Summary of Contents for Kingfisher gardening GCART3
- Page 1 Heavy Duty Garden Cart User Manual CODE: GCART3...
- Page 3 Thank you for purchasing this product, please keep this manual for future reference. Before proceeding please ensure that you have read thoroughly before proceeding and ensure that all the parts and fittings are accounted for and are present. Contents Pack Contents/Parts.................. General Information...................
- Page 4 Garden Cart Pack Contents/Parts Pack contents/parts 1 x Base 1 x Front Axle 1 x Rear Axle 1 x Rear Axle Brace 1 x Longer Side Panel 1 x Longer Side Panel 1 x Rear Side Panel 1 x Front Side Panel 4 x Wheels 1 x Handle with Cushion Grip 10 x Small Bolts...
- Page 5 Garden Cart General Information/Safety IMPORTANT, PLEASE RETAIN FOR FUTURE REFERENCE: READ CAREFULLY! Read and follow the instructions and safety information before using this product for the first time. Any errors made in following the instructions may result in serious injury. Keep all instructions in a safe place for future use.
- Page 6 Garden Cart Assembly Place the base (1) on a flat surface clear of Attach the rear axle (3) to the base (1) using 2 debris. x small bolts (A), 2 x small washers (C) and 2 x small nuts (B) as shown above. Place the rear axle braces (4) into place over Attach the front axle (2) to the base (1) using 4 the axle and attach to the base (1) using 4 x...
- Page 7 Garden Cart Assembly Attach the longer side panel (5) using 2 x split Attach the remaining side (6), rear side panel pins (G) as shown above. (7) and the front side panel (8) as shown above using 2x (G) for each. Attached the 4 x side lock pins (F) as shown to Place the 1 x handle (10) to the front axle (2) the front (8) and rear (7) panels using 1 x (B)
- Page 8 bonnington plastics.com Bonnington Plastics Limited - NG8 4GP...
