Summary of Contents for Castleton ZH1292 STORAGE LOUNGE
- Page 1 ZH1292 STORAGE LOUNGE -GREY MICRO ZH1292 STORAGE LOUNGE For assistance with assembly contact: -KHAKI MICRO Wayfair Customer Service, 877-WAYFAIR (877-929-3247) Assembly Instructions www.wayfair.com Page 1...
- Page 2 ZH1292 STORAGE LOUNGE Parts List Before beginning assembly, separate all parts and carefully study the parts diagrams below. Review all parts and hardware before disposing of any packaging. You may receive extra hardware with your unit. Call Customer Service for missing hardware.
- Page 3 ZH1292 STORAGE LOUNGE Assembly Instructions Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated on the front page. Open the Seat’s (Part A) cover and keep the Seat’s (Part A) cover open.
- Page 4 Attach Side panel (Part C) to Seat (Part A) and Back panel (Part B) by bolts (1) and Spring washer (2) and flat washer(3), Tighten them by using Allen wrench (4) as shown in Figure 3. Figure 3 Lift the Velcro strip from the Side of side panel (Part C) Insert bolt (1) and Spring washers (2) and flat washers (3) into...
- Page 5 Attach front Legs (Part D) into the seat (A) by hand rotating and attach the back leg(part E) to Back panel (Part B)’s pre-drilled holes by hand rotating, Tighten them by hand as shown in Figure Figure 5 Turn over the lounge, Then place the Pillow on the lounge as shown.
