- Page 1 Neo_WL680 WiFi Module Demo Board User Guide Version 1.0...
- Page 2 Neo_WL680 WiFi Module Demo Board User Guide Revision Record Issue Changes Reviewed By Date V1.0 Initial draft Liu Jie 2014-05 Copyright © Neoway Technology Co., Ltd...
- Page 3 1 Overview ........................1 2 Interfaces ........................1 3 Connection and Commissioning ................. 2 3.1 Top View of WL680 Demo Board ..................2 3.2 Bottom View of WL680 Demo Board ................... 2 3.3 Connection Cables ......................... 3 3.4 M5X0-PWR Board ........................ 3 3.5 Commissioning ........................
-
Page 4: Overview
Neo_WL680 WiFi Module Demo Board User Guide 1 Overview WL680 demo board provides a series of peripheral interfaces, including main power supply interface and UART interfaces for commissioning and software download. You can perform commissioning after connecting to power supply and serial ports. This document describes only the commissioning process. -
Page 5: Connection And Commissioning
Neo_WL680 WiFi Module Demo Board User Guide 3 Connection and Commissioning 3.1 Top View of WL680 Demo Board Connected to Work status antenna ON/OFF indicator Power and serial input connectors 3.2 Bottom View of WL680 Demo Board Copyright © Neoway Technology Co., Ltd... -
Page 6: Connection Cables
3.3 V CMOS level TXD and RXD for the communication between the computer and the module and software update. It is connected to the WL680 demo board through 4-pin cables, which have been soldered to the power board in a sequence of red, black, yellow, and green at one end and should be inserted into the socket of the demo board at the other end. -
Page 7: Commissioning
WL680 demo board USB interface M5X0 PWR board Before the commissioning, you must install the PL2303 Windows Driver. Then, connect the demo board to a computer as shown in the following figure. Copyright © Neoway Technology Co., Ltd... - Page 8 Neo_WL680 WiFi Module Demo Board User Guide If Prolific USB-to-Serial Comm Port (COM) is displayed under Ports (COM&LPT1) in the Device Manager pane of the Computer Management window, the serial port is read properly. Serial Port Copyright © Neoway Technology Co., Ltd...
- Page 9 Select Serial from the Protocol dropdown list. Step 2 Select Serial from the Protocol dropdown list. The following dialog box is displayed. Select the serial port. Set Baud rate to 115200 if no specific requirements. Copyright © Neoway Technology Co., Ltd...
-
Page 10: Material List
Disconnect the connection to the serial port. Terminal display area You can also input commands and press Enter to send the commands. 4 Material List WL680 demo board (including module/excluding module) M5x0-PWR board Power and serial cables ... -
Page 11: Appendix: Schematic Diagram And Pcb Silk Screen
Neo_WL680 WiFi Module Demo Board User Guide Appendix: Schematic Diagram and PCB Silk Screen Copyright © Neoway Technology Co., Ltd... - Page 12 Neo_WL680 WiFi Module Demo Board User Guide Copyright © Neoway Technology Co., Ltd...
