Sirius Conductor Sate lli te R ad io Tun e r a nd Wi re l e s s C o n tro ll er Installation & User Guide...
Page 3
Congratulations on your purchase of the SIRIUS Conductor Satellite Radio Tuner! SIRIUS Satellite Radio: The Best Radio On Radio With everything from 100% commercial-free music to in-depth sports coverage, plus news, talk and the hottest entertainment – you can always hear exactly what you want. •...
Page 4
Table of Contents WaRnIng and SafeTy InfORmaTIOn FCC Warning ........4 Remote Control Certifications .
Page 5
Key Mover Feature ....... . . 46 Key Macros Feature ....... . 47 Adjusting the Contrast of the LCD Display .
Warning and Safety Information FCC Warning This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in this User Guide. The user could lose the authority to operate this equipment if an unauthor- ized change or modification is made.
Consult the dealer or an experienced radio/TV technician for help. Compliance with IC Rules and Regulations IC: 2575A-URC10000 Model: URC-10000 Universal Electronics Inc. This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC Rules.
General Precautions SIRIUS disclaims all liability for hearing loss, bodily injury, or property damage as a result of the use or misuse of this product. general Safety Warnings Be sure to observe the following warnings. Failure to follow these safety instructions and warnings may result in a serious injury or death.
Page 9
a rubber grommet to prevent the wire’s insulation from being cut by the metal edge of the hole. • Use the specified accessory parts and install the product securely. Be sure to use only the specified accessory parts. Use of non-specified parts may damage this unit internally or may not securely install the unit in place.
Package Contents The following items are included with your purchase of the Sirius Conductor: Indoor/Outdoor antenna Indoor/Outdoor antenna Sirius Conductor Tuner Sirius Conductor Tuner aC Power adapter aC Power adapter Wireless Controller Wireless Controller RCa audio Cable RCa audio Cable IR Blaster Cable IR Blaster Cable Package Contents...
Controls Sirius Conductor Tuner Buttons and Connectors Figure 1 and the table following identify and describe the buttons and connectors of the Sirius Conductor Tuner. DIN CONNECTOR RESET BUTTON IR CONNECT IR CONNECT RESET SECOND AUDIO OUT OPTICAL TUNER 5V DC POWER L/R AUDIO OUT AUDIO OUT...
Page 12
The following table describes the functions of the buttons and connectors on the Sirius Conductor Tuner. Sirius Conductor Tuner Button and Connector descriptions Button/ description Connector Connection for a second SIRIUS radio COnneCTOR Resets the Sirius Conductor Tuner ReSeT When the tuner is powered on, this light is red to indicate the tuner is receiving power POWeR led When off, the tuner is standby mode or is not receiving power...
Wireless Controller Buttons Figure 2 and the table following identify and describe the buttons of the wireless controller. SIRIUS POWER LCD DISPLAY SCREEN SCROLL LEFT SCROLL RIGHT NUMERIC KEYS INPUT ENTER/DIR LAST VOLUME UP/DOWN CHANNEL UP/DOWN MUTE CURSOR UP/CHANNEL PREVIOUS CURSOR LEFT/CATEGORY PREVIOUS CURSOR RIGHT/CATEGORY PREVIOUS SELECT...
Page 14
The following table describes the functions of the buttons on the wireless controller. Wireless Controller Button descriptions Button description Press and hold SET to enter the wireless controller’s setup menus. Pressing SIRIUS enters the SIRIUS mode and transmits an ON com- mand to your SIRIUS Conductor Tuner.
Page 15
SIRIUS Wireless Controller Button descriptions Continued Button action Use LAST to recall the last channel when in the SIRIUS mode. Use Vol+ and Vol– to increase or decrease the audio device’s volume when in the SIRIUS mode. Use CH+ or CH– to tune the next or previous channel when in the SIRIUS mode.
Page 16
SIRIUS Wireless Controller Button descriptions Continued Button action Use SKIP BACK to command your PVR to instantly replay the last 7 sec- onds of a program you are watching. Use QUICK SKIP to command your PVR to SKIP FORWARD in the pro- gram you are watching.
Page 17
SIRIUS Wireless Controller Button descriptions Continued Button action Use POWER to turn off the Sirius Conductor Tuner. Use Select to choose a highlighted item in a menu. Use Cursor Up and Cursor Down to navigate through menus. Use Cursor Left and Cursor Right to change categories when in the SIRIUS Mode, or to navigate menus in your devices.
