POC-17i/19i Series Chapter Unpacking Page 11...

  • Page 26: U Npacking

    POC-17i/19i Series WARNING: The labels on the external box are best to be read at a distance of 30 cm due to the small label size. 2.1 Unpacking To unpack the flat panel PC, follow the steps below: WARNING! The front side LCD screen has a protective plastic cover stuck to the screen.

  • Page 27: Packing List

    POC-17i/19i Series 2.2 Packing List The POC-17i/19i Series flat panel PC is shipped with the following components: NOTE: If any of these items are missing or damaged, contact the distributor or sales representative immediately. Quantity Item Image Standard POC-17i/19i Series...
  • Page 28 POC-17i/19i Series Touch pen User manual CD and driver CD Page 14...

  • Page 29: Installation

    POC-17i/19i Series Chapter Installation Page 15...

  • Page 30: P Recautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the POC-17i/19i Series. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the POC-17i/19i Series is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered ...

  • Page 31: C Onfiguration S Teps

    Over-tightening rear cover screws will crack the plastic frame. Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm). To access the POC-17i/19i Series internally, the rear panel cover must first be removed. To remove the rear panel cover, please follow the steps below.

  • Page 32: I Nternal A Luminum C Over

    Maximum torque for cover screws is 5 kg-cm (0.36 lb-ft/0.49 Nm). To remove the internal aluminum cover, follow the steps below. Remove retention screws securing the internal aluminum cover. Step 1: Figure 3-2 shows the aluminum cover retention screws of the POC-17i/19i Step 2: Series. Page 18...

  • Page 33: Figure 3-2: Aluminum Back Cover Retention Screws

    The following jumpers can be found on the motherboard installed in the POC-17i/19i Series. Before the POC-17i/19i Series is installed, the jumpers must be set in accordance with the desired configuration. The jumpers on the POC-17i/19i Series motherboard are listed in Table 3-1.

  • Page 34: Access The Jumpers

    WARNING: Do not change the settings on the jumpers in described here. Doing so may disable or damage the system. The following jumpers are preconfigured for the POC-17i/19i Series. Users should not change these jumpers (Table 3-2). Jumper Name Label...

  • Page 35: Clear Cmos Jumper

    See Figure 3-3 Jumper Location: If the POC-17i/19i Series fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, use the jumper cap to close the pins for a few seconds then remove the jumper clip.

  • Page 36: Com1 Pin 9 Setting

    POC-17i/19i Series Figure 3-3: Clear CMOS Jumper 3.6.4 COM1 Pin 9 Setting Jumper Label: JP7 and JP8 Jumper Type: 6-pin header Jumper Settings: See Table 3-4 and Table 3-5 Jumper Location: See Figure 3-4 and Figure 3-5 Two jumpers (JP7 and JP8) configure pin 9 on COM1 and COM3 DB-9 connectors. Pin 9 on the COM1 and the COM3 DB-9 connectors can be set as the ring (RI) signal, +5 V or +12 V.

  • Page 37: Figure 3-4: Jp7 Jumper Setting Location

    POC-17i/19i Series The JP7 jumper location is shown below. Figure 3-4: JP7 Jumper Setting Location Description Short 1-2 COM3 RI +12 V Short 3-4 COM3 RI Normal Short 5-6 COM3 RI +5 V Table 3-5: COM3 Pin 9 Setting Jumper Settings The JP8 jumper location is shown below.

  • Page 38: Com3 Tx Function Select Jumper

    POC-17i/19i Series Figure 3-5: JP8 Jumper Setting Location 3.6.5 COM3 TX Function Select Jumper Jumper Label: 6-pin header Jumper Type: Jumper Settings: See Table 3-6 Jumper Location: See Figure 3-6 The COM3 TX Function Select jumper configures the TX pin on COM3 serial port connector as RS-422 or RS-485.

  • Page 39: Com3 Rs-232/422/485 Jumper

    POC-17i/19i Series Figure 3-6: COM3 TX Function Select Jumper Location 3.6.6 COM3 RS-232/422/485 Jumper Jumper Label: JP10 Jumper Type: 12-pin header (four 3-pin headers combined) Jumper Settings: See Table 3-7 Jumper Location: See Figure 3-7 The COM3 RS-232/422/485 Serial Port Select jumper sets the communication protocol used by the second serial communications port (COM3) as RS-232, RS-422 or RS-485.

