Quick Installation Guide for wivia 3
F o r v e r s i o n
t h
3 . 2 . 0 . 0 – M a r. 1 6
, 2 0 1 5
1. Installation
1. Connect two of antennas to the device.
2. Connect wivia and the display with VGA
or HDMI cable.
* Connect the device and the audio speaker with the
audio cable when you use audio, when you use VGA
cable.
* You do not have to connect the audio cable, when
you use HDMI cable.
3. Connect wivia and the power outlet with
AC adaptor.
4. Switch on the display.
5. Switch on the device by pushing the
button on the front. Confirm the standby
image is on the display.
* Please install the device on the place that you can
switch off the device, and switch off the device after
use.
1
Advertisement
Summary of Contents for UCHIDA Wivia 3
- Page 1 Quick Installation Guide for wivia 3 F o r v e r s i o n 3 . 2 . 0 . 0 – M a r. 1 6 , 2 0 1 5 1. Installation 1. Connect two of antennas to the device.
- Page 2 2. Connect your PC to the network of wivia 1. Switch on the wireless LAN of your PC. 2. Connect the network of SSID which displays on the standby screen of wivia. * How to change the connected network on the PC depends on your PC. * When SSID is not displayed on the standby screen, please confirm which network the wivia connects to the administrator, and connect your PC to the network.
- Page 3 3. Start wivia application from the start-up USB memory * When you install the application to your PC to use wivia, refer to Item 4. 1. Insert the start-up USB memory to your PC. * Before start it, please connect your PC to the network of wivia, as Item 2 on this paper.
- Page 4 * You need not to install wivia application when you use it from the start-up USB memory, refer to Item 3. 1. Download wivia application from the Web site of wivia support, http://www.uchida.co.jp/wivia/support.html. * Download wivia application following to the OS of your PC.
- Page 5 5. Project the screen * This item explains how to project the same screen of your PC to wivia. Please refer to Item 6 when you will see a video with full-screen and smooth by wivia. 1. Click or tap button.
- Page 6 6. See videos * This item explains how to see videos with full-screen and smooth in wivia. Please refer to Item 5 when you will project the same screen of your PC to wivia. 1. Click or tap button. * Connect wivia and audio speaker with audio cable to hear the audio of the video. 2.
