The Handy THPDS65 Instruction Manual

Petrol chipper shredder
Hide thumbs

Advertisement

Quick Links

Download this manual
INSTRUCTION MANUAL
CHIPPER SHREDDER
Model No: THPDS65 -- Product No: 1938153001
MINIMUM OF TWO PERSONS ASSEMBLY REQUIRED
SAVE THESE INSTRUCTIONS
SPARES & SUPPORT: 01793 333212
Please read & understand this manual, paying attention to the safety instructions, before use.
The manufacturer reserves the right to change the product specification and livery according to
continued product improvements.
Images used are for illustration purposes only
27/07/2017

Advertisement

loading
Need help?

Need help?

Do you have a question about the THPDS65 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for The Handy THPDS65

Summary of Contents for The Handy THPDS65

  • Page 1 INSTRUCTION MANUAL CHIPPER SHREDDER Model No: THPDS65 -- Product No: 1938153001 MINIMUM OF TWO PERSONS ASSEMBLY REQUIRED SAVE THESE INSTRUCTIONS SPARES & SUPPORT: 01793 333212 Please read & understand this manual, paying attention to the safety instructions, before use. The manufacturer reserves the right to change the product specification and livery according to continued product improvements.
  • Page 3 CONTENTS SPECIFICATION IMPORTANT INFORMATION GENERAL SAFETY INSTRUCTIONS GET TO KNOW YOUR MACHINE COMPONENTS ASSEMBLY OPERATION MAINTENANCE STORAGE TROUBLE SHOOTING PARTS DIAGRAM & LIST EC DECLARATION OR CONFORMITY WARRANTY NOTES MINIMUM TWO PERSONS ASSEMBLY IS REQUIRED This product requires assembly by a MINIMUM OF TWO PERSONS before use. See the “Assembly”...
  • Page 4 SPECIFICATION The manufacturer reserves the right to change the product specification and livery according to continued product improvements. Model THPDS65 Product Number 1938153001 Engine Briggs & Stratton XR950 Cubic Capacity (cc) Engine RPM Max. 3600 4 Stroke Engine Oil (Not Supplied – refer to engine manual for spec)
  • Page 5 GENERAL SAFETY INSTRUCTIONS Read and understand the owner’s manual and labels affixed to the product. Learn its application and limitations as well as the specific potential hazards. Retain these instructions for future reference. The operator is responsible for following the warnings & instructions in this manual and on the product.
  • Page 6 TYRES - NOT FOR HIGHWAYS USE Before operating make sure the tyres have the RECOMMENDED TYRE PRESSURE OF 20 PSI (Do not exceed 20PSI). We recommend the use of FOOT or HAND inflation devices only. Do not use electric or mechanical inflation devices. This is a garden/domestic product, therefore extended use over abrasive surfaces (e.g.
  • Page 7 GET TO KNOW YOUR MACHINE...
  • Page 8 COMPONENTS (THIS IS A MINIMUM OF TWO PERSONS ASSEMBLY.) When removing from the carton, take extra care due to the weight of the machine. Please check that all parts required for the assembly of this spreader are included. If for any reason you believe a part for the assembly is missing or damaged, please contact us.
  • Page 9 ASSEMBLY STEP 1: AXLE & WHEELS Attach wheel axle (#24) and wheel (#6) to the base (#1) using hex bolt M8x25 (#26), lock washer Ø8 (#27) and flat washer (#25). Tighten the wheel axle (#24) using hex bolt M6x12 (#16) and hex nut M6 (#52). Attach support leg assembly (#43) to the base (#1) using hex bolt M8x20 (#62), lock washer Ø8 (#27) and flat washer Ø8 (#50).
  • Page 10 STEP 3: INPUT HOPPER Attach the inlet hopper assembly (#5) to the roller cover plate assembly (#20), then fit to the main shredder hopper (#3) using hex bolt M8x20 (#62), lock washer Ø8 (#27) and large flat washer Ø8 (#64). STEP 4: OUTPUT HOPPER Attach the output hopper assembly (#9) to the roller cover plate assembly (#20), then fixed with shredder hopper (#3) using hex bolt M8x16 (#61), lock washer Ø8 (#27) and large flat washer Ø8...
  • Page 11 FUEL & OIL Do not attempt to start this machine until you have read the engine manual thoroughly & followed the relevant instructions within the engine manual regarding oiling & fueling the engine. ADD FUEL • Petrol is an extremely flammable fuel. Keep clear of naked flames. Do not spill any fuel – do not smoke near fuel or the machine.
  • Page 12 OPERATION DANGER The DANGER ZONE on the output of the machine must be respected, to avoid serious injury by chips thrown out of the output tube. Do not allow anyone to enter the operating DANGER ZONE with you. The danger zone is an area 12 metres in radius. Insist that persons in the RISK ZONE beyond the danger zone wear eye protection from thrown objects.
  • Page 13 BEFORE OPERATING THE MACHINE Read the engine manual, ensuring the oiling and fueling of the machine are followed completely. STARTING AND OPERATING THE MACHINE • Start the engine at half throttle and let it warm up for 3 minutes approx. Then put the engine on full throttle.
  • Page 14 TRANSPORTING THE MACHINE • Always turn off the engine. • The engine should be turned off when the machine is moved between areas and when transporting or storing the machine. • When transporting in a vehicle: properly secure your machine to prevent turnover, fuel spillage and damage.
  • Page 15 MAINTENANCE • Before operating make sure the tyres have the RECOMMENDED TYRE PRESSURE OF 20 PSI (Do not exceed). We recommend the use of FOOT or HAND inflation devices only. Do not use electric or mechanical inflation devices. This is a garden/domestic product, therefore extended use over abrasive surfaces (e.g.

