Page 1: Swimming Pool
SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual English Version... - Page 2 SWIMMING POOL HEAT PUMP Contents Performance Data Specifications Performance data of Swimming Pool Heat Pump Unit - -- - - - - - 2.The dimension for Swimming Pool Heat Pump - - - - - - - - - - - - - -- 2 3.Wire controller operation guide- - - - - - - - - - - - - - - - - - - - - - - - -- - - 3 4.Maintenance- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -- 7 5.Malfunction and solution - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 7...
- Page 3 Dear customers: In order to use this machine safely, please read this user's manual carefully before using and installation, especially pay attention to each notice remark for usage and maintenance. Also keep it carefully for later use. Heat pump water heater is a professional machine, it may cause damage or hazard when wrong installed.
- Page 4 SWIMMING POOL HEAT PUMP 1.Performance data of Swimming Pool for A type SBR-26.0H-B-S SBR-50.0H-A-S Model 26000 50000 Rated Heating Capacity 90000 170000 BTU/h 36000 18200 Rated Cooling Capacity 62000 125000 BTU/h Heating Range 15~40 Cooling Range 8~30 11100 5650 Heating Input Power...
-
Page 5: The Dimension For Swimming Pool Heat Pump
SWIMMING POOL HEAT PUMP 2.The dimension for Swimming Pool Heat Pump SBR-26.0H-B-S 1115 SBR-50.0H-A-S 1450... -
Page 6: Wire Controller Operation Guide
SWIMMING POOL HEAT PUMP 3.Wire controller operation guide The functions of the wire controller Stand by status Start-up state Initialization Remarks: Standby status means the unit is connected with electricity but not running. 1) Wire Controller Button Definition " "Button------To turn on or turn off your heat pump You may turn on or turn off the heat pump in any state. - Page 7 SWIMMING POOL HEAT PUMP 2) Wire Controller Operation Check the working status In the state of OFF, LCD display ambient temperature , In th state of ON, LCD display water in temperature and water out temperature ； In the default state，press" "or "...
- Page 8 SWIMMING POOL HEAT PUMP The unit’s operation data can be set on the wire controller. Please set according to below table: Digit meaning Range Default Adjust(yes/no) Return water temp. ℃ 8-28℃ Setting(cooling mode) Return water temp ℃ 15-40℃ Setting(heating mode) Total working time of 30-90MIN 40MIN...
- Page 9 SWIMMING POOL HEAT PUMP Timming ON /OFF Setting In default state, long press " " for 3 seconds to enter Timing Setting state.In the state of Timming Setting ,press " " again，the hour numbers for timing ON flash, press " "...
-
Page 10: Malfunction And Solution
SWIMMING POOL HEAT PUMP 4. Maintenance To check the water supply device often. You should avoid the condition of no water or air entering into system, or that will influence unit’s performance and reliability. You should clear the water filter regularly to avoid unit’s damage by filter’ jam. There should be dry, sanitary and ventilation around the unit. - Page 11 SWIMMING POOL HEAT PUMP Connection of PCB illustration Chiller 300 ROOMT PIPE2 PIPE1 OUTWT INWT Connections explanation: NO . Symbol Meaning HI FAN High speed for fan PUMP Water pump(220VAC) Fan motor(220VAC) VAL2 4way valve of system2(220VAC)(no use) VAL1 4way valve of system(220VAC) COMP2 Compressor of system2 (220VAC)(no use) COMP1...
-
Page 12: Wiring Diagram
SWIMMING POOL HEAT PUMP 6. Wiring diagram SWIMMING POOL HEAT PUMPWIRING DIAGRAM SBR-26.0H-B-S 4way valvel GREY R S T N 3 phase power supply INWT OUTWT PIPE1 PIPE2 ROOMT BL Y/G GRN TEMP. TEMP. TEMP. TEMP. SENSOR SENSOR SENSOR SENSOR... - Page 13 SWIMMING POOL HEAT PUMP Error code Protection Refrigerant anti-freezing protection(Not available for the moment) Refrigerant leakage protection(Not available for the moment) Refrigerant low pressure protection Gas compressing side high temperature protection Compressor over-current protection Refrigerant high pressure protection System refrigerant inlet pipe sensor protection(Not available for the moment) System refrigerant outlet pipe sensor protection(Not available for the moment) Gas compressing side temperature sensor protection Power source phase protection...
-
Page 14: How To Obtain Service
SWIMMING POOL HEAT PUMP Service 1.How to obtain Service For Pool Owner If you are having trouble with the unit, please contact the Installer immediately. 1. Provide your Dealer with the following information: A. Serial # located on back panel nameplate . B. - Page 15 SWIMMING POOL HEAT PUMP Pool Temperature Range Heated pool max temp Heated pool min temp Unheated pool max temp Unheated pool min temp 2.The charts displayed for an indoor pool are Energy flows for indoor pool. Pool temperature during daytime operating period. Space temperature during daytime operating period.
- Page 16 SWIMMING POOL HEAT PUMP Space Temperature operating period Maxlmum Minlmum Space Humidity operating period Maxlmum Minlmum The position of installing unit 1000mm above the top Top 2000mm Above Air inlet Outlet Air inlet Air inlet Inlet Inlet Above 1000mm Above 1000mm Heat pump 1000mm Above...
-
Page 17: The Installation About Heat Pump & Chlorinator
SWIMMING POOL HEAT PUMP Attachment 2 The Installation about Heat Pump & Chlorinator Pressure-type Chlorinator or Brominator Chlorinator Check-valve Filter Water Pump P-trap Check-valve In-line Chlorinator or Brominator Filter Water Pump P-trap Check-valve Chlorinator... - Page 18 SWIMMING POOL HEAT PUMP...
-
Page 19: Common Units Conversion
SWIMMING POOL HEAT PUMP Attachment 3 Common Units Conversion Linear Measure 1 inch=25.4 millimetres 1 foot=12 inches=0.3048 metre 1 yard=3 feet=0.9144 metre 1 (statute)mile=1760 yards=1.609 kilometres 1 nautical mile=1852 m. Square Measure 1 square inch=6.45 sq.centimetres 1 square foot=144 sq.in.=9.29 sq.decimetres 1 square yard=9 sq.ft.=0.836 sq.metre 1 acre=4840 sq.yd.=0.405 hectare 1 square mile=640 acres=259 hectares...
