Summary of Contents for Arbrux Two Light Fixture Kit
- Page 1 Two Light Fixture Kit 5- Step Quick Install Guide...
- Page 2 Thank you for choosing Arbrux! Our products represent great quality at a great price! We have worked hard to become the benchmark for our industry since 1979. We are excited to show you how easy our products are to install...
- Page 3 Step 1: Tighten Light Connector • Hand tighten lighting underwater connector from lights to shore power cable.
- Page 4 Step 2: Assemble • Assemble U shaped bracket on fixture to L shaped bracket as shown. U bracket to L bracket must be adjusted to ensure fixture is completely submerged when installed in water.
- Page 5 Step 3: Install • Install L shaped bracket from previous step on float. Shown on 40 inch float, 32 inch float can accommodate four fixtures maximum...
- Page 6 Step 4: Run Power Cables 1. Install fountain or aerator as per instructions and moor float. 2. Run power cables to shore.
- Page 7 Step 5A: Connect- ½ HP Single Phase 1. For ½ HP Single Phase models connect shore end of light kit cable to external lighting controller shown. 2. Plug controller into GFCI protected receptacle. 3. Adjust controller to desired setting.
- Page 8 Step 5B: Connect- For Larger Single Phase For larger single phase models, have your electrician connect to applicable terminals in control panel and adjust timer...
- Page 9 You’re Done... Time to Enjoy the View!
- Page 10 Don’t Forget to Show us your Lights in Action... Email your Images to sales@arbrux.com and your night images could be featured on our site!