  • Page 40: Com3 Rs-422 And Rs-485 Pinouts

    POC-17i/19i Series Short 5-6 RS-422/485 Short 8-9 RS-422/485 Short 11-12 RS-422/485 Table 3-7: COM3 RS-232/422/485 Serial Port Select Jumper Settings The COM3 RS-232/422/485 Serial Port Select jumper location is shown in Figure 3-7. Figure 3-7: COM3 RS-232/422/485 Serial Port Select Jumper Location 3.6.6.1 COM3 RS-422 and RS-485 Pinouts...

  • Page 41: Com3 Rs Function Select Jumper

    POC-17i/19i Series COM 3 RS-485 Description Pin 1 Data- Pin 2 Data+ Table 3-9: RS-485 Pinouts 3.6.7 COM3 RS Function Select Jumper Jumper Label: JP11 Jumper Type: 8-pin header Jumper Settings: See Table 3-10 Jumper Location: See Figure 3-8 The COM3 RX Function Select jumper sets the communication protocol used by the RX serial communications port COM3 as RS-232, RS-422 or RS-485.

  • Page 42: Me Debug Mode Jumper

    POC-17i/19i Series Figure 3-8: COM3 RX Function Select Jumper Location 3.6.8 ME Debug Mode Jumper Jumper Label: JP12 Jumper Type: 2-pin header Jumper Settings: See Table 3-11 Jumper Location: See Figure 3-9 The ME Debug Mode jumper allows ME firmware overwrite protection. The ME Debug Mode jumper settings are shown in Table 3-11.

  • Page 43: Itpm Setting Jumper

    POC-17i/19i Series Figure 3-9: ME Debug Mode Jumper Location 3.6.9 iTPM Setting Jumper Jumper Label: J_ITPM1 3-pin header Jumper Type: Jumper Settings: See Table 3-12 Jumper Location: See Figure 3-10 The iTPM jumper settings are shown in Table 3-12. iTPM setting...

  • Page 44: Me Rtc Select Jumper

    POC-17i/19i Series Figure 3-10: iTPM Jumper Location 3.6.10 ME RTC Select Jumper Jumper Label: ME_RTC1 Jumper Type: 3-pin header Jumper Settings: See Table 3-13 Jumper Location: See Figure 3-11 The ME RTC select jumper settings are shown in Table 3-13.

  • Page 45: Spi Setting Jumper

    POC-17i/19i Series Figure 3-11: ME RTC Jumper Location 3.6.11 SPI Setting Jumper Jumper Label: J_SPI Jumper Type: 3-pin header Jumper Settings: See Table 3-14 Jumper Location: See Figure 3-12 The SPI jumper settings are shown in Table 3-14. SPI setting...

  • Page 46: M Ounting The S Ystem

    PC does not fall down and get damaged. The methods of mounting the POC-17i/19i Series are listed below.  Wall mounting ...

  • Page 47: Figure 3-13: Wall-Mounting Bracket

    POC-17i/19i Series Drill four pilot holes at the marked locations on the wall for the bracket retention Step 3: screws. Align the wall-mounting bracket screw holes with the pilot holes. Step 4: Secure the mounting-bracket to the wall by inserting the retention screws into Step 5: the four pilot holes and tightening them (Figure 3-13).

  • Page 48: Figure 3-14: Chassis Support Screws

    POC-17i/19i Series NOTE: In the diagram below the bracket is already installed on the wall. Figure 3-14: Chassis Support Screws Secure the panel PC by fastening the retention screw of the wall-mounting Step 9: bracket. (Figure 3-15). Page 34...

  • Page 49: Arm Mounting

    Figure 3-15: Securing the Panel PC 3.7.2 Arm Mounting The POC-17i/19i Series is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 75mm or 100mm interface pad. To mount the POC-17i/19i Series on an arm, please follow the steps below.

  • Page 50: B Ottom P Anel C Onnectors

    100 mm interface pad. If the mounting arm is not VESA compliant it cannot be used to support the POC-17i/19i Series flat panel Once the mounting arm has been firmly attached to the surface, lift the flat panel Step 2: PC onto the interface pad of the mounting arm.

  • Page 51: Serial Device Connection

    RJ-45 connector into the onboard RJ-45 connector. 3.8.2 Serial Device Connection The POC-17i/19i Series has two male DB-9 connectors on the bottom panel for serial devices to be connected. Follow the steps below to connect a serial device to the POC-17i/19i Series panel PC.

