- Page 1 XL-IPM816 PDU remote power control User Manual...
- Page 2 Product function: XL-IPM816 is a kind of PDU product which can provide a steady power supply better for the server. XL-IPM816 can provide relevant information for users and makes corresponding measures of warning or overload power by monitoring the electricity and environment status. The user can get the equipment’s current status and start or shut off each output port by accessing XL-IPM816 through the network port, so as to realize the function of the remote server restart.
- Page 3 Product Diagram Instructions 1、 Power Input Socket IEC320 C20 2、 Output Socket IEC C13 3、 Reset Key 4、 Function Key, Check the machine IP address 5、 Meter Panel, Display voltage, current, temperature, humidity, etc 6、 Network Port, Connect LAN or WAN 3 / 7...
- Page 4 8 output line respectively with the power input end of the server which needs power supply. Connect one side of input line plug with the XL-IPM816 IEC320 C20 input socket, and the other side with the AC power supply socket. After that, XL-IPM816 will start from the first port to the 8th port with interval of 1 second, and supply power for the server.
- Page 5 ③ display as shown below. Users can start or shut off XL-IPM816 8-way output in this interface. Start all: click drop-down box behind the action box, choose “Start”, click the “Apply” button Shut off all : click drop-down box behind the action box, choose “Shut off”, click the “Apply” button...
- Page 6 ④ interface, display interface as shown below: Users can start or shut off time-delay of XL-IPM816 8-way output. The picture above is the factory Settings, it means that the 8 circuit of XL-IPM816 will output from the 1 to the 8 port in sequence in the interval of one second after connecting with power.
- Page 7 The login user name and password of XL-IPM816 can be modified in this interface. After filling in the original and new user name, password and password confirmation respectively, click apply button, the new user name and password will be used at the next time login XL-IPM816.
