Paper Battery PowerResponder Quick Start Manual

The Paper Battery company is pleased to provide a fast charger evaluation platform for the PowerResponder
line of supercapacitors. The kit contains a wall adapter, fast charge board and reference circuit diagrams as
requested and includes two PowerResponder™ cells. The kit will enable customers to quickly and effectively
evaluate PowerResponder
products.
NOTE: This kit cannot be used for charging lithium-ion batteries, which are unsafe under fast charge conditions
Theory of operation:
TM
The PowerResponder
current in less time than conventional lithium ion batteries. The Paper Battery Company has data on cycle life
impact showing thousands of cycles with less than 20% loss of capacitance. PowerResponder
open circuit mode after a gradual, easily measureable, and thus predictable, decrease in capacity. There is no
risk of flammability or thermal run-away from the PowerResponder
Our fast charger kit includes a standard off-the-shelf 36 Watt AC line adaptor providing 18 Volts at 2 Amperes.
The charging subsystem is a microprocessor controlled CC/CV buck converter with an integrated LED fuel gauge.
Current and voltage set points are configurable with the onboard potentiometers. The default configuration is 5A
Proprietary I nformation© P aper B attery C ompany w ww.paperbatteryco.com
For m ore d etails o n a pplications o r t o o btain s amples, c ontact: s ales@paperbatteryco.com
PowerResponder™ F ast C harger K it
Reference D esign a nd Q uick S tart G uide
TM
and provide design guidance when integrating PowerResponder
product line is a hybrid, high energy supercapacitor and can be charged at much higher
Block Diagram of the Fast Charger Board:
PowerResponder™ A pplication N ote # 150301
TM
cells.
TM
TM
cells into their
TM
devices fail in
