NPM Manual
Network Power Manager
(v1.10.1)
Shenzhen Clever Electronics Co.,Ltd.
Page 1 of 28

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NPM2000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clever Electronics NPM2000

  • Page 1 NPM Manual Network Power Manager (v1.10.1) Shenzhen Clever Electronics Co.,Ltd. Page 1 of 28...
  • Page 2 NPM Manual 1. PRODUCT INTRODUCTION......................3 2. PRODUCT DESCRIPTION ......................3 2.1 NPM 2000 ........................... 3 2.2 NPM 3000 ........................... 4 2.3 NPM 4000/5000.......................... 6 3. HARDWARE INSTALLATION ......................7 3.1. O PTION WITCH .......................... 7 3.2 N NPM..............8 ETWORK CONNECTION AND DAISY CHAIN OF 4.

  • Page 3: Product Introduction

    For CLVER NPM product, there is Four series, contain:NPM2000、NPM3000, NPM4000, NPM5000. Security feature NPM have two security levels, administrator level and user level. The administrator is allowed to access all configuration and command functions.

  • Page 4: Npm 3000

    NPM Manual Picture 2.1-1. NPM 2000 frontal panel 1: Network connect indicator: light when connect; 2: RND next unit communicated indicator: flashes when next NPM unit is communicating. 3: RLD this unit communicated indicator: flashes when this NPM unit is communicating; 4: RUN run status indicator: flashes when this unit works normal;...
  • Page 5 NPM Manual Switch on/off individual outlet and display on/off status of individual outlet; Timing switch on/off individual outlet and display on/off status of individual outlet; Original state and keep original state of individual outlet; Sequential power up/down individual outlet Display current of individual outlet; Display total current of unit;...

  • Page 6: Npm 4000/5000

    NPM Manual Picture 2.2-2. NPM 3000 back panel 9: MODEM PORT: For connecting MODEM when control via external MODEM. 2.3 NPM 4000/5000 Main character: Vertical installation, super high power, 380V AC input (NPM 5000); Switch on/off individual outlet and display on/off status of individual outlet; Timing switch on/off in dividual outlet and display on/off status of individual outlet;...

  • Page 7: Hardware Installation

    NPM Manual 2: Max. 24way outlets; 3: Three system signal indicator RUN: Flashes when NPM work normally; RLD: Lights when NPM unit receive command; RND: Lights when command received not from this unit; 4: Indicator of network connection 5: Three connect ports NET: For connecting master NPM to WAN, LAN or PC, when control via network;...
  • Page 8 Input cable Slave NPM connect to connect PC COM port next NPM Picture 3.2-1. NPM2000 series connection planation of NPM 2000 series connection: 1: If control NPM via network, please connect to RJ45 port of PC or HUB, Router, Switch, etc.

  • Page 9: Use Of Control Software

    NPM Manual Explanation of NPM 3000 series connection (NPM 4000/5000 series similar） 1: T emperature/humidity sensor; : If control NPM via network, please connect to RJ45 port of PC or HUB, Router, Switch, etc. : If control NPM via local RS-232, connect to COM port of PC. : NPM daisy chain cable, begin at master NPM unit, from LINK port to RS-232 port of next NPM unit, the rest may be deduced by analogy.

  • Page 10: Login System

    NPM Manual 4.2.1 Login system Picture 4.2.1-1 Login system Explanation: 1: After finished installation of software, there are two default login name: “lxb” and “aa”, “lxb” is administrator, “aa” is normal user, both passwords are 123. 2: Press “Database”, can configure database information. As following: Picture 4.2.1-2、Database configure The database had kept necessary information for running the software.
  • Page 11 NPM Manual Picture 4.2.2-1 Main screen 1、System menu; 2、NPM group choose. Can group NPM units according area or other requirement: For example, China, USA, Germany or Guangzhou, Shanghai, Shenzhen, etc. Explanation: t groups, NPM name can different. (contain outlet name.); A: NPM of differen B: NPM unit of different groups have relative configuration.( such as network IP);...
  • Page 12 NPM Manual Choose NPM, when choose you can read this NPM; Status parameters of NPM: 1~8: on/off status of NPM outlet, and current of outlets. Green color means switch on, white color means switch off, grey color m eans invalid or have no right to access relative outlet. A：total current of this 8way outlets;...
  • Page 13 NPM Manual Configure port and baud rate. When “Connect Type” is Modem, configure parame ters: The “Tel” is p hone number of the phone wire which connecting to the external MODEM; “Port” number is PC’s MODEM port number ; “Baud Rate”: Choose one of them. 4.2.3 Initialization network config Initializing NPM network config before control NPM via network...
  • Page 14 NPM Manual Press search all NPM units of the same network. And list these nits.The list contains module type, IP address, physics address, etc. Double click a cert ain NPM, it will show the main parameters of this NPM at “Property” section at right.
  • Page 15 NPM Manual “Properties” menu. Then the modifying can be sent to NPM. If you fill a wrong value and haven’t applied it, you can click “search” and modify again. If the NPM can’t work because of modifying (For example modify to a wrong IP address, wrong subnet mask, or forget sword), you can resume defaulting configuration when factory installed.
  • Page 16 NPM Manual C) Run the NPM management software in the remote PC, login as administrator, in the m window, enter the “HOST IP” and the two ports. The “HOST IP” is the same with the “WAN” port’s IP address of LAN’s Router. This LAN means the LAN which the NPM belong. 4.2.4 Control Screen Details In main...
  • Page 17 12: Apply for timing setting, Making the timing setting effectively. Picture 4.2.4-2 NPM 3000 control managing window NPM3000 control interface setting, except saving all setting of NPM2000, the main difference Add current display, sensor data display, setting of alarm as follow: 1.

