Summary of Contents for HY-LINE CLUX-1CAT8H
- Page 1 CLUX-1CAT8H 1 by 8 CAT6 to HDMI V1.3 Splitter Operation Manual CLUX-1CAT8H...
- Page 3 Disclaimers The information in this manual has been carefully checked and is believed to be accurate. Cypress Technology assumes no responsibility for any infringements of patents or other rights of third parties which may result from its use. Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document.
-
Page 4: Revision History
Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: Always follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. - Page 5 Table of Contents Introduction ……………………..……………………...…..….……. Applications …………………..………………….……....….. Package Contents ………………………...………....… System Requirements ……………..………..………....……. Features …………………………………………..……..…...…… Specifications ………………………………...……..………..…. Operation Controls and Functions ……………...……....…… Front Panel ................Rear Panel .…………………………………..……..…...….… Pin Definitions ……………...……..........…… IR Cable Pin Definitions ............RJ-45 Pin Definitions ..............Connection and Installation ….…………………..…..…..…..
-
Page 6: Introduction
1. Introduction This 1 by 8 CAT6 to HDMI 1.3 splitter allows users to distribute an HDMI source to seven HDMI displays located up to 40 meters away. Providing a way to send a single source to eight different screens, it can aslo connect to another CAT6 splitter through the CAT6 output port, allowing you to send your single HDMI signal to more than the original seven displays. -
Page 7: Features
5. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant Deep color video up to 12bit, 1080p@60Hz Allows users to link up to eight displays HDCP keysets allows each output to work independently when connected to an HDMI display Supports both DVI source and display by using an HDMI to/from DVI ... -
Page 8: Specifications
6. Specifications Video Bandwidth 2.25MHz/6.75Gbps Input Ports 1 x CAT6 input Video/1 x CAT6 input DDC Output Ports 1 x CAT6 output Video/1 x CAT6 output DDC 7 x HDMI female ports (Type A connector) EDID STD / TV HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D-TrueHD, DTS-HD HDMI Cable Out... -
Page 9: Operation Controls And Functions
SYNC SYNC POWER POWER OUTPUT CLUX-1CAT8H 1x8 CAT6 HDMI 1.3 SPLITTER ① ② ③ ④ ① HDMI/DVI indicators: When the LED turns on this means the input source is HDMI and when the input source is DVI the LED will not turn on. - Page 10 2. When EDID is switched to STD the unit will use its built-in EDID which supports: Video → 1080p 8-bit or 12-bit (max) Audio → PCM 2CH 3. The EDID selection will only activate when the unit is plugged in and powered on.
-
Page 11: Pin Definitions
8. Pin Definitions 8.1 IR Cable Pin Definitions IR Blaster IR Receiver ① Power 5V ① IR signal ② IR blaster signal ② Power 5V ③ NC ③ Grounding ① ② ③ ① ② ③ Note: The frequency on both IR Receiver & Blaster can support 20~60KHz. 8.2 RJ-45 Pin Definitions Video TX2+... - Page 13 60°...
-
Page 14: Acronyms
Acronyms Acronym Complete Term CAT6 Category 6 cable Digital Visual Interface EDID Extended Display Identification Data HDCP High-Bandwidth Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television Infrared LPCM Linear Pulse Code Modulation Standard SYNC Synchronize UXGA Ultra Extended Graphics Array Video Graphics Array... - Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw 20091111 MPM-CLUX1CAT8H...