Installation Before you begin installation, read this installation section completely and follow the instruc- tions. In addition, consult the manual of the audio device to which you will connect the Sirius Conductor Tuner to determine the required installation configuration. Note the following when installing: •...
Page 19
a clear unobstructed view of the sky. If your location is in major metropolitan area, the antenna may be located inside the home because terrestrial transmitters are used to boost signal strength. If you cannot obtain a clear 360 degree view of the sky (Best), then for the Better and Good installations you must at least have a clear view of the sky in the direction of the SIRIUS satel- lites, as shown in the following map diagram.
Page 20
area 4: You will need a location with a clear view of the sky facing WeST or nORThWeST or SOUThWeST area 5: You will need a clear view of the sky facing STRaIghT UP (Outdoors only) Choose a mounting location for the antenna which has an unobstructed view of the sky in the direction for your area.
visit your retailer or our website at http://sirius.com for information on signal distribu- tion accessories that let you use RG-6 coax cable, your existing in-home wiring, and other technologies to connect your Sirius Conductor Tuner to the antenna. These other options allow placement of the antenna with the best view of the sky regardless of the location of your Sirius Conductor Tuner.
Conductor Tuner to operate with your particular equipment. You may use the provided audio cable with RCA-type connectors, or purchase an optical cable if an optical con- nection is desired. Connect the provided IR blaster cable to the IR Connect connector. The other end of the IR blaster cable should be adhered to your receiver’s infrared remote control win- dow.
Activating Your SIRIUS Subscription Before you can listen to the your Sirius Conductor Tuner, you must subscribe to Sirius Satel- lite Radio service. Make sure that you have properly connected the Sirius Conductor Tuner and that its antenna is oriented to receive the SIRIUS satellite signal, as described previously. Press to turn the Sirius Conductor Tuner on.
Quick Start Adding a Device to the Wireless Controller by Manufacturer Code You can add a device to the wireless controller by manually entering its manufacturer’s code. For a list of manufacturer’s codes, refer to the Manufacturer’s Codes section beginning on page 53.
Adding a Device to the Wireless Controller by Searching for the Manufacturer Code To add a device to the wireless controller by scrolling through a list of manufacturer codes, perform the following steps: Turn on the device (receiver, TV, etc.) that you want to add to the wireless controller by pressing the power button on the device.
Page 26
To set up your wireless controller to control your receiver’s volume: Temporarily connect the IR blaster cable to your receiver’s infrared remote control window. Note: If you cannot find your receiver’s infrared window, try shining a flashlight at your receiver to locate the infrared “eye”. Press OK to exit the SIRIUS mode.
Using the SIRIUS Key and the POWER Key to Turn Your Devices On or Off You can use the SIRIUS key on your wireless controller to turn on your Sirius Conductor Tuner, and the POWER key to turn it off. When you press SIRIUS, the wireless controller enters the SIRIUS mode and turns on your the Sirius Conductor Tuner.
Page 28
Sirius Conductor Tuner Operation This section provides operation information for the Sirius Conductor Tuner. For operation information regarding your connected audio equipment, consult the owners manual which accompanied that equipment. Display Modes This section provides information about the screens displayed on the wireless controller. Note that before the wireless controller will display any information about the Sirius Conductor Tuner, it must be paired with the tuner as described in the section Pairing Your Wireless Controller With Your Sirius Conductor Tuner on page 20.
Page 29
display Button Pressing DISPLAY from the default screen switches between the channel name and category on the top line of the display. (Figure 2) 001 CAT Artist Name Song Title figure 2 figure 2 Channel list mode Pressing and holding DISPLAY for three seconds enters Channel List mode. Use CURSOR UP ( ), CURSOR DOWN ( ), CH +, or CH –...
CATEGORY 001 CH Name 002 CH Name figure 4 figure 4 The currently selected channel is highlighted on the second row. Pressing CH + or CH – browses the channels while remaining in Category List mode. Pressing CURSOR UP ( ) or CURSOR DOWN ( ) browses through the channels while keeping the second line highlighted.
Selecting a Preset To select a channel you have saved as a preset: Select the band by pressing and releasing BAND until the desired band is displayed in the upper right hand corner of the display (A, B, or C). Press and release the numeric key in which the preset is stored, for example, 1.
001 CH NAME Artist Name Song Title figure 5 figure 5 Press SWAP to switch the display between the SIRIUS radios. Menu Options To display the Menu Options, press MENU. A list of the Menu Options will be displayed. (Figure 6) MENU OPTIONS Signal Indicator Factory Reset...
