Eborn G-01 Owner's Manual

Hd gps dvr
Hide thumbs Also See for G-01:
Table of Contents

Advertisement

Quick Links

EBORN TECH
HD GPS DVR G-01
Owner' s Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Eborn G-01

Summary of Contents for Eborn G-01

  • Page 1 EBORN TECH HD GPS DVR G-01 Owner’ s Manual...
  • Page 2 We are always here to help ,please do not hesitate to let us know if any questions or concerns you may have! Your 100% satisfaction is our priority! You can download firmware/user manual, view set up videos at our website! www.Eborn.net.cn Customer Service : service@eborn.net.cn Technology Support : tech@eborn.net.cn...
  • Page 3 Table of Contents About EBORN G-01 Dashboard Camera ............................... 2 Setting Up for First Time Use ..................................2 EBORN Dash Cam G-01 Layout ..................................3 Main Interface Instruction ..................................4 Recording mode ......................................5 Preview mode......................................5 Menu mode ......................................... 6 Playback mode ......................................
  • Page 4 About EBORN GPS Dashboard Camera G-01 The G-01 is designed to automatically turn ON when it receives power to the DC IN port. It also automatically shuts down and records for a few extra seconds using the internal battery when the power is shut off (to avoid any sudden power cuts and possibly corrupting data).
  • Page 5 Greenwich Mean Time (find setting menu-Time Zone),the GPS will locate in 1~ 3mins. We have set up video steps on www.eborn.net.cn EBORN G-01 Layout Structure 9. Power port 1. Power 10. TF card port 2.

  • Page 6: Main Interface Instruction

    Main Interface Instruction: 4 / 20...
  • Page 7 Button functions: 5 / 20...

  • Page 8: Recording Mode

    The camera will check if there has a memory card when boot up. When first time use it will ask you format the memory card, please choose YES and format it. .After formatting ,EBORN dash cam will start recording. Button functions in recording mode: Preview mode Press OK button to stop recording and switch to preview mode.

  • Page 9: Menu Mode

    Menu mode Press OK button to stop recording then press the menu button. Button functions in menu mode: Tips: If you press the menu button during preview mode,it will direct you to the recording menu, and if you press it during photo mode,it will direct you to the photo menu. 7 / 20...
  • Page 10 8 / 20...

  • Page 11: Playback Mode

    Playback mode Long press M button at preview mode, it will direct you to playback mode, you can see a video list: 9 / 20...

  • Page 12: Photo Mode

    Choose a file to play, you can use the button to delete or move to another file: Photo mode Short Press M button at preview mode: 10 / 20...

  • Page 13: Parking Monitor

    Parking Monitor Please mount the hardwire kit first before using the parking mode, Using a hardwire kit requires some basic technical skills. Depending on your vehicle, you can route the wires to the back of your cigarette lighter or fuse panel. If wiring to a fuse panel, please use a multi--meter or a test light to find a fuse that is ON when vehicle is in Accessory/Ignition and is off when vehicle is off.

  • Page 14: Locked Video

    2.find "way of monitor", choose the monitor way way of monitor Description Can be set to 1 second / frame, 2 seconds / frame, 5 seconds / frame, 30 time lapse seconds / frame. The default is 1 second per frame. When choose time lapse, it will continue recording, the playback speed is 30 frames per second.

  • Page 15: Ldws

    SD card space status LDWS (Lane Departure Warning System) start “LDWS calibration” at menu: press OK button to start First step: Press “Up” and “Down” button to adjust purple line to end of road(horizontal). Second step: press “Up” and “Down” button to adjust red line to the edge of engine cover(liking picture),after adjusting,press OK to exit LDWS calibration.

  • Page 16: Video Resolution

    When car deviate the road,the camera will beep warning and shows below: Resolution Video resolution can be selected up to 2304 x 1296P. Higher resolution produces a higher quality image. The higher the resolution, the higher the file size. A standard 32GB microSD card will hold approximately 8 hours at the highest resolution mode available.

  • Page 17: Low Light Warning

    Low Light Warning System (Lamp Start Tips) Under low---light conditions the camera will remind you to turn on your headlights. Fatigue Warning System The camera device will display a warning picture and warning tone when you have been continuously driving for more than safety driving time you set. Car Start tips ( Safety Driving Distance Warning) Including the front car start reminder and saftety driving distance warning two features.

  • Page 18: Firmware Upgrade

    Adjust the sensitivity parameter of the sensor so that the camera does not automatically lock all the recorded videos. Firmware upgrade Please download the newest firmware from www.eborn.net.cn to get the newest function for fix bug. Tips: You can check the current firmware in “version” from setting menu. Indicator Instruction When boot up, it will comes blue light first, it means "successfully connect with power",...
  • Page 19 We have install steps video sample on www.eborn.net.cn After installation, click on the top of left, choose the language/map/speed you want. The setting will be saved in your computer when the first time you set ,there is no need to set every-time, unless you change another computer.
  • Page 20 EBORN Electronic Technology Inc WWW.EBORN.NET.CN 18 / 20...