  • Page 52: Usb Device Connection

    3.8.3 USB Device Connection There are four external USB 2.0 connectors. All connectors are perpendicular to the POC-17i/19i Series. To connect a USB 2.0 or USB 1.1 device, please follow the instructions below. Located the USB connectors. The locations of the USB connectors are shown Step 1: in Chapter 2.

  • Page 53: Vga Monitor Connection

    3.8.4 VGA Monitor Connection The POC-17i/19i Series has a single female DB-15 connector on the external peripheral interface panel. The DB-15 connector is connected to a CRT or VGA monitor. To connect a monitor to the POC-17i/19i Series, please follow the instructions below.

  • Page 54: At/Atx M Ode S Election

    Step 0: 3.9 AT/ATX Mode Selection AT and ATX power modes can both be used on the POC-17i/19i Series. The selection is made through an AT/ATX switch on bottom panel (Figure 3-21). To select AT mode or ATX mode, follow the steps below.

  • Page 55: At Power Mode

    Manufacturing shop flow 3.9.2 ATX Power Mode With the ATX mode selected, the POC-17i/19i Series panel PC goes in a standby mode when it is turned off. The panel PC can be easily turned on via network or a power switch in standby mode.

  • Page 56: System Maintenance

    POC-17i/19i Series Chapter System Maintenance Page 42...

  • Page 57: S Ystem M Aintenance I Ntroduction

    POC-17i/19i Series 4.1 System Maintenance Introduction If the components of the POC-17i/19i Series fail they must be replaced. Components that can be replaced include:  SO-DIMM module  HDD drive Please contact the system reseller or vendor to purchase replacement parts.

  • Page 58: Turn Off The Power

    POC-17i/19i Series 4.3 Turn off the Power WARNING: Failing to turn off the system before opening it can cause permanent damage to the system and serious or fatal injury to the user. Before any maintenance procedures are carried out on the system, make sure the system is turned off.

  • Page 59: Figure4-1: Hdd Bracket Screws

    POC-17i/19i Series Figure 4-1: HDD Bracket Screws Lift the HDD bracket away to expose the DIMM connectors. See (Figure 4-2). Step 4: Figure 4-2: SO-DIMM Socket Location Remove the DDR memory module by pulling both the spring retainer clips Step 5: outward from the socket.

  • Page 60: Hdd Card Replacement

    DDR memory module in the socket. Figure 4-3: DDR SO-DIMM Module Installation 4.4.2 HDD Card Replacement The POC-17i/19i Series is preinstalled with one HDD. To replace the HDD, follow the instructions below. Follow all anti-static procedures. See Section 4.2.

  • Page 61: Figure 4-4: Hdd Cover Screw

    POC-17i/19i Series Figure 4-4: HDD Cover Screw Remove the HDD bracket retention screw (Figure 4-4). Step 4: Figure 4-5: HDD Bracket Retention Screw Pull the old HDD from the HDD slot. Step 5: Page 47...

  • Page 62: Figure 4-6: Hdd Removal

    POC-17i/19i Series Figure 4-6: HDD Removal Line up the new HDD with the SATA connector. Step 6: Insert the HDD into SATA connector until it is securely in place. Step 7: Secure the HDD bracket with the previously removed retention screw.

  • Page 63: Bios Setup

    POC-17i/19i Series Chapter BIOS Setup Page 49...

  • Page 64: I Ntroduction

    POC-17i/19i Series 5.1 Introduction A licensed copy of the BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 65: Getting Help

    POC-17i/19i Series Right arrow Move to the item on the right hand side Increase the numeric value or make changes Decrease the numeric value or make changes Page Up key Move to the next page Page Dn key Move to the previous page Esc key Main Menu –...

  • Page 66: Main

    POC-17i/19i Series  Selects exit options and loads default settings Save & Exit The following sections completely describe the configuration options found in the menu items at the top of the BIOS screen and listed above. 5.2 Main The Main BIOS menu ( B IOS Menu 1) appears when the BIOS Setup program is entered.

  • Page 67: A Dvanced

    POC-17i/19i Series  Memory Information The Memory Information lists a brief summary of the on-board memory. The fields in Memory Information cannot be changed.  Total Memory: Displays the auto-detected system memory size and type. The System Overview field also has two user configurable fields: ...

  • Page 68: Acpi Settings

    POC-17i/19i Series Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit > ACPI Settings System ACPI Parameters > Trusted Computing > CPU Configuration > SATA Configuration > USB Configuration ---------------------- > Super IO Configuration : Select Screen...

