SMARTBOX Wi-Fi
ENGLISH
Installation Manual
• Connected via Ethernet to the router
• It requires no configuration
• No computer required
• Powered via a micro USB adapter
• It manages the data collected from the various devices
connected
• Each home requires at least one Smartbox
PE - DERXPE007 EN 10/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smartbox Wi-Fi and is the answer not in the manual?

Questions and answers

Summary of Contents for Perry Electric Smartbox Wi-Fi

  • Page 1 SMARTBOX Wi-Fi ENGLISH Installation Manual • Connected via Ethernet to the router • It requires no configuration • No computer required • Powered via a micro USB adapter • It manages the data collected from the various devices connected • Each home requires at least one Smartbox...
  • Page 2 CONTENTS WARNINGS............................page 3 INSTALLATION ..........................page 4 System assembly Radio range warnings.......................... page 5 SMARTBOX INSTALLATION page ....................... F.A.Q. (frequently asked questions) ...................... page 7 RESET SMARTBOX ..........................page 8 SMARTBOX TECHNICAL SPECIFICATIONS ..................page 8 SIMPLIFIED EU DECLARATION OF CONFORMITY ................

  • Page 3: Warnings

    WARNINGS The installation and electrical connection of the Important: for the system modes and operation devices and appliances must be implemented by of the WIFI temperature control system and for qualified personnel and in conformity with current correct installation, also see the specific laws and regulations.

  • Page 4: Installation System Assembly

    INSTALLATION System assembly ROUTER INTERNET SMARTBOX ** ENERGY METER WiFi (optional) *EXPANDABLE (up to 30 devices): *WI-FI PROGRAMMABLE THERMOSTAT the dwelling can be divided into several thermal zones by adding other programmable thermostats (even in homes with distribution manifolds). it is possible to add n° 01 **Energy meter (optional).

  • Page 5: Radio Range Warnings

    INSTALLATION Radio range warnings During installation, some precautions must be taken in order not to limit or, in some cases, inhibit the range of the radio waves between Smartbox and i dispositivi connessi , in particular: - install the appliance away from metal furniture or structures which could alter or screen propagation of radio signals; - make sure that there are no electrical or electronic devices (television, microwave oven, etc.) within a range of at least 1 m from the appliance;...

  • Page 6: Smartbox Installation

    SMARTBOX INSTALLATION Ethernet micro USB 3. Control of LEDs 1. Connect the Smartbox to the router Normal: orange light on, alternating with green light with the Ethernet cable every 5 seconds; otherwise see FAQ on next page. 2. Connect power by means of the micro USB adapter 4.

  • Page 7: F.a.q. (Frequently Asked Questions)

    F.A.Q. (frequently asked questions) 1) The Smartbox does not connect. Check that the unit is powered and correctly connected to the router of the user by means of the Ethernet cable, without proxy and with 123 UDP, 5000 TCP and 5001 TCP ports open. The DHCP protocol must be enabled on the router. The LEDs on the Smartbox indicate: ·Green light off, orange light flashing once each second: Smartbox in discovery mode to find new devices to connect.

  • Page 8: Reset Smartbox

    869,525 MHz, Manufacturer, Fabricat , Fabrikant , Fabbricante, Fabricante: with a max. power 0.75mW e.r.p. PERRY ELECTRIC S.r.l. •Dimensions: Via Milanese, 11 L = 102mm; P = 76mm; H = 35mm 22070 VENIANO (Como) - ITALY Tel.