Page 33
the indoor/outdoor antenna in a location which receives a consistent signal from the SIRIUS satellites. The signal indicator screen provides a visual display of the signal strength being received from the satellites (S) and terrestrial transmitters (T). A consistent signal of three bars or greater is required for good reception.
Page 34
Factory Restore? figure 8 figure 8 Sirius Id The Sirius ID menu option displays the SIRIUS ID number (SID) of your SIRIUS Conductor Tuner. This 12-digit number is unique to your tuner and is needed when activating the tuner to receive the Sirius Satellite Radio service.
Page 35
Special Display Messages The wireless controller may also display status information about the Sirius Conductor Tuner. These messages are described in the following table. Message Explanation Out of Range The LCD displays Out of Range whenever the wireless controller and the Sirius Conductor Tuner cannot communicate because they are too far apart or out of range because of some other interference.
Wireless Controller Operation The SIRIUS Conductor includes a wireless controller which allows you to operate up to 12 home entertainment devices as well as your Sirius Conductor Tuner. Read this section to familiarize yourself with using the wireless controller. Setting Up Your Wireless Controller The first time you power up your wireless controller, you will need to pair it with the Sirius Conductor Tuner.
Page 37
Additional nodes in your network could be other Z-Wave compatible products such as an RF signal repeater to extend the range of operation of your wireless controller, lighting products, HVAC controls, or other remote controls, etc. Once a node has been added to your network, it will act as a range extender for your wireless controller.
network Reset Performing a network reset will delete all nodes which had been added to the wireless con- troller, including your Sirius Conductor Tuner. If you only want to remove a specific node from your network, refer to the previous section Deleting a Node. To perform a network reset: Press and hold SET until the LCD displays Initial Setup.
Page 39
device Types long name Short name CABLE BOX SATELLITE MISC AUDIO HOME CTRL LASER DISC CASSETTE MEDIA AMPLIFIER Note: You must set up your audio device so that your wireless controller controls the volume and mute functions in order for these features to work properly. Refer to the section Control- ling Your Receiver’s Volume and Setting Its Audio Source Using Your Wireless Controller on page 23.
Page 40
Enter the four-digit code for your device using the 0—9 buttons. The SIRIUS button blinks once for each digit entry. It blinks twice after the you have entered the final digit. SIRIUS button emits one long blink and the LCD If an invalid code is entered, the displays Invalid.
The LCD displays REPLACE WHAT? Press Scroll Left ( ) or Scroll Right ( ) to select the device you want to replace. Press OK. The LCD displays With What Device. Press Scroll Left ( ) or Scroll Right ( ) to go to a replacement device.
Press and hold SET until the LCD displays Initial Setup. Press OK. The LCD displays ADD DEVICE. Press Scroll Left ( ) or Scroll Right ( ) to go to VIEW CODE. Press OK. The first line of the LCD displays the long name of the current device and the third line displays the 4-digit code number for the device.
press the SIRIUS button, the wireless controller will automatically select the correct audio source input. Note: Any learning of key functions for your audio device must be performed before you choose the audio source input. Refer to the section Learn Feature on page 41 for more information.
Page 44
Codes section beginning on page 53. (For example, for a CD player you could enter code 0180.) learning key functions To have the wireless controller learn a key function from a device’s remote control: Press and hold SET until the LCD displays Initial Setup. Use Scroll Left ( ) or Scroll Right ( ) to go to Advanced Setup and press OK.
Page 45
Note: If learning fails, the LCD display reads LEARNING FAILED PUSH OK TO LEARN PUSH SET TO EXIT. Possible causes for learning failure might be: • Attempting the learning procedure too close to a UV source (i.e., sunlight or fluorescent lighting).
The LCD displays ADD LEARN KEY . Press Scroll Left ( ) or Scroll Right ( ) to go to DELETE LEARN KEY. Press OK. The LCD displays SELECT MODE THEN PUSH OK. The device name is displayed on the bot- tom line (for example, DVD).
Page 47
You can now proceed to add other devices so that their volume is locked to the source device you have just selected. adding a device for Volume lock You can add devices for volume lock so that their audio volume will be controlled by the device you have designated to control volumes.
device you removed from volume lock (for example, TV2 has been removed from Volume Lock). The LCD displays Push OK to remove another or push Set to Exit. Press OK to add remove another device from volume lock or press and hold SET to exit the menu. Key Mover Feature The key mover feature allows you to move key functions for a device from one key to another key, and from one device to another device.
deleting moved keys You can delete all moved keys from a device or delete a single moved key from a device. To delete moved keys: Press and hold SET until the LCD displays Initial Setup. Press Scroll Left ( ) or Scroll Right ( ) to go to Advanced Setup and press OK.