  • Page 69: Trusted Computing

    POC-17i/19i Series  ACPI Sleep State [S3 (CPU Stop Clock)] Use the ACPI Sleep State option to specify the sleep state the system enters when it is not being used.  The system enters S1 (POS) sleep state. The (CPU...

  • Page 70: Cpu Configuration

    POC-17i/19i Series  TPM Support [Disable] Use the TPM Support option to configure support for the TPM.  TPM support is disabled. Disable EFAULT  TPM support is enabled. Enable 5.3.3 CPU Configuration Use the CPU Configuration menu (BIOS Menu 5) to view detailed CPU specifications and configure the CPU.

  • Page 71: Sata Configuration

    POC-17i/19i Series 5.3.4 SATA Configuration Use the SATA Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced SATA Configuration (1) IDE Mode.

  • Page 72: Usb Configuration

    POC-17i/19i Series  Configures the on-board SATA controller to be in Compatible EFAULT compatible mode. In this mode, a SATA channel will replace one of the IDE channels. This mode supports up to 6 storage devices. 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings.

  • Page 73: Super Io Configuration

    POC-17i/19i Series  Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support. Normally if this option is not enabled, any attached USB mouse or USB keyboard does not become available until a USB compatible operating system is fully booted with all USB drivers loaded.

  • Page 74: Serial Port N Configuration

    POC-17i/19i Series 5.3.6.1 Serial Port n Configuration Use the Serial Port n Configuration menu (BIOS Menu 9) to configure the serial port n. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Advanced Serial Port 0 Configuration Enable or Disable Serial...
  • Page 75 POC-17i/19i Series  Serial Port I/O port address is 3F8h and the interrupt IO=3F8h; address is IRQ3, 4 IRQ=3, 4  Serial Port I/O port address is 2F8h and the interrupt IO=2F8h; address is IRQ3, 4 IRQ=3, 4  Serial Port I/O port address is 2C0h and the interrupt IO=2C0h;...
  • Page 76 POC-17i/19i Series  Serial Port I/O port address is 2C8h and the interrupt IO=2C8h; address is IRQ3, 4 IRQ=3, 4 5.3.6.1.3 Serial Port 2 Configuration  Serial Port [Enabled] Use the Serial Port option to enable or disable the serial port.
  • Page 77 POC-17i/19i Series 5.3.6.1.4 Parallel Port Configuration  Parallel Port [Enabled] Use the Parallel Port option to enable or disable the parallel port.  Disable the parallel port Disabled  Enable the parallel port Enabled EFAULT  Change Settings [Auto] Use the Change Settings option to change the parallel port IO port address and interrupt address.

  • Page 78: H/W Monitor

    POC-17i/19i Series  Printer mode  EPP-1.7 and SPP Mode ECP and EPP 1.7 Mode  5.3.7 H/W Monitor The H/W Monitor menu (BIOS Menu 10) shows the operating temperature, fan speeds and system voltages. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc.

  • Page 79: Serial Port Console Redirection

    POC-17i/19i Series VCC3V Vcore +12 V +1.5V VSB3V VBAT 5.3.8 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 11) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port.

  • Page 80: C Hipset

    POC-17i/19i Series 5.4 Chipset Use the Chipset menu (BIOS Menu 12) to access the Northbridge and Southbridge configuration menus WARNING! Setting the wrong values for the Chipset BIOS selections in the Chipset BIOS menu may cause the system to malfunction.

  • Page 81: Northbridge Configuration

    POC-17i/19i Series 5.4.1 Northbridge Configuration Use the Northbridge Chipset Configuration menu (BIOS Menu 13) to configure the Northbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset Memory Information IGD Share Memory Size CPU Type Arrandale Total Memory...

  • Page 82: Southbridge Configuration

    POC-17i/19i Series 5.4.2 Southbridge Configuration Use the Southbridge Configuration menu (BIOS Menu 14) to configure the Southbridge chipset. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Chipset Auto Power Button [Disabled] When Auto Power Button Restore AC Power Loss...

