Summary of Contents for Salini SCI-4052B
- Page 2 CONTENTS Important safety information Description of the appliance Control panel Installation 7-10 Cleaning and Maintenance 11-12 Technical data Declaration of conformity IMPORTANT: This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it in a safe place so that it is easily available for future reference;...
-
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING: Do not use or attempt to install this appliance until you have read this instruction manual. This appliance is intended for household use only. General Information This appliance is designed for domestic household use and designed be built into a standard kitchen cabinet or housing unit. - Page 4 The positions where the heat will radiate from are clearly marked on the hob top. The saucepans must be positioned exactly on these zones for efficient heating to occur. Pans should have the same diameter as the cooking zone that they are being used on. ...
-
Page 5: Child Safety
Electrical Caution CAUTION! Cleaning operations must only be carried out when the oven is cool and disconnected from the power supply. Any work on electric equipment and systems may only be carried out by authorized qualified persons. In case of any damage, switch off the appliance and disconnect it from the power supply ... -
Page 6: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Induction hob 4 zone schematic diagram... -
Page 7: Control Panel
Induction hob control panel ON/OFF: Turn the machine on or off CHILD LOCK: Press button once to lock the appliance. Other buttons will not operate while appliance is locked. Hold the button down to unlock. PLUS: Increase the power level or add the time. MINUS: Reduce the power level or reduce the time. -
Page 8: Installation
INSTALLATION The installation must be carried out by a suitably qualified person, in compliance with local electrical and building rules and specifications, and the instructions outlined in this manual. IMPORTANT: Ensure that the appliance is installed in a suitable position, in consideration to adjacent walls, cupboards and protection for combustible materials in accordance with local rules. - Page 9 2. Due to the high temperatures reached inside the Induction Cooker, you must ensure adequate ventilation is provided to assure the appliance will operate correctly. Follow the guidelines below for correct ventilation.
- Page 10 3. If the hob is installed on top of a drawer, put a shelf in between as shown below (50mm) 4. If shelves are put in between, ensure that they allow air to flow (30mm) IMPORTANT: In the case of units with base plinths, a front grill is necessary which allows an input section of at least 100 sq.
-
Page 11: Installing The Induction Cooktop
Installing the Induction Cooktop WARNING: Be careful of cutting edges. End parts are in foamed plastic. During unpacking these components could cause slight injuries or cuts. Step 1: Put a towel or cloth on the work surface. Place the hob face down on the protected surface. -
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE CAUTION! Cleaning operations must only be carried out when the hob is cool. The appliance should be disconnected from the power supply before commencing any cleaning process. Cleaning the ceramic hob top Any residues that are left on the hob top surface from cleaning agents will damage it. - Page 13 IMPORTANT: If your appliance appears not to be operating correctly, please make contact with the dealer. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF! Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
-
Page 14: Technical Data
TECHNICAL DATA Specifications Model Rated Voltage: Max Rated Dimensions Net Weight Inputs: (mm) (kg) SCI-4052B 220-240V ~ 50Hz 7000W 580x510x65 12.6 -13-... -
Page 15: Installation
DECLARATION OF CONFORMITY Australian Standards This product has been designed and manufactured to comply with all relevant Australian and New Zealand Standards. AS/NZS 60335.1 General Requirements for Domestic Electrical Appliances AS/NZS 60335.2.6 Specific Requirements for Domestic Electrical Cooking Appliances This appliance is SAA certified Installation of the appliance must be only be undertaken by a licenced electrician who can provide a compliance certificate.
