Summary of Contents for AOS SD Streaming server
- Page 1 Streaming server installation and operation manual...
- Page 2 SECTION DESCRIPTION PAGE General Information Introduction Purpose of the equipment Application Introduction Typical application Installation Prior to installation Cautions and warnings Wiring Physical Characteristics Electrical Characteristics Post Installation Test Troubleshooting Layout and Operation Layout diagram Lamp Codes Operation Specifications...
-
Page 3: General Information
(AOS) physical and electrical characteristics of the unit. 1.2 Purpose of the equipment AOS’s SD Streaming server (SDSS) has been designed to offer low bandwidth composite video streaming to a globally accessible shore based server. In the recommended installation, the unit receives power from a 240v AC Source, Video from a composite video source, and internet via an ethernet port. -
Page 4: Typical Application
2.2 Typical application Within a rack mount environment, the SDSS will be installed above or below other servers. Specific rack mount instructions apply to the installation process. Please see section 3 for more details. 3.0 Installation 3.1 Prior to installation The SDSS is a simple module to install. - Page 5 3.1.3 The following rack mount instructions should be followed: A) Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than room ambient. Therefore, consideration should be given to installing the equipment in an environment compatible with the maximum ambient temperature specified by the following table:...
-
Page 6: Cautions And Warnings
3.2 Cautions and Warnings 3.3.1 Do not remove any factory-installed screws 3.3.2 Do not install near heat sources 3.3.3 ESD (Electro Static Discharge) precautions shall be followed when installing 3.3 Wiring Requirements 3.4.1 The length and routing of external cables should be carefully studied and planned before attempting installation of the equipment. -
Page 7: Physical Characteristics
3.4 Physical characteristics 3.5.1 The shall be located away from heat SDSS sources, magnetic fields and areas with excessive dust. 3.5.2 When using a rack mount, the unit shall be rigidly mounted to its location using the appropriate hardware 3.5 Electrical characteristics Input Voltage : 100-240Vac 50-60Hz... -
Page 8: Troubleshooting
3.6.6 Confirm live stream present by accessing the online location. The stop stream button is used to cancel a live stream, in which case the stream start stream green led will be extinguished. 3.7 Troubleshooting 3.7.1 If the stop stream red LED is illuminated after startup, the SDSS has not detected a reliable internet connection. Please check the... -
Page 9: Layout And Operation
4.1 Layout diagram 4.2 Lamp Codes Solid Green Lamp - Connection with AOS Server established, streaming. Flashing Green Lamp - Connecting to AOS Server. Can take several minutes initially. Solid Red Lamp - Network error, WAN connection to AOS Server Not available. -
Page 10: Operation
4.3 Operation To power on the unit after initial installation or power fail, press the power button above. To start streaming, press the Start stream button. the green button bezel will flash periodically while the unit establishes a live stream. When the stream is established, the green light will become solid. -
Page 11: Specifications
5. Specifications Power and requirements Input Voltage : 100-240Vac 50-60Hz Typical Consumption : 600w Operating temperature : 10° to 35° C (50° to 95° F) Storage temperature : -40° to 47° C (-40° to 116° F) Relative humidity : 5% to 95% non-condensing WAN : Min 256Kbps Typical acoustical performance: Sound pressure level (operator...