  • Page 83: Intel Igd Swsci Opregion

    POC-17i/19i Series  onboard High Definition Audio controller Enabled EFAULT automatically detected and enabled  Set Spread Spectrum [Disabled] Use the Set Spread Spectrum option to enable or disable the Set Spread Spectrum function.  Set Spread Spectrum is disabled...
  • Page 84 POC-17i/19i Series  256 MB  Maximum Default  Active LFP [Enable LVDS] Use the Active LFP option to enable or disable LVDS.  LVDS is disabled Disable EFAULT LVDS  LVDS is enabled Enable LVDS  LCD Panel Type [Select by Panel ID] Use the LCD Panel Type option to select the type of flat panel connected to the system.

  • Page 85: Boot

    POC-17i/19i Series 5.5 Boot Use the Boot menu (BIOS Menu 16) to configure system boot options. Aptio Setup Utility – Copyright (C) 2010 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit Boot Configuration Enables/Disables Quiet Quiet Boot...

  • Page 86: S Ecurity

    POC-17i/19i Series  Does not enable the keyboard Number Lock automatically. To use the 10-keys on the keyboard, press the Number Lock key located on the upper left-hand corner of the 10-key pad. The Number Lock LED on the keyboard lights up when the Number Lock is engaged.

  • Page 87: Exit

    POC-17i/19i Series  Administrator Password Use the Administrator Password field to set or change a administrator password.  User Password Use the User Password field to set or change a user password.  Set User Password Use the Set User Password field to set or change an HDD user password.
  • Page 88 POC-17i/19i Series  Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.  Discard Changes and Reset Use the Discard Changes and Reset option to exit the system without saving the changes made to the BIOS configuration setup program.

  • Page 89: Software Drivers

    POC-17i/19i Series Chapter Software Drivers Page 75...

  • Page 90: A Vailable S Oftware D Rivers

    POC-17i/19i Series 6.1 Available Software Drivers NOTE: The content of the CD may vary throughout the life cycle of the product and is subject to change without prior notice. Visit the IEI website or contact technical support for the latest updates.

  • Page 91: Figure 6-1: Chipset Driver File Extraction Screen

    POC-17i/19i Series Figure 6-1: Chipset Driver File Extraction Screen When the setup files are completely extracted the Welcome Screen in Figure Step 4: 6-2 appears. Click N to continue. Step 5: Figure 6-2: Chipset Driver Welcome Screen The license agreement in Figure 6-3 appears.

  • Page 92: Figure 6-3: Chipset Driver License Agreement

    POC-17i/19i Series Read the License Agreement and click Y to continue. Step 7: Figure 6-3: Chipset Driver License Agreement The Readme File Information screen in Figure 6-4 appears. Step 8: Click N to continue. Step 9: Figure 6-4: Readme File Information Screen Setup operations are performed as shown in Figure 6-5.

  • Page 93: Figure 6-5: Setup Progress Screen

    POC-17i/19i Series Once the setup operations are complete, click N to continue. Step 11: Figure 6-5: Setup Progress Screen The Setup Is Complete screen appears. Step 12: Select “Yes, I want to restart the computer now” and click Finish (Figure Step 13: 6-6).

  • Page 94: Vga D River I Nstallation

    POC-17i/19i Series 6.3 VGA Driver Installation To install the VGA driver, please do the following. Access the driver list from the driver CD Step 1: Click VGA and double click on the folder which corresponds to your operating Step 2: system.

  • Page 95: Figure 6-8: Vga Driver Setup File Extraction Screen

    POC-17i/19i Series Figure 6-8: VGA Driver Setup File Extraction Screen The Welcome Screen in Figure 6-9 appears. Step 8: Click N to continue. Step 9: Figure 6-9: VGA Driver Welcome Screen The License Agreement in Figure 6-10 appears. Step 10: Click Y to accept and continue.

  • Page 96: Figure 6-10: Vga Driver License Agreement

    POC-17i/19i Series Figure 6-10: VGA Driver License Agreement The Readme File in Figure 6-11 appears. Step 12: Click N to continue. Step 13: Figure 6-11: VGA Driver Readme File Setup operations are performed as shown in Figure 6-12. Step 14: Once the setup operations are complete, click N to continue.

  • Page 97: Figure 6-12: Vga Driver Setup Operations

    POC-17i/19i Series Figure 6-12: VGA Driver Setup Operations The Setup Is Complete screen appears. Step 16: Select “Yes, I want to restart the computer now” and click F . See Figure Step 17: INISH 6-13. Figure 6-13: VGA Driver Setup Is Complete Screen...

