- Page 1 RazorSafe 7-Series Hardware Getting Started Guide Release: AOS 5.0 September 2010 Part Number: 010-00822c This manual supports Archiving Operating System (AOS) release 5.0 and later releases, and RazorSafe 7-Series appliances, until replaced by a newer edition.
- Page 2 Mirapoint Software, Inc., except that you are permitted to make one copy for archival purposes only in connection with the lawful use and operation of this software.
- Page 3 Contents Mirapoint RazorSafe 170 (RS170) Installation.........5 Obtaining Technical Assistance...................5 Overview ..........................5 Unpacking the Appliance ....................6 Installing the Rails and Appliance in a Rack ...............6 Connecting Keyboard, and Monitor ...................6 Connecting the Power Cable ....................7 Securing the Power Cord.....................7 Connecting Ethernet Cables ....................7 Powering the Appliance ......................8...
- Page 4 Additional Information ............... 15 Other Information You Might Need ................15 Technical Specifications ....................16 RS170 Technical Specifications ................. 16 RS700 Technical Specifications ................. 19 S7000-RS Technical Specifications ................22...
-
Page 5: Mirapoint Razorsafe 170 (Rs170) Installation
If you need help understanding a procedure in this guide or if the appliance performs unexpectedly, see Additional Information on page 15 and the Mirapoint RazorSafe 170 (RS170) Hardware Guide. Overview Installing and configuring your appliance involves the following tasks:... -
Page 6: Unpacking The Appliance
Mirapoint RazorSafe 170 (RS170) Installation Unpacking the Appliance Unpack your appliance and identify each item. Installing the Rails and Appliance in a Rack If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment might be greater than room ambient temperature. -
Page 7: Connecting The Power Cable
Plug the other end of the power cable into a grounded electrical outlet or a separate power source such as an uninterruptible power supply (UPS) or a power distribution unit (PDU). Connecting Ethernet Cables Mirapoint recommends the use of Category 5 patch cables; port connections are standard RJ-45. Designated Ethernet Port... -
Page 8: Powering The Appliance
Install the bezel (optional). Completing the Operating System Setup The Archiving Operating System (AOS) is pre-installed on all Mirapoint RazorSafe appliances. Once your appliance is physically installed and powered on, you must complete the software configuration as described in the Mirapoint RazorSafe Software Configuration Guide. -
Page 9: Mirapoint Razorsafe 700 (Rs700) Installation
Obtaining Technical Assistance If you need help understanding a procedure in this guide or if the appliance performs unexpectedly, see Additional Information on page 15 and the Mirapoint RS700 Hardware Guide. Overview Installing and configuring your appliance involves the following tasks:... -
Page 10: Unpacking The Appliance
Mirapoint RazorSafe 700 (RS700) Installation Unpacking the Appliance Unpack your appliance and identify each item. Installing the Rails and Appliance in a Rack If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment might be greater than room ambient temperature. -
Page 11: Connecting The Power Cables
(UPS) or a power distribution unit (PDU). For improved redundancy, Mirapoint recommends connecting the two power supplies to separate circuits, but never mixing the voltages. For example: Do not plug one power supply into a 120V current and the other... -
Page 12: Connecting Ethernet Cables
Mirapoint RazorSafe 700 (RS700) Installation Connecting Ethernet Cables Mirapoint recommends the use of Category 5 patch cables; port connections are standard RJ-45. Designated Ethernet Port Powering the Appliance Press the power button on the appliance and the monitor. The power indicators illuminate. -
Page 13: Completing The Operating System Setup
Completing the Operating System Setup Completing the Operating System Setup The Archiving Operating System (AOS) is pre-installed on all Mirapoint RazorSafe appliances. Once your appliance is physically installed and powered on, you must complete the software configuration as described in the Mirapoint RazorSafe Software Configuration Guide. - Page 14 Mirapoint RazorSafe 700 (RS700) Installation...
-
Page 15: Additional Information
The CD and DVD media, which accompanies these instructions within the ◆ folio, provides documentation and tools for configuring and managing your appliance. Always first check for updates online at support.mirapoint.com, and read any updates, because they often supersede information in other documents. -
Page 16: Technical Specifications
Additional Information Technical Specifications RS170 Technical Specifications Processor Processor type ® ® Xeon Single Quad-core Intel Expansion Bus Bus type PCI Express Generation 2 Memory Memory capacity 8GB DDR3 Drives Hard drives Two 3.5-inch cabled SATA internal drives Optical drive One internal slimline SATA DVD-ROM Connectors Back... - Page 17 Technical Specifications Power AC Power Supply Wattage 250W Voltage 100-240 VAC, 50/60 Hz, 4-2 A Heat dissipation 1039 BTU/hr maximum Maximum inrush current Under typical line conditions and over the entire system ambient operating range, the inrush current might reach 25 A. Batteries Appliance battery CR 2032 3.0-V lithium ion coin cell...
- Page 18 G2 or lower as defined by ISA-S71.04-1985 NOM Information (Mexico Only) The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM): Exporter: Mirapoint Software, Inc. 1215 Bordeaux Drive Sunnyvale, CA 94089 408-720-3700 Importer: VIRMAR COMUNICACION EMPRESARIAL SA DE CV Privada Liendo 708 Sur, Col.
-
Page 19: Rs700 Technical Specifications
Six 3.5-inch, internal, hot-swappable SAS hard drives.* Optical drive One internal slimline SATA DVD-ROM *If you purchased your hardware before September 15, 2010, your configuration is different. For details, contact your Mirapoint representative. Connectors Back Four RJ-45 10/100/1000 Mbps Ethernet... - Page 20 Additional Information Power AC Power Supply (per power supply) Wattage 870 W (Max.) Voltage 90–264 VAC, autoranging, 47-63 H Heat dissipation 2968.6 BTU/hr maximum (Max.) Maximum inrush Under typical line conditions and over the entire current ambient operating range, the inrush current might reach 55 A per power supply for 10 ms or less.
- Page 21 –16 to 10,600 m (–50 to 35,000 ft) NOM Information (Mexico Only) The following information is provided on the device described in this document in compliance with the requirements of the official Mexican standards (NOM): Exporter: Mirapoint Software, Inc. 1215 Bordeaux Drive Sunnyvale, CA 94089 408-720-3700 Importer: VIRMAR COMUNICACION EMPRESARIAL SA DE CV Privada Liendo 708 Sur, Col.
- Page 22 1. Scope. This License governs you (“User”) and your use of any and all computer software, any printed or electronic documentation, or other code, whether on disk, in read only memory, or on any other media (collectively, the “Mirapoint Software”) provided to you as part of or with a Mirapoint Product.
- Page 23 Mirapoint’s total liability to you for all damages exceed the amount paid for this License to the Mirapoint Software. 8. Export Control. As required by the laws of the United States and other countries, User represents and warrants that it: (a) understands that the Mirapoint Software and its components may be subject to export controls under the U.S.