  • Page 16: Trouble Shooting

    TROUBLE SHOOTING PROBLEM CAUSE SOLUTION The shredder does not - the blades are worn. - change or sharpen the blades & perform properly: the - the diameter of the counter-blade. Note: that the blades are wood is not pulled in by branches inserted into the sharpened on both edges so they can be the machine itself.
  • Page 17 PARTS DIAGRAM NOTE: Parts Lists are supplied for information purposes only, not all parts are stocked individually & we recommend you contact our Spares Team on 01793 333212 for expert advice.
  • Page 18 PARTS LIST...

  • Page 19: Ec Declaration Of Conformity

    EC DECLARATION OF CONFORMITY We Handy Distribution Ltd - SN3 5HY (Importer) declare that the product: Designation: Chipper Shredder 65 Model(s): THPDS65 Product Number: 1938153001 Type/Serial No: As per rating label on machine Complies with the following directives: 2006/42/EC – Machinery Directive...
  • Page 20 GJ HANDY & CO LTD USER WARRANTY POLICY Users Statement of Warranty Each new machine is warranted against defective material or assembly of material under normal usage. The warranty applies to the original purchaser and covers faulty parts and the labour involved in replacing and repairing those parts, which are of original manufacture.
  • Page 21 GJ HANDY & CO LTD USER WARRANTY POLICY Not covered by this warranty a) The warranty policy does not cover any depreciation or damages caused by ordinary wear, rusting or corrosion, lack of correct maintenance or operation, misuse, abuse, lack of transportation or accident.
  • Page 22 NOTES _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________ _____________________________________________...
  • Page 24 For spares or support of your handy product, please contact us: Tel: 01793 333212 Email: customerservice@handydistribution.co.uk (Mon – Fri 8.00am to 5.30pm excl. Bank Holidays) To see our range of garden machinery & equipment visit: www.thehandy.co.uk Making gardening easier & affordable since 1938 Distributed by Handy Distribution, Murdock Road, Dorcan, Swindon, SN3 5HY...