  • Page 98: Lan D River I Nstallation

    POC-17i/19i Series 6.4 LAN Driver Installation To install the LAN driver, please do the following. Access the driver list from the driver CD Step 1: Locate the installation icon setup.exe and double click on it. Step 2: The Welcome screen in Figure 6-14 appears.

  • Page 99: Figure 6-15: Lan Driver Welcome Screen

    POC-17i/19i Series Figure 6-15: LAN Driver Welcome Screen The program begins to install. Step 7: The installation progress can be monitored in the progress bar shown in Figure Step 8: 6-16. Figure 6-16: LAN Driver Installation When the driver installation is complete, the screen in Figure 6-17 appears.

  • Page 100: A Udio D River I Nstallation

    POC-17i/19i Series Click F to exit setup. Step 10: INISH Figure 6-17: LAN Driver Installation Complete 6.5 Audio Driver Installation To install the Realtek High Definition (HD) Audio driver, please follow the steps below. 6.5.1 BIOS Setup Enter the BIOS setup. To do this, reboot the system and press F2 during POST.

  • Page 101: Figure 6-18: The Installshield Wizard Starts

    POC-17i/19i Series Locate the install icon and double click on it. Step 3: The InstallShield Wizard starts (Figure 6-18). Step 4: Figure 6-18: The InstallShield Wizard Starts The InstallShield Wizard is prepared to guide the user through the rest of the Step 5: process (Figure 6-19).

  • Page 102: Figure 6-20: Installshield Wizard Welcome Screen

    POC-17i/19i Series Figure 6-20: InstallShield Wizard Welcome Screen InstallShield starts to install the new software as shown in Figure 6-21. Step 8: Figure 6-21: Audio Driver Progress Screen The Installation Wizard updates the system as shown in Figure 6-22. Step 9:...

  • Page 103: Figure 6-22: Installation Wizard Updates The System

    POC-17i/19i Series Figure 6-22: Installation Wizard Updates the System After the driver installation process is complete, a confirmation screen appears Step 10: (Figure 6-23). The confirmation screen offers the option of restarting the computer now or later. Step 11: For the settings to take effect, the computer must be restarted.

  • Page 104: Figure 6-24: Penmount Welcome Screen

    POC-17i/19i Series 6.6 Touch Screen Driver To install the touch panel software driver, please follow the steps below. Access the driver list from the driver CD Step 1: Click Touch Screen. Step 2: Open the x:\5. Touch Screen\PenMount Windows Universal Driver Step 3: V2.1.0.263 directory and locate the installation icon setup.exe.

  • Page 105: Figure 6-25: License Agreement

    POC-17i/19i Series Figure 6-25: License Agreement Browse for an install location or use the one suggested then click I Step 8: NSTALL continue (Figure 6-26). Figure 6-26: Choose Install Location The Install screen appears and displays the progress of the installation (Figure Step 9: 6-27).

  • Page 106: W Ireless D River

    POC-17i/19i Series Figure 6-27: Installing PenMount Universal Driver V2.1.0.263 When the installation is complete, click F to exit setup (Figure 6-28). Step 10: INISH Figure 6-28: PenMount Universal Driver Update Complete 6.7 Wireless Driver To install the wireless driver, please follow the steps below.

  • Page 107: Figure 6-29: Wireless Driver License Agreement

    POC-17i/19i Series Select an OS folder then double click the installation icon setup.exe. Step 2: The license agreement in Figure 6-29 appears. Step 3: Figure 6-29: Wireless Driver License Agreement Accept the conditions of the license agreement and click N to continue.

  • Page 108: Figure 6-30: Wireless Driver Configuration Tool Options

    POC-17i/19i Series Figure 6-30: Wireless Driver Configuration Tool Options The Wireless Mode Options window in Figure 6-31 appears. Step 7: Click N in Figure 6-31. Step 8: Figure 6-31: Wireless Mode Select Window Click I in Figure 6-32 to start to install the driver.

  • Page 109: Keypad Driver

    POC-17i/19i Series Figure 6-32: Wireless Driver Installation After the installation is complete, click F to exit setup. Step 10: INISH 6.8 Keypad Driver To install the Keypad software driver, please follow the steps below. Select Keypad from the list from the driver CD Step 1: Locate the installation icon “KeypadAP_v2.2.msi”...

  • Page 110: Figure 6-33: Keypad Driver Welcome Screen

    POC-17i/19i Series Figure 6-33: Keypad Driver Welcome Screen The Customer Information appears as shown in Figure 6-34. Step 5: Enter user and organization name in the fields provided then click N Step 6: Figure 6-34: Customer Information Screen Select a setup type (Figure 6-35) and click N...