Page 50
Right ( ) to go to Advanced Setup and press OK. From ADVANCED SETUP, press Scroll Left ( ) or Scroll Right ( ) to go to KEY MACRO. Press OK. The LCD displays ADD KEY MACRO. Press OK. The LCD displays SELECT MACRO KEY. Press any key except SET, Scroll Left ( ), Scroll Right ( SIRIUS and press OK.
Adjusting the Contrast of the LCD Display You can adjust the contrast setting of the LCD display on the wireless controller. To change the contrast setting: Press and hold SET until the LCD displays Initial Setup. Use Scroll Left ( ) or Scroll Right ( ) to go to Advanced Setup and press OK.
About Feature The About screen displays information about the wireless controller and the Sirius Conductor Tuner. You can find software version information about the wireless controller and the Sirius Conductor Tuner using this feature. To view the About information: Press and hold SET until the LCD displays Initial Setup. Use Scroll Left ( ) or Scroll Right ( ) to go to Advanced Setup and press OK.
Resetting to factory Settings Resetting the wireless controller to its factory settings will delete everything that has been programmed in the wireless controller, including all devices which have been added to the wireless controller. Use caution when restoring to the factory settings. To perform a factory reset: Press and hold SET until the LCD displays Initial Setup.
Page 54
Right ( ) to go to SIRIUS Setup and press OK. From SIRIUS SETUP press Scroll Left ( ) or Scroll Right ( ) to go to REMOTE COPY. Press The LCD displays TRANSMIT NETWORK INFORMATION. Press OK. The LCD displays Sending until the wireless controller completes the replication process. The LCD displays Successful if the programming was successfully sent, or TIME OUT if the programming was not successfully sent.
Setup Codes For Setup Codes For DVD Players Sony 0533, 1533, , DVD/VCR Combination 1033, 1431 Sylvania 0675 Setup Codes For Symphonic 0675 DVD/VCR Combination Teac 0790, 0809 Controlled by the DVD Technics 0490, 0703 Broksonic 0695 Theta Digital 0571 Emerson 0675 Toshiba...
Setup Codes For Setup Codes For Home Automation DVD Recorders 0240 GoldStar 1537 Kenmore 1537 Setup Codes For DVD Recorders 1537 Funai 0675 One For All 0167 1164 Radio Shack 0240 Magnavox 0646, 0675 Russound 1232, 1233 Panasonic 0490 Security System 0167 Philips 0646...
Setup Codes For Setup Codes For Video Laser Disk Players Media Center Controllers Realistic 0203 Tagar Systems 1272 Sony 0193, 0201 Toshiba 1272 Technics 0204 Touch 1272 Theta Digital 0194 Viewsonic 1272 Yamaha 0217 Voodoo 1272 ZT Group Controlled by the VCR CyberPower 1972 Setup Codes For...
Setup Codes For PVRs Setup Codes For Televisions Hush 1972 Akai 0812, 0702, 0030, 0672 iBUYPOWER 1972 America Action 0180 Linksys 1972 Anam 0180 Media Center PC 1972 0030 Microsoft 1972 Apex Digital 0748, 0879, 0765 Mind 1972 Audiovox 0451, 0180, 0092 Niveus Media 1972 Aventura...
Troubleshooting Symptom Solution I’m only receiving channels 000 Call 1-888-539-7474 to activate your subscription. and 184 The wireless controller Make sure your antenna is securely connected to the continues to display “Antenna Sirius Conductor Tuner. Not Detected” The wireless controller doesn’t Press the Reset button on the Sirius Conductor Tuner.
Page 73
Troubleshooting Continued Symptom Solution I get an Out of Range message Go through SIRIUS setup and delete the Sirius Conduc- tor Tuner. Then pair the Sirius Conductor Tuner to the even when I’m close to the wireless controller again. Refer to the section Pairing Sirius Conductor Tuner Your Wireless Controller With Your Sirius Conductor Tuner on page 20.
SIRIUS ID Write down the SIRIUS ID (SID) of your Sirius Conductor Tuner in the space provided below. SID: _______________________________________ SIRIUS ID...
Page 77
SIRIUS Product Support: 1-800-869-5364 customercare@sirius-radio.com SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 1-888-539-7474 http://www.sirius.com...
Page 78
SIRIUS Satellite Radio Inc. 1221 Avenue of the Americas New York, NY 10020 (800) 869-5590 http://sirius.com Sirius Conductor Installation & User Guide (091807)
