Summary of Contents for Scalextric digital ARC PRO
- Page 2 ENGLISH ....................... FRANÇAIS ....................DEUTSCH ..................... ITALIANO ...................... ESPAÑOL ..................... REGULATORY COMPLIANCE INFORMATION ........
- Page 3 CONTENTS PAGE ..................POWERBASE & CONTROLLER GUIDE ..........LED BEHAVIOUR ..................QUICK START GUIDE: STAGE 1 - DOWNLOAD APP ..........STAGE 2 - CONNECT APP ............STAGE 3A - CONNECT CONTROLLERS ......STAGE 3B - CONNECT CONTROLLERS ......STAGE 4 - CONNECT CARS ........... LANE CHANGING ..................
- Page 4 KEY: KEY: Power Switch Power/Bluetooth LED Power/Bluetooth LED Binding Buttons Trigger Binding LEDs Battery Screw Round Power Sockets Battery Door USB Port Lanyard Loop Analogue/Digital Switch (note; Analogue Brake Button mode will switch to ARC AIR functionality. ARC AIR will only run 2 analogue cars, with Lane Change Button no lane changing function available)
- Page 5 Green Solid Controller is in binding mode/ battery is low...
- Page 6 STAGE Download and install the Scalextric ARC App from Google Play or the iTunes App Store.
- Page 7 STAGE Insert the round plugs into the powerbase. Plug transformer into the wall and turn on. The powerbase power/Bluetooth LED will flash orange. Open the ARC App on your smart device and follow the on screen instructions. When the powerbase power/ Bluetooth LED glows solid green, you are ready to race.
- Page 8 STAGE Please note: Your hand controllers should already be connected. However if they are not, or you wish to connect your controller to a different colour, please follow the steps below; Turn off the controller Press and hold binding button on powerbase for colour you wish to connect to – LED will flash green to indicate binding mode.
- Page 9 STAGE Continue holding the trigger and turn the controller on. Release the trigger – your controller is now connected!
- Page 10 Please Note: Your car should already be connected to the controller. However if it is not, or STAGE you wish to connect your car to a different colour, please follow the steps below Place car onto track. (NOTE; only 1 car on the track at a time) Ensure the controller is switched on.
- Page 11 USING THE LANE CHANGER Identify the sensors on the lane change sections of track. During the race, before reaching the sensor, press and hold lane change button. Once the car has passed sensor, release the lane change button. The lane change point will click and the car will change lanes.
- Page 12 IMPORTANT Pit Lane Setup The Powerbase MUST NOT go in the centre of the pit lane, as this will not register a lap when going through the pit lane. To avoid this, connect the power base in the correct position, either before or after the pit lane, when setting up the track.
- Page 13 Note: The pitstop fuctionality can be activated anywhere on the track (ie drivers do not have to enter the pitlane in order for the pitstop button to work). However, it is recommended that a pitlane is used when racing in ARC PRO mode in order to avoid...
- Page 14 Yellow Flag Mode When the Yellow Flag feature is activated in settings, you can use Yellow Flag Mode. If a car comes off of the track, tap the screen of your smart device to raise the yellow flag and restrict all racers speed to 5%. When the car is reconnected with the track, tap the screen again to return all racers to full power.
- Page 16 Your car must be calibrated to race correctly while the in-race features are active.
- Page 18 DRIVER COLOUR KERS When KERS is activate, power will be limited to 80%. When fully charged KERS will give the car 100% power for 3 seconds. TYRES...
- Page 19 Tyre blowout Enter pits Leave pits Yellow Flag Please note: The car's speed will be reduced if you are using the wrong tyres for the weather conditions. Change your tyres by entering the pits.
- Page 20 Fast revving-like rumble Light showers/Heavy...
- Page 21 Top speed Endurance Lane Changing KERS Yellow Flag...
- Page 22 App will automatically pause the race timing. All players should stop racing until the App is resumed as laps and pit stops will not be registered.
- Page 23 The App keeps showing I have stopped for a pit stop/ the second sensor is not picking up the car(s).