  • Page 111: Figure 6-35: Setup Type

    POC-17i/19i Series Figure 6-35: Setup Type The InstallShield Wizard is ready to install the program. Step 8: Click I to continue (Figure 6-36). Step 9: NSTALL Figure 6-36: Ready to Install the Program The installation screen appears and displays the progress of the installation Step 10: (Figure 6-37).

  • Page 112: Figure 6-37: Installing Keypadap V2.2

    POC-17i/19i Series Click N to continue. Step 11: Figure 6-37: Installing KeypadAP v2.2 When the installation process is complete, click F . See Figure 6-38. Step 12: INISH Figure 6-38: Keypad Driver Installation Complete Screen The user is then prompted to select to restart the computer now or later (Figure Step 13: 6-47).

  • Page 113: Figure 6-39: Reboot The Computer

    POC-17i/19i Series Figure 6-39: Reboot the Computer Page 99...

  • Page 114: A Safety Precautions

    POC-17i/19i Series Appendix Safety Precautions Page 100...

  • Page 115: A.1 S Afety P Recautions

    WARNING: The precautions outlined in this chapter should be strictly followed. Failure to follow these precautions may result in permanent damage to the POC-17i/19i Series. A.1 Safety Precautions Please follow the safety precautions outlined in the sections that follow: A.1.1 General Safety Precautions Please ensure the following safety precautions are adhered to at all times.

  • Page 116: A.1.2 Explanation Of Graphical Symbols

    POC-17i/19i Series  The signal input parts or signal output parts (SIP/SOP) need to be connected properly and any unused SIP/SOP shall not be accessible to unqualified personnel after the LCD is integrated into a medical system. The unit is for exclusive interconnection with IEC 60XXX certified equipment ...

  • Page 117: A.1.3 Anti-Static Precautions

    POC-17i/19i Series This symbol alerts the user that important information concerning the operation and maintenance of this unit has been included. Therefore, the information should be read carefully in order to avoid any problems. ISO 7000-1641: Follow operating instructions or consult instructions for use.

  • Page 118: A.1.4 Product Disposal

    A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the system, please read the details below. Special maintenance is not necessary during normal use of the POC-17i/19i  Series panel PC. If the user has any questions on how to operate the panel PC, please contact the manufacturer for technical support and customer service (contact information is listed on Page iv).

  • Page 119: A.2.2 Cleaning Tools

    POC-17i/19i Series  Except for the LCD panel, never spray or squirt liquids directly onto any other components. To clean the LCD panel, gently wipe it with a piece of soft dry cloth or a slightly moistened cloth. The interior of the system does not require cleaning. Keep fluids away from ...

  • Page 120: A.3 Fcc P Recautions

    POC-17i/19i Series A.3 FCC Precautions WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This...

  • Page 121: B Bios Options

    POC-17i/19i Series Appendix BIOS Options Page 107...

  • Page 122: B.1 Bios C Onfiguration O Ptions

    POC-17i/19i Series BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 5. 　 System Overview .........................52 　 Memory Information ......................53 　 System Date [xx/xx/xx] ......................53 　 System Time [xx:xx:xx] .......................53 　 ACPI Sleep State [S3 (CPU Stop Clock)] ................55 　...
  • Page 123 POC-17i/19i Series 　 Realtek 8111E PXE OpROM [Disabled]................72 　 Administrator Password .....................73 　 User Password ........................73 　 Set User Password ......................73 　 Save Changes and Reset ....................74 　 Discard Changes and Reset ....................74 　 Restore Defaults ........................74 　 Save as User Defaults ......................74 　...

  • Page 124: C Watchdog Timer

    POC-17i/19i Series Appendix Watchdog Timer Page 110...
  • Page 125 POC-17i/19i Series NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.

  • Page 126: Example Program

    POC-17i/19i Series NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BX, 05 ;time-out value is 5 seconds ;...

  • Page 127: D Hazardous Materials Disclosure

    POC-17i/19i Series Appendix Hazardous Materials Disclosure Page 113...
  • Page 128 POC-17i/19i Series The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 129 POC-17i/19i Series 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T 11363-2006 (现由 GB/T 26572-2011 取代) 标准规定的限量要求以下。...

This manual is also suitable for:

Poc-19i

Table of Contents