  • Page 18: The Alarm Setting About The Overload And Exceed Limit

    NPM Manual Picture 4.2.4-3. NPM 4000/5000 control managing window NPM 4000 NPM4000 due to the character of super great current, This control interface setting, except saving all setting of NPM3000, the main difference is: Add the group setting of outlets, and grouping current display as follow: NPM4000 1: A group total current, A group 1-8 way current display of outlet units;...

  • Page 19: The Automatic Manage Setting

    NPM Manual Picture 4.2.5-1、setting the safety limit bound 1, Pre ss “Warning” can enter the overload and exceed limit setting. 2, Th administrator can set the outlet current, tempera ture and humidity limit bound If the system operating automonitor, the system will send the alarm when the outlet data over top the setting data.
  • Page 20 NPM Manual Picture 4.2.6-1、The automatic manage setting. explain： Setting the automatic manage parameter Interval Interval about the automatic reply data Monitor Type Monitor Type Warning Records Inquire about alarm records All Records Keep all the monitor data。 Enable sound prompt If choose the sound alarm and can user-defined the soun Enable sound prompt...

  • Page 21: User Management

    NPM Manual When you set the interval, this window will display the NPM outlet state in time, when the outlet data overtop the setting data and the NPM will automatic give an alarm. Picture 4.2.6 -3 、the automatic manage record The system will aut omatic record these overtop current...

  • Page 22: Assign Properties Of Npm For User

    NPM Manual Picture 4.2.7-1、the user manage Press “”A dd new” can add new user. As show in following picture. （3 ） Picture 4.2.7-2、the user manage (4) In the list choose one user and pr ess ”Modify”, then you can edit the user information. (5)Press “property can assign the properties for the current user.
  • Page 23 NPM Manual 865161620 Picture 4.2.8-1、NPM property configuration 1、It is the first step choosing NPM group； 2、Administrator have the right control all the NPM； 3、The administrator assign the user’s right，the frame display each PNM’s outlet state in the window，if you choose ones and you have the right to control, then you can see the outlet state and current.

  • Page 24: Change The User

    NPM Manual 4.2.10 Change the user Entrance:(main menu: system>>change user) Change the current login user and login again. 4.2.11. Modem initialization Entrance:(main menu: Tools>>modem initialization) This function is conveniences connect with the NPM external modem. When the user use it, the external modem connect with the pc port directly, then select the parameter (the main setting: how many times the system will automatism answer, baud rate, diabolo or no,) press ”modify is OK”.

  • Page 25: Technology Parameters

    NPM Manual 3、 Press will delete all marking groups。 4、 Below the window attribute is the current attribute, the user can divide attribute into two items: copy it from another group, clear these attribute. 5、 Press will show the Groups List， choose one group and copy the content to the currentl y group.

  • Page 26: Installation

    NPM Manual NPM 300 0、NPM 4 000、NPM 5 000： 1、o ne piece of NPM； 2、one piece of (3 pin)； 3、o ne piece of network cable(beeline)； 4、o e n piece of CD (contain a manage software and the user manual 7: Ins tallation 1: The ha rdware Configuring...
  • Page 27 NPM Manual Picture7 -2、connecting configure Choose RS-232 a nd port number, baud rate, then press “Connect Type” again to exit the choosing frame. 4、Choose the first NPM(put√in the c hoosing frame),press inferior button “Read”to read NPM state data. 5、Press “Detail(01)” to enter the controlling window, press inferior button “Prope rty”...

  • Page 28: Appendix1 List For Default Occupied Ports In Tcp And Udp

    NPM 用户使用手册 Appendix1 List for default occupied ports in TCP and UDP Agreement Port Reservation TCP port multi channel server 2reservation 2 ECHO Reservation Reservation Reservation Network status TELNET SMTP Printer Time server Name server Reservation Login host computer agreement DHCP DHCP TETP...
