Broan 52WH254DP Installation Instructions

MODEL: 52WH254DP, 52WH254DPF,
52WH304P, 52WH304PF,
52WH304DP, 52WH304DPF
RECESSED MOUNTED,
STEEL MEDICINE CABINETS
1. Carefully remove all packing material. Place
hardware packages, shelves and door aside until
needed. Hardware and shelves are located in the
fillers identified by "Hardware enclosed" tape.
2. Determine desired location of cabinet on wall.
Mark wall to show wall opening size (see
dimension chart). Generally, the recommended
height to the center of the cabinet is 64" from the
floor. (Fig. 1)
3. CAUTION: Wall studs, plumbing or electrical lines
that interfere must be removed or relocated. Cut
wall opening, being careful not to damage the
surrounding wall surface. Insert framing to
support all plaster board edges.
Fig. 1
Fig. 3
Wall
Opening
4. Prepare the mounting screws by placing the
5. Note: For ease of installation, an additional person is
6. Snap the screw covers over the screw bases.
Fig. 2
Insert screw
through clear
plastic base
Cabinet
Body

INSTALLATION INSTRUCTIONS

MODEL WALL OPENING
NO.
52WH254DP 19
52WH254DPF 19
52WH304P 23
52WH304PF 23
52WH304DP 23
52WH304DPF 23
screws into the clear plastic bases. (Fig. 2)
recommended. Insert cabinet into wall opening.
(Fig.3) Ensure the cabinet is plumb and level. If
necessary use a carpenter's level and shim corners of
cabinet. Secure to wall studs through the four (4)
mounting holes inside cabinet, using the screws that
have been placed into the plastic bases. (Fig. 4) Do
not over tighten the mounting screws as the body
side wall may bend and prevent proper shelf
installation. Only tighten screws until they are
flush with the body.
(Fig.5)
Snap on Cover
Screw
Fig. 4
Mounting
Screws
OVERALL SIZE
W H D W H
1
/ 24 4 20 25
4
1 / 24 4 20 25
4
1
/ 29 4 24 30
4
1 / 29 4 24 30
4
1
/ 29 4 24 30
4
1 / 29 4 24 30
4
Fig. 5
Cover
Base
Mounting
screw into
mounting
hole
D
5
5
5
5
5
5
