3/8" Reversible Drill
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
07196
1
Advertisement
Related Manuals for SIP 07196
Summary of Contents for SIP 07196
- Page 1 It is suitable for recycling. Help to protect the environment, take the packaging to the local amenity tip and place into the appropriate recycling bin. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 07196 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
-
Page 2: Declaration Of Conformity
LE12 9NH England As the manufacturer's authorised representative within the EC declare that the 3/8” Reversible Air Drill - SIP Pt. No. 07196 Suppliers Part No. RP7101 Conforms to the requirements of the following directive(s), as indicated. 2006/42/EC Machinery Directive Signed: …………………………………... - Page 3 PARTS LIST Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. Housing AI05-00084 End Plate AI05-00101 Bolt 3×24 AI05-00085 Cylinder AI05-00102 Exhaust Deflector AI05-00086 Rotor vein AI05-00103 Air Inlet AI05-00087 Cylinder pin AI05-00104 Air inlet cover AI05-00088...
- Page 4 SAFETY INSTRUCTIONS EXPLODED DRAWING IMPORTANT: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the drill. When using your drill, basic safety precautions should always be followed to reduce the risk of personal injury and / or damage to the drill.
- Page 5 TROUBLESHOOTING…. cont SAFETY INSTRUCTIONS….cont The compressed air supply MUST be at a suitable regulated pressure. Pipe work, reg- ulators, hoses, isolation valves and connection devices MUST be suitable for the in- tended application correctly installed and maintained in good condition by a com- PROBLEMS POSSIBLE CAUSES REMEDIES...
- Page 6 SAFETY INSTRUCTIONS….cont OPERATING INSTRUCTIONS….cont Understand the operating environment; Before each use the operator should assess, understand and where possible reduce the specific risks and dangers associated Note: Never start the drill with the bit touching the work-piece. Allow the drill with the operating environment.
- Page 7 OPERATING INSTRUCTIONS….cont GETTING TO KNOW YOUR AIR DRILL amounts of oil should be avoided. In the event that it becomes necessary to store the tool for an extended period of time (overnight, weekend, etc.), it should receive a generous amount of lubrication at that time.
- Page 8 Quick Connector Quick Connector Filter This SIP air tool is covered by a 12 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or operating Tool the machine outside the scope of this manual.
